General Specifications:

• Model: FHT2422D
• Type: Double Lane Full Height Turnstile
• Application: Suitable for high-security environments (e.g., stadiums, factories, airports, office buildings, etc.)
• Material: Stainless steel construction, ensuring durability and rust resistance.
• Lane Type: Double-lane, supporting simultaneous access of two persons.

Turnstile Dimensions & Design:

• Dimensions:
  • Height: 2200 mm
  • Width: 2200 mm (approximately)
  • Depth: 1800 mm
• Passage Width: Typically 600 mm for each lane.
• Design: Full-height turnstile, providing higher security than half-height or waist-high models.

Performance:

• Throughput Speed: 20-30 persons per minute (depending on user speed).
• Motorized Mechanism: Automated turnstile gates for easier and more efficient control of access.
• Rotation: 90° turnstile rotation after each validated access.

Controller & Integration:

• Controller: Integrated with InBio Pro Controller.
  • InBio Pro is a powerful access control panel capable of handling complex access control systems.
  • Supports biometric authentication, including fingerprint scanning.
• Fingerprint Reader: ZKTeco Fingerprint Reader.
  • Capacity for storing a large number of fingerprint templates.
  • Can work with ZKTeco's access control software for managing users.

Authentication Methods:

• Fingerprint: High-quality fingerprint reader for user authentication.
• Card-Based Access: Optional integration with RFID cards for additional security.
• PIN Code: Optional PIN code support via connected keypad or software configuration.

Security & Functionality Features:

• Anti-Tailgating: Detects and prevents tailgating (unauthorized person following a valid user).
• Anti-Piggybacking: Ensures only one person enters per authentication (prevents two individuals from accessing with one user).
• Emergency Mode: Turnstile can be unlocked during emergencies for safe passage.
• LED Indicators: Provides visual guidance for users (green for valid entry, red for restricted entry).

• General Features

  • Designed for 2-door access control
  • Supports in and out readers for each door
  • Authentication methods: Fingerprint, RFID card, and password
  • Advanced access control features, including multi-zone and multi-card opening

• Biometric and User Capacity

  • Fingerprint capacity: 20,000 templates
  • Card capacity: 60,000 users
  • Event capacity: 100,000 transaction logs

• Reader Compatibility

  • Supports RS485 readers, including ZKTeco's biometric readers
  • Compatible with Wiegand readers (26-bit and up to 34-bit)
  • Supports encrypted communication for enhanced security

• Communication

  • Network support: TCP/IP and RS485
  • Real-time data transfer with automatic push function
  • Fully integrated with ZKBioSecurity software for centralized management

• Access Control Features

  • Time-based access control with customizable time zones and user groups
  • Anti-passback and interlock functionality for enhanced security
  • Integration with fire alarms for emergency unlocking
  • Built-in first card unlocking and multi-card opening options

• Hardware Specifications

  • Processor: 1.2 GHz 32-bit high-speed processor
  • Memory: 32 MB RAM and 256 MB flash memory
  • Power supply: 12V DC/3A
  • Input ports: 4 (Exit button, door sensor, auxiliary inputs)
  • Output ports: 2 relay outputs for door locks, 2 auxiliary outputs

• Software Integration

  • Compatible with ZKBioSecurity and third-party management software
  • Supports firmware updates for continuous improvements

• Environmental Specifications

  • Operating temperature: 0°C to 45°C (32°F to 113°F)
  • Humidity: 20% to 80% (non-condensing)

• Design and Dimensions

  • Compact and durable for easy installation
  • Dimensions: 160 mm x 106 mm

General Features:

• Model: LMB-180U
• Type: 180-degree U-shaped mounting bracket
• Material: High-quality stainless steel for durability and corrosion resistance
• Finish: Silver or black powder-coated finish (depending on the model)
• Usage: Designed for mounting magnetic locks (such as ZKTeco’s magnetic lock models) in access control installations
• Compatibility: Compatible with 180-degree magnetic locks, ideal for use with ZKTeco's electromagnetic locks in single door installations
• Mounting Orientation: Provides a secure base for magnetic locks in horizontal or vertical orientations, offering flexibility in installation

Dimensions:

• Length: Typically 180mm (can vary by specific model)
• Width: Approximately 50mm
• Height: Approximately 50mm
• Weight: Lightweight design for easy installation

Functionality:

• Magnetic Lock Support: Specifically designed to hold and secure electromagnetic locks to door frames in access control systems
• Easy Installation: Facilitates straightforward installation of magnetic locks by providing a stable and secure mounting platform
• Angle Design: 180-degree angle allows for flexible positioning of magnetic locks to ensure secure door closure and proper alignment with the strike plate
• Adjustability: Some models may offer slight adjustability in positioning to accommodate different door types and frames

Applications:

• Doors: Designed for use on single doors, especially in situations where space or installation flexibility is limited
• Access Control Systems: Ideal for securing office buildings, data centers, hospitals, or other high-security areas requiring magnetic lock integration
• Indoor and Outdoor Use: Suitable for both indoor and outdoor applications when installed in weather-protected areas
