Access Control systems

• Biometric Capability

  • Fingerprint Sensor: SilkID fingerprint sensor
  • Capacity:
    • Fingerprint templates: 3,000
    • Face templates: 3,000 (optional)
    • User capacity: 10,000
    • Log capacity: 100,000

• Verification

  • Modes: Fingerprint, Card, PIN, Face (optional), or combinations
  • Speed: Fingerprint verification in less than 1 second
  • Accuracy: FAR ≤ 0.0001%, FRR ≤ 0.01%
  • Multi-biometric: Compatible with multiple biometric types

• Card Reader

  • Card Support: RFID, optional MIFARE
  • Card Capacity: 10,000

• Display and Interface

  • Screen: 2.4-inch TFT LCD color display
  • User Interface: Intuitive graphical interface
  • Keypad: 4x4 touch keypad

• Communication

  • Connectivity: TCP/IP, RS485, USB-Host
  • Wi-Fi: Optional
  • Wiegand: Input & Output for integration with third-party devices

• Access Control Features

  • Relay Output: Door lock, alarm
  • Inputs: Exit button, door sensor
  • Anti-Passback: Supported
  • Multiple Access Groups: Configurable

• Performance

  • Algorithm: ZKFinger V10.0 for superior accuracy
  • 1:N Fingerprint Matching: Up to 3,000 templates
  • Face recognition: Available in Pro models

• Power and Environment

  • Power Supply: 12V DC, 3A
  • Operating Temperature: -10°C to 45°C
  • Operating Humidity: 20%-80%

• Security Features

  • Tamper Alarm: Built-in tamper switch
  • Data Encryption: Supported
  • Backup: USB for data transfer and backup

• Software Integration

  • Supported Software: ZKAccess3.5 or third-party software via SDK
  • Time Zones: 50 custom time zones
  • Holiday Schedules: Configurable

• Physical

  • Dimensions: 181.6mm x 135mm x 44mm
  • Weight: 400g
  • Mounting: Wall-mounted installation

• Design & Build:

  • Material: SUS304 stainless steel for durability and corrosion resistance
  • Dimensions: 2220 mm (H) x 1500 mm (W) x 1460 mm (D)
  • Full-height structure for enhanced security
  • Compact and robust design suitable for both indoor and outdoor use

• Access Control Features:

  • Integrated with fingerprint recognition and RFID technology
  • Supports multiple verification methods: Fingerprint, RFID card, and password
  • High-speed and accurate biometric identification

• Performance:

  • Flow Rate:
    • Up to 25 persons per minute (RFID mode)
    • Up to 20 persons per minute (Fingerprint mode)
  • Bidirectional access for seamless entry and exit
  • Adjustable passage width for accommodating individuals or small equipment

• Control System:

  • Advanced controller for flexible access configurations
  • Integration support for third-party devices (e.g., barcode readers, face recognition terminals)
  • Dry contact and relay signal support
  • LED indicators for direction guidance and user feedback

• Safety Features:

  • Anti-tailgating and anti-reverse entry mechanisms
  • Emergency mode with fail-safe or fail-lock options during power failure
  • Equipped with a fire alarm interface for emergency unlocking
  • Smooth and silent operation with minimal noise

• Power & Environment:

  • Power Supply: AC 100~240V, 50/60Hz
  • Operating Temperature: -28°C to 60°C
  • Operating Humidity: 5% to 80% non-condensing
  • Suitable for harsh weather conditions

• Software Integration:

  • Compatible with ZKTeco's access control and time attendance software
  • Real-time monitoring and data management via network connectivity
  • Remote configuration and firmware upgrade support

General Specifications:

• Model: FHT2422
• Type: Full Height Turnstile with Fingerprint and RFID Access Control System
• Application: Suitable for high-security areas like office buildings, airports, factories, stadiums, and other locations with heavy foot traffic.
• Material: High-quality stainless steel for durability, rust resistance, and a modern finish.
• Lane Configuration: Single-lane passage.
• Passage Width: Approximately 600 mm per lane.

