Hikvision DS-3E0318P-E/M 16 Port Unmanaged PoE Switch

General Information

• Product Type: Unmanaged PoE Switch
• Model: DS-3E0318P-E/M
• Ports:
  • 16 × 10/100 Mbps PoE Ports
  • 2 × 10/100 Mbps Uplink Ports (RJ45)

PoE Specifications

• PoE Standard:
  • IEEE 802.3af (PoE)
  • IEEE 802.3at (PoE+)
• Total PoE Power Budget:
  • 250W
• Max PoE Output per Port:
  • 30W (for PoE+)

Performance

• Switching Capacity:
  • 3.6 Gbps
• Forwarding Rate:
  • 1.34 Mpps (Million packets per second)
• MAC Address Table:
  • 8K entries

Network Features

• Layer:
  • Layer 2
• VLAN:
  • Port-based VLAN
• QoS:
  • Supports QoS (Quality of Service) for traffic prioritization
• Auto-Negotiation:
  • Yes

Physical Specifications

• Dimensions:
  • Approximately 260 × 155 × 44 mm (10.2 × 6.1 × 1.7 inches)
• Weight:
  • Approximately 1.5 kg (3.3 lbs)
• Housing:
  • Metal

Power

• Power Supply:
  • AC 100-240V, 50/60Hz
• Power Consumption:
  • Typically 300W (including PoE)

Environmental

• Operating Temperature:
  • 0°C to 40°C (32°F to 104°F)
• Operating Humidity:
  • 10% to 90% (non-condensing)
• Storage Temperature:
  • -40°C to 70°C (-40°F to 158°F)

Features

• PoE Management:
  • Automatic detection of PoE devices
  • Overload and short-circuit protection
• LED Indicators:
  • Power, Link/Activity, PoE status for each port
• Fanless Design:
  • No moving parts for silent operation
• Mounting Options:
  • Rack-mountable or desktop

Accessories

• Included Items:
  • Power cord
  • Rack ears
  • Mounting screws
  • User manual

Applications

• Use Cases:
  • Small to medium-sized IP camera networks
  • Office and retail environments
  • VoIP and networked devices

Price Range

• Price Range:
  • $150 to $250 USD depending on supplier and quantity
• Best Price:
  • Prices can vary; check online retailers or local distributors for current pricing
