Hikvision

General Information

• Product Type: HD 720P IR Turret Camera
• Model: DS-2CE56C0T-IRP
• Resolution: 720P HD (1280 × 720)
• Video Format: H.264, H.265 (for compatible DVRs)

Camera

• Image Sensor: 1/4" Progressive Scan CMOS
• Lens: Fixed lens
  • Example: 2.8mm (varies by model)
• Field of View:
  • Typically around 90° (varies with lens type)
• Infrared (IR) Illumination: EXIR LED technology
• IR Range: Up to 20 meters (65 feet)
• Day/Night Mode: Automatic IR cut filter (ICR)
• WDR (Wide Dynamic Range): Basic WDR or Digital WDR
• Noise Reduction: 3D DNR (Digital Noise Reduction)

Video

• Video Output:
  • Analog HD video output (for use with HD-TVI DVRs)
• Video Compression:
  • Not applicable (analog signal)
• Frame Rate:
  • 25-30 fps (frames per second) at 720P

Network & Connectivity

• Network Interface:
  • Not applicable (analog camera)
• Protocols Supported:
  • Not applicable (analog camera)

Features

• Motion Detection:
  • Configurable motion detection areas (varies by DVR)
• Alarm Integration:
  • Support for alarm inputs and outputs (varies by DVR)
• Tamper Detection:
  • Alerts if camera is tampered with (varies by DVR)
• Privacy Masking:
  • Up to 4 configurable privacy zones (varies by DVR)
• ONVIF Compliance:
  • Not applicable (analog camera)

Physical Specifications

• Housing:
  • Weatherproof and vandal-resistant (typically IP66)
• Dimensions:
  • Approximately 95 × 100 mm (3.7 × 3.9 inches)
• Weight:
  • Approximately 0.5 kg (1.1 lbs)

Power

• Power Supply:
  • 12V DC ± 25%
• Power Consumption:
  • Typically 4-6W
• Backup Power:
  • None (direct power required)

Environmental

• Operating Temperature:
  • -40°C to 60°C (-40°F to 140°F)
• Operating Humidity:
  • 10% to 90% (non-condensing)

Accessories

• Included Items:
  • Mounting bracket
  • User manual
• Optional Items:
  • Additional mounting accessories
  • Surge protectors

Applications

• Use Cases:
  • Outdoor surveillance
  • Commercial and residential security
  • Perimeter monitoring

Price Range

• Price Range:
  • $60 to $120 USD depending on supplier and quantity
• Best Price:
  • Prices can vary; check online retailers or local distributors for current pricing

• General Information

  • Product Type: 2 MP IR Dome Camera
  • Model: DS-2CD2722F-IS
  • Resolution: 2 MP (1920 × 1080)
  • Video Format: H.264, H.265

  Camera

  • Image Sensor: 1/2.8" Progressive Scan CMOS
  • Lens: Fixed lens
    • Example: 2.8mm, 4mm (varies by model)
  • Field of View:
    • Typically 90° (with 2.8mm lens), 60° (with 4mm lens)
  • Infrared (IR) Illumination:
    • EXIR LED technology
  • IR Range: Up to 30 meters (98 feet)
  • Day/Night Mode: Automatic IR cut filter (ICR)
  • WDR (Wide Dynamic Range): 120 dB
  • Noise Reduction: 3D DNR (Digital Noise Reduction)

  Video

  • Video Output:
    • Digital IP video stream
  • Video Compression:
    • H.265, H.264
  • Frame Rate:
    • Up to 30 fps at 1080P
  • Bit Rate:
    • Adjustable, with options for constant bit rate or variable bit rate

  Network & Connectivity

  • Network Interface:
    • 1 × Ethernet port (10/100/1000 Mbps)
  • Protocols Supported:
    • TCP/IP, DHCP, DDNS, SMTP, NTP, UPnP, RTP, RTSP
  • Remote Access:
    • Mobile app (Hik-Connect or iVMS-4500)
    • Web browser interface (via Hikvision's software)

  Features

  • Motion Detection:
    • Configurable motion detection areas
  • Alarm Integration:
    • Support for alarm inputs and outputs
  • Tamper Detection:
    • Alerts if camera is tampered with
  • Privacy Masking:
    • Up to 4 configurable privacy zones
  • ROI (Region of Interest):
    • Adjustable to improve image quality in specific areas
  • ONVIF Compliance:
    • For integration with third-party NVRs

  Physical Specifications

  • Housing:
    • Weatherproof and vandal-resistant (typically IP66, IK10)
  • Dimensions:
    • Approximately 130 × 90 mm (5.1 × 3.5 inches)
  • Weight:
    • Approximately 0.6 kg (1.3 lbs)

  Power

  • Power Supply:
    • 12V DC ± 25% or PoE (Power over Ethernet, IEEE 802.3af)
  • Power Consumption:
    • Typically 6-10W
  • Backup Power:
    • None (direct power or PoE required)

  Environmental

  • Operating Temperature:
    • -30°C to 60°C (-22°F to 140°F)
  • Operating Humidity:
    • 10% to 90% (non-condensing)

  Accessories

  • Included Items:
    • Mounting bracket
    • User manual
  • Optional Items:
    • Additional mounting accessories
    • Surge protectors

  Applications

  • Use Cases:
    • Indoor and outdoor surveillance
    • Commercial and residential security
    • Office and public areas monitoring

  Price Range

  • Price Range:
    • $150 to $250 USD depending on supplier and quantity
  • Best Price:
    • Prices can vary; check online retailers or local distributors for current pricing

• General Information

  • Product Type: 1080p HD CCTV IR Camera
  • Model: DS-2AE7230TI-A
  • Resolution: 1080p HD (1920 × 1080)
  • Video Format: Analog HD-TVI, HD-CVI, AHD

