Yealink Enterprise HD IP Phone SIP-T27P Mtech

Yealink Enterprise HD IP Phone SIP-T27P is a highly featured phone designed to deliver advanced sound quality and uses standard encryption protocols.

Yealink SIP-T27P Enterprise HD IP Phone  offers a rich user experience and a wide range of functionality that  include  BLF, SCA, 3-way conference and paperless labels.

SIP-T27P is a feature-rich sip phone for business. It has been designed by pursuing ease of use in even the tiniest details. Yealink SIP-T27P Enterprise HD IP Phone Delivering a superb sound quality as well as rich visual experience.

The T27P also offers a wide range of functions, like SCA, BLF List, call forward, Yealink SIP-T27P Enterprise HD IP Phone call transfer, 3-way conference,and up to support various features.Using standard encryption protocols to perform highly secure remote provisioning and software upgrades.

Yealink T27P comes equipped with numerous features and is designed for superb audio quality for any type of office setting. The T27P offers phone features such as; 3-way calling,

Yealink SIP-T27P Enterprise HD IP PhoneBusy Lamp Field (BLF) keys and an XML browser right on the phone. Use this phone in conjunction with the Yealink Expansion Module Yealink SIP-T27P is a VoIP phone that supports up to 6 SIP accounts, 3.6″ backlit display and Yealink Optima HD Voice.

The T27P supports PoE and is easy to configure. T27P, is Yealink’s latest feature-rich tool unifying superior voice capabilities and increased function extension capability for business.

Yealink Optima HD technology and wideband codec of Opus deliver a superb sound quality and bring you a life-like voice communications.

Yealink SIP-T27P Enterprise HD IP Phone specifications

Audio Features

> HD voice: HD handset, HD speaker

> Wideband codec: G.722

> Narrowband codec: G.711(A/?), G.729AB, G.726, iLBC > DTMF: In-band, Out-of-band(RFC 2833) and SIP INFO

> Full-duplex hands-free speakerphone with AEC > VAD, CNG, AEC, PLC, AJB, AGC

Phone Features

> 6 VoIP accounts

> One-touch speed dial, redial

> Call forward, call waiting

> Call transfer, call hold

> Call return, group listening

> Mute, auto answer, DND

> 3-way conference call

> Direct IP call without SIP proxy

> Ring tone selection/import/delete

> Hotline, emergency call

> Set date time manually or automatically

> Dial plan > XML Browser,

> Action URL/URI

> Integrated Screenshots > RTCP-XR

Directory

> Local phonebook up to 1000 entries

> Black list

> XML/LDAP remote phonebook

> Intelligent search method

> Phonebook search/import/export

> Call history: dialed/received/missed/forwarded

IP-PBX Features > Busy Lamp Field (BLF)

> Bridged Line Apperance(BLA)

> Anonymous call, anonymous call rejection

> Hot-desking

> Message Waiting Indicator (MWI)

> Voice mail

> Call park, call pickup

> Intercom, paging,

> Music on hold > Call recording

Display and Indicator > 3.66″ 240×120-pixel graphical LCD with backlight

> LED for call and message waiting indication > Dual-color (red or green) illuminated LEDs for line status information

> Intuitive user interface with icons and soft keys

> National language selection > Caller ID with name, number

Feature keys > 8 line keys with LED

> 8 line keys can be programmed up to 21 various features (3-page view)

> 8 features keys: message, headset, conference, mute, hold, transfer, redial, hands-free speakerphone

> 4 context-sensitive soft keys

> 6 navigation keys

> 2 volume control keys

> Illuminated message key

> Illuminated headset key

Interface

> 1xRJ9 (4P4C) handset port

> 1xRJ9 (4P4C) headset port

> 1XRJ12 (6P6C) EHS port

> Power over Ethernet (IEEE 802.3af), Class 2

Other Physical Features

> Stand with 2 adjustable angles

> Wall mountable (optional)

> External universal AC adapter (optional)? AC 100~240V input and DC 5V/1.2A output

> Power consumption (PSU): 1.173.32W

> Power consumption (PoE): 1.60?5.94W

> Dimension(W*D*H*T): 265mm x 210mm x 170.5mm x 53.5mm

> Operating humidity: 10-95% > Operating temperature: -10~50°C

Package Features

> Qty/CTN: 5 PCS > N.W/CTN: > G.W/CTN:

> Giftbox size: 300mm x 225mm x 118mm

> Carton Meas: 610mm x 310mm x 238mm

Management

> Configuration: browser/phone/auto-provision

> Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy

> Auto-provision with PnP > Zero-sp-touch TR-069

> Reset to factory, reboot

> Package tracing export, system log

Network and Security

> SIP v1 (RFC2543), v2 (RFC3261)

> NAT transverse: STUN mode

> Proxy mode and peer-to-peer SIP link mode

> IP assignment: static/DHCP

> HTTP/HTTPS web server

> Time and date synchronization using SNTP

> UDP/TCP/DNS-SRV(RFC 3263)

> QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP

> SRTP for voice > Transport Layer Security (TLS)

> HTTPS certificate manager

> AES encryption for configuration file

> Digest authentication using MD5/MD5-sess

> OpenVPN, IEEE802.1X > IPv6
