Access Control systems

Display & User Interface

• Screen: 7-inch color TFT touchscreen
• Resolution: 800 x 480 pixels
• User Interface: Intuitive graphical user interface with easy navigation
• Audio: Voice prompts for feedback (successful access, denied, etc.)
• Keypad: On-screen virtual keypad for password input

Identification Methods

• Fingerprint Recognition:
  • High-quality optical fingerprint sensor
  • Fingerprint Template Capacity: Up to 5,000 templates
  • Verification Speed: Less than 1 second
• RFID Card Authentication:
  • Supports 125kHz RFID proximity cards
  • RFID Card Capacity: Up to 10,000 cards
• Password Authentication: Option for password entry as an additional layer of security
• Multi-Modal Authentication: Fingerprint, RFID, and password options for flexible access control

Log Storage Capacity

• Transaction Logs: Stores up to 200,000 transaction records (time and attendance logs, access logs)
• Logs: Real-time data storage for efficient attendance tracking

Communication & Connectivity

• Network Connectivity:
  • Ethernet: TCP/IP for network communication and data synchronization
• USB: USB Host and USB Client for data backup and transfer
• Wi-Fi: Optional support for external USB Wi-Fi dongle
• RS485: For integration with other access control devices
• Relay Output: For integration with door locks and other access control peripherals

Time & Attendance Features

• Shift Management: Configurable shift scheduling, overtime settings, and holiday management
• Real-Time Synchronization: Instant synchronization with time and attendance software
• Report Generation: Generates attendance and working hours reports for payroll calculations
• Real-Time Data Export: Direct export of attendance data to payroll systems for efficient processing

Access Control Features

• Door Control: Supports electric and magnetic locks for door access management
• Relay Output: Control over external access devices such as door locks
• Wiegand Interface: Supports Wiegand protocol for integrating with additional access control equipment
• Door Status Monitoring: Monitors the status of doors (open/closed) for real-time tracking

Security Features

• Anti-Tamper Alerts: Alerts triggered in case of unauthorized tampering or bypass attempts
• Data Encryption: Ensures secure communication and data storage through encryption protocols
• Multi-Factor Authentication: Enhanced security by combining fingerprint, RFID, and password authentication

Power Supply

• Power Input: 12V DC
• Power Consumption: Energy-efficient operation for reduced power usage

Physical Characteristics

• Dimensions: 232mm x 188mm x 49mm
• Weight: Approximately 0.8 kg
• Mounting: Wall-mountable design for easy installation
