General Features:

• Model: ZKTeco MB160
• Type: Multi-biometric Time Attendance Terminal with Access Control
• Authentication Methods:
  • Fingerprint recognition
  • Facial recognition
  • PIN (Password) authentication
  • RFID card (optional, depending on model)
• Display: 4.3-inch color touchscreen
• Verification Speed: ≤ 1 second for fingerprint recognition
• Matching Speed: < 1 second for facial recognition
• User Capacity:
  • Fingerprint capacity: Up to 3,000 fingerprints
  • Face template capacity: Up to 3,000 faces
  • Transaction logs: Up to 100,000 logs
• Fingerprint Sensor: Optical sensor for fast and reliable biometric capture
• Facial Recognition Technology: Advanced facial recognition for access control and attendance management
• Liveness Detection: Prevents spoofing attempts by ensuring only live fingerprints or faces are recognized

Access Control Features:

• Relay Output: For controlling electric locks, door strikes, or other access control devices
• Wiegand Output: Supports integration with third-party access control devices
• Alarm Integration: Supports alarm functionality for unauthorized access or emergency situations
• Anti-Tailgating: Prevents multiple people from entering a restricted area by following an authorized user
• Anti-Passback: Ensures that users cannot re-enter without the proper clearance or authorization
• Door Open Time: Configurable door open duration for better security management
• Multiple Authentication Modes: Allows users to configure combinations of fingerprint, face, and PIN for enhanced security

Power & Connectivity:

• Power Supply:
  • DC 12V or PoE (Power over Ethernet)
  • Low power consumption
• Communication Protocols:
  • TCP/IP (Ethernet) for network connectivity
  • USB port for data backup and software configuration
  • Wiegand interface for integration with third-party systems
• Communication Ports:
  • RS485, Wiegand output for additional peripheral device integration
• Backup Power: Option for UPS (Uninterruptible Power Supply) to maintain system operation during power outages

Environmental Specifications:

• Operating Temperature: -20°C to 45°C (-4°F to 113°F)
• Operating Humidity: 20% to 80% (non-condensing)
• Indoor Use: Designed primarily for indoor installations
• IP Rating: Not specifically rated for outdoor use, so should be installed in protected indoor locations

Software & Integration:

• Software Compatibility:
  • ZKTeco’s Time Attendance Software for reporting, real-time monitoring, and payroll integration
  • ZKTeco Access Control Software for comprehensive management of access rights and logs
• API/SDK Support:
  • Allows integration with third-party software and systems (e.g., HR, payroll systems, building management)
• Real-Time Monitoring: Provides real-time access logs and monitoring for security personnel
• Data Export: Can export logs and reports in CSV, Excel, and PDF formats for easy auditing
• Multi-Device Management: Manage multiple MB160 devices from a centralized system
• Mobile App Integration: Some models support integration with mobile apps for remote monitoring
