Fanvil A201 Ceiling Speaker

Fanvil A201 Ceiling Speaker

The Fanvil A201 is a commercial-grade IP audio terminal designed for ceiling-mounted installation in enterprise, education, healthcare, and public infrastructure environments. It operates as a standalone audio endpoint or as part of a larger unified communication, broadcast, or security system. The A201 supports 2 SIP lines, HD voice encoding, lossless audio broadcast, scheduled task broadcasting, and two-way intercom — consolidating multiple audio functions into a single networked device.

Helpful Data:

Fanvil A201 firmware and documentation

Audio Output and Speaker Performance

The A201 uses an 8 Ω speaker rated at 10 W output power under PoE+ or DC supply. The speaker frequency response runs from 250 Hz to 20 kHz, with a sensitivity of 90 ± 3 dB measured at 1 m / 1 W. Maximum SPL reaches 100 dB, suitable for medium to large rooms, corridors, and open-plan spaces where consistent audio coverage is required.

Speaker power output varies by power source:

• PoE (802.3af): 6 W
• PoE+ (802.3at) or DC 12V–24V/2A: 10 W

For installations where full 10 W output is required, PoE+ or DC power is the correct choice. Standard PoE delivers 6 W, which is adequate for smaller spaces but represents a meaningful reduction in SPL headroom.

Microphone and Intercom

The A201 includes a built-in omnidirectional microphone with a sensitivity of −38 ± 3 dB, an impedance of 2.2 kΩ, and a bias voltage of 2 V. This enables two-way intercom, self-test, and monitoring functions without requiring an external microphone unit. The microphone supports HD voice through G.722 and Opus encoding, maintaining wideband call quality in both intercom and paging directions.

Broadcast and Audio Capabilities

The A201 supports multiple broadcast modes suited to different operational requirements:

• HD intercom: G.722 and Opus encoding for wideband two-way voice
• Lossless music broadcast: MP3 and WAV file playback
• Scheduled task broadcast: automated audio playback via internal scheduling
• Emergency notification and alarm audio: customisable audio files assignable to alarm triggers

Built-in storage of 24 MB holds locally loaded audio files for scheduled and emergency playback. This means the A201 can operate scheduled broadcasts independently without a continuous server connection, which is relevant in network-unreliable environments or during infrastructure failures.

The A201 furthermore supports 20 multicast partitions, allowing zone-based audio distribution across a site. Each partition can receive independent audio streams, enabling differentiated announcements across floors, departments, or building zones from a single management interface.

Integration and Linkage

A key feature of the A201 is its ability to integrate with external systems beyond standard SIP telephony. Supported integration modes include:

• Unified communication systems — via SIP 2.0 over UDP/TCP/TLS
• Video surveillance systems — via external IP camera video linkage
• Access control systems — via short-circuit input and output ports
• Fire alarm systems — via short-circuit I/O and customisable emergency audio
• Digital billboards and signage — via HTTP API and Action URL/Active URI
• Fanvil broadcast and intercom system — native integration with Fanvil’s FDMCS platform and broadcast intercom APP

The short-circuit input port detects external trigger signals, while the short-circuit output port (rated at 30 V / 2 A) activates connected security or alarm devices in response. This bidirectional I/O makes the A201 a practical node in integrated building management and emergency response systems.

Deployment Modes

The A201 operates across four distinct deployment modes, giving installers flexibility to match the device to the existing infrastructure:

• Serverless mode — direct peer-to-peer operation without a SIP proxy
• Converged communication mode — integration with a SIP PBX or UC platform
• Fanvil broadcast intercom system mode — managed via Fanvil FDMCS or broadcast intercom APP
• External linkage mode — triggered and controlled by third-party systems via HTTP API or short-circuit I/O

Network and Management

The A201 connects via a single RJ45 port operating at 10/100 Mbps. It supports IPv4, IPv6, and dual-stack IPv4+IPv6 addressing. IP assignment options include static IP, DHCP, and PPPoE. Network security and segmentation features include VLAN, QoS, LLDP, L2TP, and OpenVPN.

Remote management is available via a web portal, Fanvil DM software, FDMCS, and the Fanvil broadcast intercom mobile app. Auto-provisioning is supported across FTP, TFTP, HTTP, HTTPS, DHCP Option 66, SIP PnP, and TR-069, covering the full range of enterprise zero-touch deployment workflows. Additional management tools include web-based packet capture, configuration export/import, firmware upgrade, and syslog.

Who the Fanvil A201 Suits

• Enterprise and corporate office deployments — The 20 multicast partitions and SIP 2.0 integration enable zone-based paging across floors and departments. Web management and TR-069 auto-provisioning reduce on-site IT overhead for multi-device rollouts.
• Education campuses and schools — Scheduled task broadcast and 24 MB internal audio storage support automated bell schedules, announcements, and emergency alerts without continuous server dependency. Two-way intercom enables staff communication across buildings.
• Healthcare facilities — The emergency notification audio function and short-circuit I/O linkage with alarm systems address nurse call, fire, and security alert scenarios. The built-in microphone supports monitoring applications in patient areas.
• Retail and hospitality environments — Lossless MP3 and WAV broadcast with remote volume adjustment via web interface allows background music and zone-based announcements to be managed centrally. The ceiling-mount form factor integrates cleanly into finished interior spaces.
• Security and access control integrators — The short-circuit input and output ports, IP camera video linkage, and HTTP API allow the A201 to function as an active node in physical security systems. Triggered audio responses to access events, alarms, or camera detections are configurable without additional hardware.

Fanvil A201 Ceiling Speaker Technical Specifications

Audio — Speaker

Audio — Microphone

Audio Features

Connectivity

Protocols

Network Features

Deployment and Management

Physical Specifications

Packaging

Conclusion

The Fanvil A201 consolidates paging broadcast, scheduled audio, emergency notification, two-way intercom, and third-party system integration into a single ceiling-mounted IP terminal. Its combination of SIP 2.0 support, short-circuit I/O, IP camera linkage, and 20 multicast partitions makes it a practical choice for enterprise, education, healthcare, and security-integrated deployments. PoE+ or DC power supply is recommended where full 10 W speaker output is required. For sites already running Fanvil telephony infrastructure, the A201 extends the same management environment to the audio broadcast layer without introducing a separate platform.
