Fiber

• Product Type: Air Blown Duct Micro Fiber Optic Cable
• Core Count: 48 cores
• Fiber Type: Single-mode
• Cable Design: Micro cable design for enhanced flexibility and minimal bending radius
• Outer Diameter: Typically around 6-8 mm (exact dimension may vary by manufacturer)
• Material: Low smoke zero halogen (LSZH) or PVC jacket (depending on the version)
• Installation Method: Air-blown installation compatible with duct systems
• Weight: Lightweight for easy handling and installation
• Max Tensile Strength: Typically 600 N (may vary by manufacturer)
• Bending Radius: Minimum bending radius is usually 20 times the outer diameter
• Temperature Range: Operating temperature typically between -40°C to +70°C
• Connector Type: Various connector options available (e.g., SC, LC, ST)
• Wavelengths: Standard wavelengths for single-mode fibers (1310 nm, 1550 nm)
• Transmission Distance: Capable of long-distance transmission (up to 40 km or more depending on the network setup)
• Application: Suitable for data centers, telecommunications networks, and outdoor installations
• Compliance: Meets international standards (e.g., IEC, TIA/EIA) for fiber optic cables
•

General Specifications:

• Product Type: Underground Armoured Singlemode Fibre Optic Cable
• Fiber Count: 48 cores
• Fiber Type: Single-mode (G.652D, G.657A1, or equivalent)

Optical Performance:

• Attenuation:
  • 1310 nm: ≤ 0.36 dB/km
  • 1550 nm: ≤ 0.22 dB/km
• Chromatic Dispersion:
  • 1285–1330 nm: ≤ 3.5 ps/nm·km
  • 1550 nm: ≤ 18 ps/nm·km
• Polarization Mode Dispersion (PMD): ≤ 0.2 ps/√km

Physical Specifications:

• Cable Structure: Loose tube design
• Armour Type: Corrugated steel tape or steel wire armor
• Outer Jacket Material: Polyethylene (PE) or Low Smoke Zero Halogen (LSZH)
• Cable Diameter: Typically ranges from 10 mm to 15 mm, depending on design
• Weight: Typically between 100 kg/km to 200 kg/km, depending on armor and jacket

Mechanical Specifications:

• Tensile Strength: Typically 1500 N to 3000 N
• Crush Resistance: ≥ 1000 N/100 mm
• Minimum Bending Radius:
  • Static: 10 x cable diameter
  • Dynamic: 20 x cable diameter
• Impact Resistance: Typically designed to withstand up to 10 impacts at a height of 1 meter

Environmental Specifications:

• Temperature Range:
  • Operating: -40°C to +70°C
  • Installation: -30°C to +60°C
  • Storage: -40°C to +70°C
• Water Blocking: Water-blocking gel or water-swellable tape to prevent moisture ingress
• UV Resistance: UV-resistant outer jacket for protection against sunlight in exposed environments

Standards and Compliance:

• Standards Compliance:
  • ITU-T G.652D, G.657A1 (fiber type)
  • IEC 60793-1, IEC 60794-1 (cable design)
  • RoHS compliant
• Fire Resistance: LSZH jacket complies with IEC 60332-1 standards (if applicable)

Additional Features:

• Buffer Tubes: Typically filled with water-blocking gel and color-coded for easy identification
• Strength Members: Central strength member (usually FRP or steel wire) for additional mechanical support
• Ripcord: Incorporated for easy stripping of the outer jacket during installation

• Core Configuration: 24 singlemode fibers
• Core Diameter: 9 µm
• Cladding Diameter: 125 µm
• Outer Diameter: Typically around 10.5 mm to 12 mm
• Armouring: Steel wire or aluminum armoured for enhanced protection
• Material: Low Smoke Zero Halogen (LSZH) or PVC outer sheath
• Maximum Attenuation:
  • ≤ 0.35 dB/km at 1310 nm
  • ≤ 0.20 dB/km at 1550 nm
• Operating Temperature Range: -40°C to +70°C
• Storage Temperature Range: -40°C to +85°C
• Tensile Strength: ≥ 1500 N
• Crush Resistance: ≥ 1500 N/100 mm
• Water Resistance: IP68 rated for submerged conditions
• Installation Method: Suitable for direct burial in underground applications
• Reinforcement: Additional moisture barriers for enhanced durability
• Applications: Telecommunications, data center interconnections, LAN/WAN backbones, FTTH deployments
• Weight: Approximately 100-120 kg/km (depending on armouring and sheath material)

