General Features:

• Model: DS-2CE72DFT-F
• Product Type: 2 MP Full Time Color Turret Camera
• Camera Type: Fixed lens, turret-style

Image and Video:

• Image Sensor: 1/2.8″ Progressive Scan CMOS
• Resolution: 2 MP (1920 × 1080)
• Min. Illumination:
  • Color: 0.001 Lux @(F1.0, AGC ON)
• Shutter Speed: 1/25 s to 1/100,000 s
• Lens:
  • Fixed lens: 2.8 mm
  • Horizontal Field of View: 102°

Color Technology:

• Full Time Color: Designed to provide full-color images even in low-light conditions

Video Output:

• Video Output: 1 HD analog output (HD-TVI/CVBS)

Image Enhancement:

• Wide Dynamic Range (WDR): Digital WDR
• Backlight Compensation (BLC): Yes
• White Balance: Auto
• Digital Noise Reduction (DNR): 3D DNR
• Defog: Yes

Infrared and Night Vision:

• Infrared (IR) LEDs: None
• IR Range: N/A (Full Time Color)

Power Supply:

• Power Supply:
  • 12 VDC ± 15%
• Power Consumption: Max. 4.5 W

Environmental Specifications:

• Operating Temperature:
  • -40 °C to +60 °C (-40 °F to 140 °F)
• Operating Humidity:
  • 90% or less (non-condensing)
• Weather Resistance: IP67-rated weatherproof housing

Physical Characteristics:

• Dimensions:
  • 97.5 mm × 94.1 mm (3.84″ × 3.70″)
• Weight:
  • Approximately 300 g (0.66 lbs)

Additional Features:

• Mounting: Wall or ceiling mount
• Housing Material: Metal
• Design: Compact turret design for discreet installation
• Full Time Color: Ensures continuous color imaging without relying on IR illumination
