Fanvil A308i Video Console Phone:
The Fanvil A308i is an Android 9.0 video console IP phone that combines audio and video communication in a single desk unit. It supports 20 SIP lines, 10-party audio conferencing, and 3-party video conferencing. The A308i runs on Android 9.0, allowing third-party application installation alongside native phone functions. A 5-megapixel adjustable camera, gooseneck microphone, and 7-inch touch screen make it suited to reception desks, executive offices, and shared conference room deployments.
Related Documents:
Fanvil A308i firmware and user manual documents
Who the Fanvil A308i Suits
- Reception and front-desk operators — The 7-inch touch screen, 116 programmable DSS keys, and 20 SIP lines allow a single operator to monitor and manage a large number of extensions simultaneously. BLF keys give real-time visibility of colleague availability without a separate console device.
- Executive and managerial offices — The 5MP adjustable camera and 3-party video conferencing support face-to-face communication from the desk. Android 9.0 allows calendar, email, and productivity apps to run alongside the phone, consolidating devices on the desk.
- Small conference and huddle rooms — 10-party audio conferencing and the gooseneck microphone make the A308i functional as a standalone conference phone. The 90 dB maximum volume and full-duplex AEC maintain call clarity in rooms where multiple participants are present.
- Enterprises deploying Fanvil broadcast and intercom systems — The A308i includes built-in Fanvil broadcast and intercom system support, allowing it to participate in site-wide paging, zone broadcast, and intercom workflows without additional licensing or hardware.
- IT and telecoms administrators managing large SIP deployments — TR-069, AES-encrypted provisioning, and 802.1x access control address enterprise security and zero-touch deployment requirements. Dual Gigabit ports reduce switch port consumption in dense desk environments.
Fanvil A308i Technical Specifications
Display and Keys
| Parameter | Value |
|---|---|
| Screen | 7-inch colour touch screen |
| Resolution | 1024 × 600 |
| DSS keys | 116 (programmable) |
| Physical keys | 5 (Volume −/+, Home, Hands-free, Return) |
Camera
| Parameter | Value |
|---|---|
| Resolution | 5 megapixel |
| Angle | Adjustable |
| Video codecs | H.264 (standard), H.265 (optional) |
| Video resolution | CIF / VGA / 4CIF / 720P / 1080P |
| Frame rate | 5 – 30 fps |
| Bandwidth | 64 kbps – 4 Mbps |
| Image formats | JPEG / PNG / BMP |
| Video format | MP4 |
Audio
| Parameter | Value |
|---|---|
| Microphone | Gooseneck |
| Speaker frequency response | 0 – 7 kHz |
| Wideband sampling | 16 kHz ADC/DAC |
| Maximum volume | 90 dB |
| Narrowband codecs | G.711a/u, G.729AB, iLBC |
| Wideband codecs | G.722, Opus |
| Echo cancellation | Full-duplex AEC |
| Noise reduction | Yes (NR) |
| Packet loss concealment | Yes (PLC) |
| Jitter buffer | Dynamic adaptive |
| DTMF | In-band, out-of-band (RFC2833 / SIP INFO) |
| HAC handset | Yes |
Call and Phone Features
| Feature | Detail |
|---|---|
| SIP lines | 20 |
| Audio conference | 10-party |
| Video conference | 3-party |
| Local phonebook | 2,000 entries |
| Remote phonebook | XML / LDAP, 2,000 entries |
| Call logs | 1,000 entries (in/out/missed) |
| Modes | Handset / Hands-free / Headset |
| Call features | Hold, Transfer, Waiting, Forwarding, Parking, Pick-up, BLF, DND, Auto-answer, Speed Dial, Redial, Intercom, Hot Line, Hot Desking |
Network
| Parameter | Value |
|---|---|
| Ethernet | Dual Gigabit (10/100/1000 Mbps) |
| PC bypass port | Yes (bridged) |
| IP mode | IPv4 |
| IP assignment | Static / DHCP |
| Wi-Fi | 2.4 GHz / 5 GHz dual band |
| PoE | Yes (802.3af/at) |
| Network access control | 802.1x |
| VPN | OpenVPN (via third-party app) |
| VLAN / LLDP / CDP / QoS | Yes |
Protocols
| Protocol |
|---|
| SIP 2.0 (UDP / TCP / TLS) |
| RTP / RTCP / SRTP |
| STUN |
| DHCP |
| LLDP / CDP |
| 802.1x |
| OpenVPN |
| SNTP |
| FTP / TFTP |
| HTTP / HTTPS |
| TR-069 |
Operating System and Applications
| Parameter | Value |
|---|---|
| OS | Android 9.0 |
| Third-party apps | Supported |
| Secondary development | API available |
| Built-in apps | Files, Calendar, Gallery, Browser, Email, Calculator, Notepad, Sound Recorder, Clock, Video, Music |
Ports and Interfaces
| Interface | Detail |
|---|---|
| RJ45 | × 2 (Network × 1, PC bypass × 1) |
| RJ9 | × 2 (Handset, Headset) |
| USB 2.0 Type-A | × 1 |
| Safety keyhole | × 1 |
Power
| Parameter | Value |
|---|---|
| Power input | 12V / 1A or PoE |
| Power consumption — PoE | 3.52 – 10.76 W |
| Power consumption — adapter | 2.38 – 8.6 W |
Physical Specifications
| Parameter | Value |
|---|---|
| Colour | Grey |
| Dimensions (45° stand) | 265 × 172.1 × 145.2 mm |
| Dimensions (50° stand) | 265 × 161.7 × 154.5 mm |
| Working temperature | 0 °C to +45 °C |
| Working humidity | 10% – 95% RH |
| Installation | Desktop, wall-mounted |
Packaging
| Parameter | Value |
|---|---|
| Gift box dimensions | 337 × 218 × 81 mm |
| Carton dimensions | 456 × 430 × 357 mm |
| Qty per carton | 10 PCS |
Package Contents
- Fanvil A308i Video Console IP Phone × 1
- HD Handset (RJ9) × 1
- Standard RJ9 Handset Wire × 1
- 1.5 m CAT5 Ethernet Cable × 1
- Installation bracket × 1
Conclusion
The Fanvil A308i brings together video calling, multi-line SIP management, Android application support, and large-scale DSS key programming in a single console unit. Its 116 programmable DSS keys, 20 SIP lines, and 7-inch touch screen address the demands of reception and operator positions, while the 5MP camera and 3-party video conferencing extend its utility to executive desks and small meeting rooms. Dual Gigabit ports with PoE and dual-band Wi-Fi give installers flexible connectivity options across wired and wireless environments. For organisations already running Fanvil infrastructure, the A308i integrates directly into the broadcast, intercom, and provisioning ecosystem without additional configuration overhead.