• Product Type: 48 Core Singlemode Un-Armoured Fibre Optic Cable
• Core Count: 48 fibers
• Fiber Type: Singlemode
• Cable Construction:
  • Loose tube design for enhanced protection and flexibility
  • Un-armoured, lightweight, and suitable for indoor applications
• Outer Diameter: Typically ranges from 8-14 mm (exact dimensions may vary by manufacturer)
• Material:
  • Outer jacket made from low smoke zero halogen (LSZH) or polyethylene (PE)
  • Loose tubes constructed from durable plastic for fiber protection
• Operating Temperature Range: -40°C to +70°C
• Bending Radius: Minimum bending radius usually 10 times the outer diameter
• Wavelengths: Optimized for transmission at 1310 nm and 1550 nm
• Transmission Distance: Suitable for long-distance signal transmission with low attenuation
• Connector Type: Compatible with various connector types (e.g., SC, LC, ST)
• Moisture Resistance: Designed primarily for indoor applications; may offer some moisture resistance
• Compliance: Meets international standards (e.g., IEC, TIA/EIA) for singlemode fiber cables
• Application: Ideal for high-capacity telecommunication networks, data centers, and enterprise LAN applications

• Product Type: 24 Core Singlemode Un-Armoured Fibre Optic Cable
• Core Count: 24 fibers
• Fiber Type: Singlemode
• Cable Construction:
  • Loose tube design to accommodate expansion and contraction
  • No armouring, suitable for indoor and some outdoor applications
• Outer Diameter: Typically ranges from 8-12 mm (exact dimensions may vary by manufacturer)
• Material:
  • Outer jacket made from low smoke zero halogen (LSZH) or polyethylene (PE)
  • Loose tubes made from plastic materials for fiber protection
• Operating Temperature Range: -40°C to +70°C
• Bending Radius: Minimum bending radius usually 10 times the outer diameter
• Wavelength: Optimized for wavelengths of 1310 nm and 1550 nm
• Transmission Distance: Suitable for long-distance transmission with low attenuation
• Connector Type: Various options available (e.g., SC, LC, ST)
• Moisture Resistance: Designed for indoor use; may have some moisture resistance
• Compliance: Meets international standards (e.g., IEC, TIA/EIA) for singlemode fiber cables

• Product Type: 2 Core SingleMode Outdoor FTTH Drop Cable
• Core Count: 2 fibers
• Fiber Type: Singlemode
• Cable Length: 1 kilometer (1000 meters)
• Construction:
  • Loose tube or tight-buffered design
  • UV-resistant outer jacket for outdoor applications
• Outer Diameter: Typically ranges from 3-5 mm (exact dimensions may vary by manufacturer)
• Material:
  • Outer jacket made from low smoke zero halogen (LSZH) or polyethylene (PE)
  • Reinforced with aramid yarn for additional strength and protection
• Operating Temperature Range: -40°C to +70°C
• Bending Radius: Minimum bending radius usually 10 times the outer diameter
• Wavelength: Optimized for wavelengths of 1310 nm and 1550 nm
• Transmission Distance: Capable of long-distance transmission with low attenuation
• Connector Type: Various options available (e.g., SC, LC)
• Moisture Resistance: Designed for outdoor use with moisture-proof features
• Compliance: Meets international standards (e.g., IEC, TIA/EIA) for singlemode fiber cables
• Application: Ideal for Fiber-to-the-Home (FTTH) installations, telecommunications, and data networks

• Product Type: OM4 Multimode Fibre Optic Cable
• Core Count: 8 cores
• Fiber Type: Multimode
• Cable Design: Loose tube or tight-buffered, depending on manufacturer
• Outer Diameter: Typically ranges from 8-12 mm (exact dimensions may vary by manufacturer)
• Material: Low smoke zero halogen (LSZH) or PVC outer jacket
• Max Tensile Strength: Typically up to 1000 N (may vary by manufacturer)
• Bending Radius: Minimum bending radius usually 10 times the outer diameter
• Operating Temperature Range: -20°C to +70°C
• Wavelengths: Optimized for wavelengths of 850 nm and 1300 nm
• Transmission Distance:
  • Up to 150 m at 850 nm
  • Up to 400 m at 1300 nm
• Connector Type: Various connector options available (e.g., LC, SC, ST)
• Moisture Resistance: Designed for reliable performance in indoor environments
• Compliance: Meets international standards (e.g., IEC, TIA/EIA) for multimode fiber cables
