ZK-Teco Access Control

• General Features:

  • Model: KR502E
  • Type: Proximity access control reader with integrated keypad
  • Function: Supports both proximity cards and PIN code authentication for enhanced security
  • Design: Compact, rugged, and weather-resistant design suitable for various environments
  • LED Indicators: Visual feedback for access status (green for access granted, red for access denied)

• Card & PIN Authentication:

  • Card Type: 125 kHz EM proximity cards
  • Card Reading Distance: Up to 10 cm (depending on the card)
  • Keypad: 4x4 numeric keypad for PIN code entry
  • PIN Code Length: 4-6 digits
  • Authentication Modes: Card-only, PIN-only, or Card + PIN for multi-factor authentication

• Performance & Operation:

  • Operating Voltage: 9V to 16V DC (recommended 12V DC)
  • Current Consumption: < 60 mA (standby), < 120 mA (operating)
  • Operating Temperature: -20°C to 60°C
  • Operating Humidity: 0% to 95% (non-condensing)
  • Door Lock Relay: 1 relay output for controlling electric locks
  • Wiegand Output: Supports Wiegand 26-bit and 34-bit protocols for integration with access control systems

• Material & Build:

  • Material: High-quality plastic with a rugged, weather-resistant enclosure
  • Surface Finish: Smooth, corrosion-resistant surface for durability in outdoor or indoor settings
  • IP Rating: IP65 rated for dust and water resistance, making it suitable for both indoor and outdoor use

• Mounting & Installation:

  • Mounting Type: Wall mountable, simple installation
  • Dimensions: Approx. 110 mm (L) x 75 mm (W) x 18 mm (H)
  • Mounting Hole: Standard mounting hole for easy installation on different surfaces
  • Cable Length: 1 meter cable included for easy connection

• Security Features:

  • Anti-tamper: Tamper alarm feature to prevent unauthorized removal or tampering
  • User Capacity: Can store up to 10,000 cards and 10,000 PINs in memory
  • Event Logging: Logs of access events for auditing and security monitoring

• General Features

  • Model: KR102
  • Type: Proximity card reader
  • Supported card technology: MIFARE cards (13.56 MHz)
  • Card reading range: Up to 5 cm (2 inches)

• Design and Build

  • Compact and durable ABS plastic housing
  • Sleek black finish for modern aesthetics
  • Waterproof design with IP65 rating, suitable for indoor and outdoor use
  • Dimensions: 76 x 43 x 16 mm (H x W x D)

• Compatibility

  • Works with Wiegand 26-bit output format
  • Compatible with most standard access control panels and systems

• Power and Performance

  • Operating voltage: 9V–16V DC
  • Current consumption: ≤ 70mA at 12V DC
  • Fast card reading response for efficient operation

• Installation and Connectivity

  • Simple installation with compact form factor
  • Wiring: 5-wire interface for easy integration with access control systems
  • Mounting: Surface mount

• Environmental Specifications

  • Operating temperature: -20°C to 65°C (-4°F to 149°F)
  • Operating humidity: 20%–95% (non-condensing)

• Additional Features

  • LED indicators: Tri-color LED (Red, Green, Blue) for status feedback
  • Built-in buzzer for audible feedback upon card detection
  • Anti-tamper protection to enhance security

• Design and Build
  • Left-hand configuration for easy installation on left-side oriented doors
  • Material: High-quality zinc alloy with a corrosion-resistant finish
  • Elegant, modern design suitable for hotel, resort, and residential use
  • Available in finishes such as Satin Chrome, Polished Chrome, and custom finishes
• Access Methods
  • RFID contactless access technology
  • Compatible with MIFARE ISO14443A RFID cards
  • Card capacity: Stores up to 200 RFID cards
  • Mechanical key override for emergency access
• Locking Mechanism
  • High-strength mortise lock with dual-latch for added security
  • ANSI Grade 1 certified lock mechanism for durability and safety
  • Anti-panic design ensures easy exit in case of emergency
  • Motorized locking system for automatic operation
• Power Supply
  • Powered by 4 x AA alkaline batteries
  • Battery life: Up to 12 months under normal usage
  • Low battery alert with visual and audible warnings
  • External emergency power port for continuous operation during power failure
• Operational Features
  • Compatible with ZKBiolock hotel management software for centralized control
  • Stores up to 200 audit trail records for tracking access events
  • Time-limited access feature for guest RFID cards
  • Operating temperature range: -10°C to 55°C
  • Operating humidity range: 20%-90% (non-condensing)
• Installation and Dimensions
  • Designed to fit standard mortise door types
  • Compatible with doors having a thickness of 35–55 mm
  • Dimensions: Handle length: 160 mm; Plate size: 290 x 75 mm (HxW)
• Security Features
  • Dual-latch mortise lock system for enhanced security
  • Fire-rated lock for improved safety compliance
  • Anti-tamper features to prevent unauthorized access

General Features

• Model: ZKTeco FR1200-ID
• Type: Fingerprint reader for access control systems.
• Fingerprint Sensor: Optical sensor with high accuracy and reliability.
• ID Card Reader: Integrated 125kHz RFID ID card reader.
• Access Modes: Supports fingerprint, RFID card, or combined access modes (fingerprint + card).