  Camera

  • Image Sensor: 1/2.8" Progressive Scan CMOS
  • Lens:
    • Optical Zoom: 30x
    • Focal Length: 4.7mm to 141mm
    • Aperture: f/1.6 to f/3.9
  • Field of View:
    • Horizontal: 56.7° to 2.1°
  • Infrared (IR) Illumination:
    • EXIR LED technology
  • IR Range: Up to 100 meters (328 feet)
  • Day/Night Mode: Automatic IR cut filter (ICR)
  • WDR (Wide Dynamic Range): 120 dB
  • Noise Reduction: 3D DNR (Digital Noise Reduction)

  Video

  • Video Output:
    • Analog HD-TVI, HD-CVI, AHD, CVBS
  • Video Compression:
    • N/A (analog output)
  • Frame Rate:
    • Up to 30 fps at 1080p

  PTZ (Pan-Tilt-Zoom)

  • Pan Range:
    • 0° to 360°
  • Tilt Range:
    • -15° to 90°
  • Pan Speed:
    • 0.1° to 180°/s
  • Tilt Speed:
    • 0.1° to 90°/s
  • Preset Positions:
    • Up to 300 presets
  • Patrol Function:
    • 8 patrols, each with up to 32 preset points

  Network & Connectivity

  • Network Interface:
    • N/A (analog model)
  • Protocols Supported:
    • N/A (analog model)

  Physical Specifications

  • Housing:
    • Weatherproof (IP66)
    • Vandal-resistant (IK10)
  • Dimensions:
    • Approximately 280 × 210 × 140 mm (11.0 × 8.3 × 5.5 inches)
  • Weight:
    • Approximately 3.5 kg (7.7 lbs)

  Power

  • Power Supply:
    • 24V AC ± 25%
  • Power Consumption:
    • Typically 20-30W

  Environmental

  • Operating Temperature:
    • -40°C to 60°C (-40°F to 140°F)
  • Operating Humidity:
    • 10% to 90% (non-condensing)

  Features

  • Motion Detection:
    • Configurable motion detection settings
  • Alarm Integration:
    • N/A (analog model)
  • Tamper Detection:
    • Alerts for tampering (depending on DVR compatibility)
  • Privacy Masking:
    • N/A (analog model)
  • ONVIF Compliance:
    • N/A (analog model)

  Accessories

  • Included Items:
    • Mounting bracket
    • User manual
  • Optional Items:
    • Additional mounting accessories
    • Surge protectors

  Applications

  • Use Cases:
    • Large area surveillance
    • Outdoor and industrial security
    • Public spaces and high-security areas

  Price Range

  • Price Range:
    • $400 to $600 USD depending on supplier and quantity
  • Best Price:
    • Prices can vary; check online retailers or local distributors for current pricing

General Features:

• Model: DS-2AE5123TI-D
• Product Type: PTZ (Pan-Tilt-Zoom) Dome Camera
• Camera Type: Dome-style
• Color: White

Image and Video:

• Image Sensor: 1/3" Progressive Scan CMOS
• Resolution: 2 MP (1920 × 1080)
• Video Frame Rate:
  • 1080p @ 25/30 fps
  • 720p @ 25/30/50/60 fps
• Minimum Illumination:
  • Color: 0.05 Lux @(F1.6, AGC ON)
  • B/W: 0.005 Lux @(F1.6, AGC ON)
• Shutter Speed: 1/1 s to 1/10,000 s
• Signal System: PAL/NTSC

Lens:

• Type: Motorized Zoom Lens
• Focal Length: 4.8 mm to 110 mm
• Aperture: F1.6 to F4.4
• Horizontal Field of View: 59.8° to 3.2°
• Minimum Working Distance: 10 mm to 1500 mm (wide to tele)

Zoom Capabilities:

• Optical Zoom: 23x
• Digital Zoom: 16x

Pan, Tilt, and Rotate:

• Pan Range: 360° endless
• Tilt Range: -15° to 90° (auto flip)
• Pan Speed: 0.1° to 160°/s
• Tilt Speed: 0.1° to 120°/s
• Preset Speed:
  • Pan: 160°/s
  • Tilt: 120°/s
• Number of Presets: 256
• Patrol: 10 patrols, up to 32 presets per patrol
• Pattern: 5 patterns, recording time up to 10 minutes each

Video Compression:

• Compression Standard:
  • H.264
  • MJPEG
• Bit Rate: 32 Kbps to 8 Mbps

Image Enhancement:

• Wide Dynamic Range (WDR): Digital WDR
• Backlight Compensation (BLC): Yes
• Digital Noise Reduction (DNR): 3D DNR
• Image Stabilization: Yes
• Defog: Yes
• White Balance: Auto, ATW, Indoor, Outdoor, Manual
• Day/Night Mode: IR Cut Filter with Auto Switch

Smart Features:

• Smart Detection: Motion detection, Line crossing detection, Intrusion detection
• Privacy Masking: 8 programmable zones

Power Supply:

• Power Supply:
  • 24 VAC
• Power Consumption: Max. 20 W (IR: 7 W)

Environmental Specifications:

• Operating Temperature:
  • -30 °C to +65 °C (-22 °F to 149 °F)
• Operating Humidity:
  • 90% or less (non-condensing)
• Weather Resistance: IP66-rated weatherproof housing

Physical Characteristics:

• Dimensions:
  • Ø 220 mm × 353 mm (Ø 8.66" × 13.9")
• Weight:
  • Approximately 3.0 kg (6.6 lbs)
• Material: Metal and Plastic

Additional Features:

• Mounting: Ceiling or wall mount
• Communication Interface: RS-485
• Video Output: 1 HD-TVI output
• Menu Language: English
• Synchronization: Internal synchronization
