General Information

• Model: Hikvision DS-1H34-0101P
• Type: PoE Extender (Power over Ethernet Extender)
• Purpose: Extends the reach of PoE-powered devices beyond the typical 100-meter Ethernet limitation
• Application: Ideal for extending network connections and powering devices like IP cameras, access control systems, or other PoE-enabled devices

Electrical and Power

• Power Supply: Powered by PoE (IEEE 802.3af/at)
• Power Consumption:
  • Max. 4W (without external load)
• PoE Input:
  • IEEE 802.3af (PoE) / IEEE 802.3at (PoE+) compliant
• PoE Output:
  • 1 × PoE output port (up to 30W output power)

Ports and Connectivity

• Input Port:
  • 1 × 10/100/1000 Mbps Ethernet port (RJ-45) for receiving PoE input
• Output Port:
  • 1 × 10/100/1000 Mbps Ethernet port (RJ-45) for providing extended PoE output
• Transmission Distance:
  • Extends PoE power and data transmission up to an additional 100 meters, allowing a total distance of up to 200 meters from the original PoE power source
• Auto-Negotiation: Supports automatic speed and duplex configuration (10/100/1000 Mbps)

Performance and Features

• PoE Extension:
  • Extends PoE to remote devices, providing both power and data for up to 200 meters
  • Ideal for connecting devices in hard-to-reach areas or locations far from the main PoE source
• Data Rate:
  • Supports 10/100/1000 Mbps Ethernet data rates for high-speed communication
• PoE Standards:
  • Complies with IEEE 802.3af (PoE) and IEEE 802.3at (PoE+) for power delivery
• Plug-and-Play: Easy installation with no configuration required

Environmental and Durability

• Operating Temperature:
  • -10°C to 50°C (14°F to 122°F)
• Operating Humidity:
  • 10% to 90% (non-condensing)
• Enclosure:
  • Plastic casing designed for indoor use (IP20 rated)

Physical Dimensions and Weight

• Dimensions: 90 mm × 55 mm × 25 mm (3.54″ × 2.17″ × 0.98″)
• Weight: Approx. 0.1 kg (0.22 lbs)

Applications

• Use Cases:
  • Extending the reach of PoE-powered devices like IP cameras, access control systems, and network switches
  • Ideal for large surveillance systems, commercial offices, or installations in remote locations
• Installation Locations:
  • Can be used in buildings, parking lots, warehouses, and outdoor locations when used with proper enclosures