Dimensions & Design:

• Overall Dimensions:
  • Height: 2200 mm
  • Width: 1500 mm (approx.)
  • Depth: 1800 mm (approx.)
• Turnstile Height: Full-height design for maximum security, preventing unauthorized access through climbing or other bypass methods.
• Design: Space-efficient with a compact footprint while offering high security.

Authentication Methods:

• Fingerprint Authentication:
  • Integrated ZKTeco Fingerprint Reader for secure biometric authentication.
  • Large fingerprint storage capacity for fast identification and enhanced security.
  • High recognition speed for smooth and efficient operation.
• RFID Card Access:
  • Supports RFID cards (typically 125KHz or 13.56MHz) for access control.
  • Card Reader integrated for easy and fast user identification.
• PIN Code: Optional support for PIN code input (via additional keypad or software configuration).

Security Features:

• Anti-Tailgating: Detects and prevents unauthorized entry by ensuring that only one person passes at a time.
• Anti-Piggybacking: Prevents two people from entering using a single access pass.
• Emergency Mode: Allows emergency release to unlock the turnstile for safe evacuation.
• LED Indicators: Clear visual feedback showing the status of the access attempt (green for valid entry, red for denied access).
• Locking Mechanism: Motorized, ensuring the turnstile locks automatically after every entry or exit attempt until authorized access is granted.
• Direction Control: Configurable direction of access (either entry or exit) based on user needs.

Performance:

• Throughput Speed: Up to 30 people per minute, depending on the authentication method and user behavior.
• Motorized Operation: Automatically rotates upon successful authentication, ensuring smooth and efficient access.
• Rotation: 90° rotation after each validated access attempt to allow a person to pass.

Connectivity & Integration:

• Access Control Integration: Fully compatible with ZKTeco InBio controllers or other access control systems for centralized monitoring.
• Communication Protocols:
  • TCP/IP for networked access.
  • RS-485 and Wiegand protocols for integration with external access control systems.
• Event Log: Automatically logs all access events for tracking and reporting purposes.

Power Supply & Consumption:

• Power Supply: Operates on 12V DC or 24V DC, depending on configuration.
• Power Consumption:
  • Standby Power: Approx. 30W
  • Operational Power: Approx. 50W

Environment Specifications:

• Temperature Range:
  • Operating: -10°C to 60°C.
  • Storage: -20°C to 70°C.
• Humidity: 0% to 90% (non-condensing), making it suitable for both indoor and outdoor environments.

Safety & Security Features:

• Emergency Release Mechanism: Ensures safe evacuation by releasing the turnstile locks during emergencies.
• Safety Sensors: Prevents the turnstile from operating if there is an obstruction, avoiding injury or damage.

• General Information

  • Product Type: RS485 Slave Fingerprint Reader
  • Usage: Works with ZKTeco access control terminals and control panels
  • Communication: RS485 protocol for secure and reliable data transfer

• Biometric Capability

  • Fingerprint Sensor: High-precision optical sensor
  • Fingerprint Templates: Stored and matched by the host device

• Card Reader

  • Card Type: Supports EM and MIFARE (optional) cards
  • Reading Range: 3-5cm

• Verification and Authentication

  • Authentication Modes: Fingerprint, Card, or a combination
  • Response Time: Fast authentication with low latency

• Interface

  • Connectivity: RS485 for communication with master device
  • LED Indicators: Multi-color LED for operation status (e.g., access granted/denied)
  • Buzzer: Audible feedback for successful/failed actions

• Design

  • Compact Size: Slim and lightweight for easy installation
  • Material: Durable plastic housing
  • Dimensions: 102mm x 50mm x 37mm
  • Weight: ~120g

• Power and Environment

  • Power Supply: DC 12V ± 10%
  • Operating Temperature: 0°C to 45°C
  • Operating Humidity: 20%-80% (non-condensing)
  • Power Consumption: Low power consumption for energy efficiency

• Compatibility

  • Works With: ZKTeco control panels and standalone access control devices supporting RS485
  • Fingerprint Matching: Handled by the master device or panel

• Security Features

  • Data Communication: Secure and encrypted RS485 transmission
  • Tamper Detection: Built-in tamper switch for enhanced security
