APC Smart-UPS C1000VA LCD 230V(TOWER) 600Watts 1.0Kva
The APC 1000VA Smart UPS is a reliable power backup solution with a capacity of 1000 VA or 600 Watts. It is designed to provide backup power and surge protection for your sensitive electronic equipment. Here are the detailed specifications of this UPS.
- Model: APC 1000VA Smart UPS
- Capacity: 1000 VA / 600 Watts
- Input Voltage: 230V
- Output Voltage: 230V
- UPS Topology: Line-interactive
- Waveform Type: Sine wave
- Transfer Time: 2-6 ms typical
- Nominal Input/Output Frequency: 50/60 Hz
- Input Connection: IEC-320 C14
- Output Connections: 6 x IEC 320 C13
- Battery Type: Maintenance-free sealed lead-acid battery with suspended electrolyte
- Typical Recharge Time: 3 hours
- Communication Ports: USB
- LED Indicators: On-line, On-battery, Replace Battery, and Overload
- Audible Alarms: Battery Backup, Low Battery, Overload, and Fault
- Surge Energy Rating: 680 Joules
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Dimensions (H x W x D): (not available)
- Weight: (not available)
- Cold-start capable
APC SMART-UPS 1000VA, 600watts/ 230v Rack-Mount Provides temporary battery power when the utility power is out.
- Green mode
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
- High online efficiency
Reduces utility costs, generates less heat.
- LCD Status Display
Provides key UPS status at a glance. Multiple status indicators with load and battery bar graphs.
- Pure sine wave output on battery
Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
- Smart Connect
Innovative, easy to use remote monitoring feature that provides automatic notifications, firmware updates, and advanced support services.
- Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.
Specifications
| Output power capacity | 600Watts / 1.0 kVA |
| Output Frequency (sync to mains) | 50/60 Hz +/- 3 Hz Sync to mains |
| Nominal Output Voltage | 230V |
| Input frequency | 50/60 Hz +/- 3 Hz Auto-sensing |
| Input voltage range for main operations | 170 300 Adjustable, 180 287V |
| Other Input Voltages | 220, 240 |
| Battery type | Lead-acid battery |
| Typical recharge time | 3hour(s) |
| Battery Charge Power (Watts) | 72Watts |
| Battery Volt-Amp-Hour Capacity | 216 |
