9 ways PDU standard sockets with on/off switch
The PDU Standard Sockets with On/Off Switch is a versatile power distribution unit designed to efficiently manage and protect multiple electronic devices. Featuring a master on/off switch, this unit allows for easy control of all connected outlets simultaneously, simplifying power management and enhancing convenience.
With a power rating typically ranging from 10A to 16A and available in 230V AC or 120V AC configurations, it supports a wide range of devices. The PDU typically includes 6 to 12 standard outlets, accommodating multiple devices, and often integrates surge protection with a rating of 1000 to 3000 Joules to guard against electrical spikes.
For enhanced performance, it includes EMI/RFI filtering to reduce electrical noise and interference, ensuring clean and stable power. The unit is designed for flexible mounting options, including rack-mountable, wall-mountable, or free-standing configurations, and comes with a heavy-duty power cord typically ranging from 1.5 to 3 meters.
Constructed from durable, flame-retardant plastic or metal, the PDU is built to withstand demanding environments. Safety features include overload protection, which either shuts off the unit automatically or includes a circuit breaker to prevent overloading. LED indicator lights provide clear visual feedback on power status and surge protection, making it an essential tool for managing and safeguarding critical electronic equipment in data centers, server rooms, or office environments.
Frequency Compatibility | 50 / 60 Hz |
Output Capacity Details | 3.84kW (240V), 3.68kW (230V), 3.52kW (220V), 3.33kW (208V), 3.2kW (200V), 2.03kW (127V), 1.92kW (120V), 1.6kW (100V) / 16A total capacity; 16A max per C19 outlet; 12A (10A CE) max per C13 outlet |
Output Receptacles | (12) C13; (2) C19 |
Output Nominal Voltage | 100; 120; 127; 200; 208; 220; 230; 240 |
Overload Protection | 16A circuit breaker |
INPUT
PDU Input Voltage | 100; 120; 127; 200; 208; 220; 230; 240 |
Recommended Electrical Service | 20A 120V; 20A 208/240V; 16A 230V |
Maximum Input Amps | 16 |
PDU Plug Type | IEC-320 C20 |
Input Phase | Single-Phase |
Input Cord Details | C20 inlet accepts user supplied input cable with C19 output connection |
USER INTERFACE, ALERTS & CONTROLS
Switches | No power switch |
PHYSICAL
Minimum Required Rack Depth (cm) | 19.81 |
Shipping Dimensions (hwd / cm) | 5.33 x 52.32 x 23.62 |
Shipping Weight (kg) | 1.68 |
Unit Dimensions (hwd / cm) | 4,4 x 44,5 x 10,8 |
Unit Weight (kg) | 1.45 |
Material of Construction | Metal |
Form Factors Supported | 1U rackmount, 0U vertical rackmount, wall-mount and undercounter installation supported |
PDU Form Factor | Horizontal (1U) |
Outlets Measurement (Center to Center) | Distance between Front (C13) outlets = 28.75mm; Distance between Rear (C19) outlets = 55mm; Distance between Rear (C13) outelts = 28.75mm |
ENVIRONMENTAL
Storage Temperature Range | 5 to 122F (-15 to 50C) |
Relative Humidity | 5-95% non-condensing |
Operating Elevation (ft.) | 0-10,000 |
Operating Elevation (m) | 0-3000 |
SPECIAL FEATURES
TVSS Grounding | Back panel grounding lug |