Fingerprint Recognition

• Fingerprint Capacity: Up to 2,000 fingerprint templates for user registration.
• Fingerprint Sensor Type: Optical sensor, providing fast and accurate identification.
• Fingerprint Matching Speed: Less than 1 second for quick authentication.
• Verification Speed: High-speed processing with <1 second identification and verification.

Card Reader

• Card Type Supported: 125kHz EM-ID card reader.
• Card Capacity: Supports 10,000 card records for users.
• Card Reading Distance: Typically 5-10 cm (depending on the card type and conditions).

Connectivity

• Communication Interface:
  • Wiegand output for integration with other access control systems.
  • RS485 for communication with the controller.
• Data Transmission: Can be connected to a central control system for real-time updates or offline use.

Display & User Interface

• Display: LED indicators for status display (access granted/denied).
• Audible Feedback: Buzzer for confirmation of access attempts.

Security Features

• Anti-tamper Mechanism: Built-in tamper detection alerts.
• Data Security: Encrypted data storage to ensure the security of user templates and records.
• Password Protection: Restrict unauthorized access to the device settings.

Power & Battery

• Power Supply: 12V DC via external power supply.
• Power Consumption: Low power consumption for extended usage.

Physical Characteristics

• Casing: IP65 rated housing, waterproof and dustproof for use in outdoor and harsh environments.
• Dimensions: 160mm x 100mm x 50mm.
• Weight: Approx. 500 grams.
• Mounting: Suitable for wall mounting or door frame installation.

Operating Environment

• Operating Temperature: -10°C to 60°C (14°F to 140°F).
• Operating Humidity: 20% to 80% RH (non-condensing)

Biometric Authentication Features

• Fingerprint capacity: Stores up to 3,000 fingerprint templates.
• Card capacity: Supports up to 10,000 RFID cards (125kHz EM).
• Log capacity: Can store up to 100,000 transaction logs.
• Authentication modes:
  • Fingerprint recognition
  • RFID card (125kHz EM)
  • Fingerprint + RFID card combination.
• Verification speed: < 1 second for rapid authentication.

Time Attendance & Access Control Features

• Time attendance management: Automatically tracks work hours and attendance data.
• Shift management: Supports multiple shift patterns for flexible timekeeping.
• Overtime tracking: Manages and records overtime data for payroll purposes.
• Attendance reports: Supports easy export of attendance data for integration with payroll systems.
• Access control: Built-in relay for controlling door locks.
• Anti-passback: Prevents unauthorized access attempts by enforcing entry/exit control.

Display & User Interface

• Display: 3.5-inch color TFT LCD screen for clear user interface and status monitoring.
• Keypad: Touch keypad for easy user interaction.
• LED indicators: Provides visual feedback for authentication status and operations.
• Audio feedback: Audible tones for user confirmation during authentication.

Connectivity & Integration

• Communication interfaces:
  • TCP/IP
  • Wiegand 26/34 input/output
  • RS485
• USB support: USB flash drive for simple data backup and transfer.
• Mobile integration: Bluetooth integration for remote management via the ZKBioBT app (supports mobile device interaction).

Design & Durability

• Material: High-quality ABS plastic housing.
• Weatherproof rating: IP65 for dust and water resistance, making it suitable for outdoor use.
• Operating temperature: -20°C to 50°C, ensuring reliable performance in various climates.
• Operating humidity: 20% to 80% humidity tolerance.

Power & Environmental Requirements

• Power supply: 12V DC, 1A.
• Power consumption: Low energy consumption for cost-efficient operation.
• Backup options: Supports backup battery (optional) to ensure uninterrupted operation during power failures.

Security & Additional Features

• Anti-tamper alarm: Alerts when unauthorized attempts to tamper with the device are detected.
• Multiple user access levels: Customizable access control policies for different user groups.
• Advanced encryption: Uses secure communication protocols for data protection.
• Easy enrollment: Simplified user enrollment process for adding fingerprints and RFID cards.

Physical Dimensions & Weight

• Dimensions: 180mm x 132mm x 42mm (L x W x D).
• Weight: Approx. 0.5 kg.
