General Specifications
- Product Type: Planar Lightwave Circuit (PLC) Optical Splitter
- Configuration: 1x4 (1 input fiber and 4 output fibers)
- Design: Bare PLC Splitter in a Steel Tube
- Fiber Type: Singlemode Fiber
- Fiber Buffer Diameter: 250µm (tight-buffered)
Optical Performance
- Wavelength Range: 1260 nm - 1650 nm (suitable for both 1310 nm and 1550 nm windows)
- Insertion Loss:
- Typical: ≤ 7.5 dB
- Maximum: ≤ 8.0 dB
- Uniformity: ≤ 1.2 dB (ensures consistent signal distribution among outputs)
- Return Loss: ≥ 50 dB (minimizes back reflections)
- Directivity: ≥ 55 dB (reduces cross-talk between inputs and outputs)
- Polarization Dependent Loss (PDL): ≤ 0.2 dB (ensures consistent performance regardless of polarization)
- Splitting Ratio: 1:4 (equal power distribution)
Fiber Specifications
- Fiber Mode Compatibility: ITU-T G.657A or G.652D compliant
- Input/Output Fiber Diameter: 250µm tight-buffered fiber
- Cable Jacket Material: Steel tube for added protection and mechanical strength
Physical Dimensions
- Enclosure Type: Steel tube
- Dimensions:
- Length: Typically 60-100 mm (varies by design)
- Diameter: Approximately 6-8 mm
- Weight: Approximately 50-100 grams (varies by design and length)
Environmental Specifications
- Operating Temperature: -40°C to +85°C (suitable for a wide range of environments)
- Storage Temperature: -40°C to +85°C
- Humidity: 0% to 95% (non-condensing, suitable for various environmental conditions)
Installation Features
- Mounting: Typically installed in splice trays or enclosures
- Cable Management: Requires external cable management solutions
- Accessibility: Accessible for splicing and maintenance
- Labeling: Clear port numbering and labeling for easy identification and troubleshooting
Compliance and Standards
- Industry Standards:
- Telcordia GR-1209 and GR-1221 compliant for reliability and performance
- IEC 61753-1 compliant for fiber optic interconnecting devices
- RoHS compliant for environmental and safety regulations
Additional Features
- Design: Compact and durable steel tube design for robust protection
- Accessories: May include splice sleeves, protective caps, and installation instructions
- Reliability: High stability and reliability for various network applications, including FTTH, PON, and CATV
- Durability: Engineered for long-term operation with low maintenance requirements
1X4 Bare PLC Steel Tube 250µm Single Mode Fiber Splitter
Original price was: KSh 5,000.KSh 4,600Current price is: KSh 4,600. ( Ex VAT )Original price was: KSh 5,000.KSh 4,600Current price is: KSh 4,600. ( Ex VAT ) Add to cart - -10%
General Specifications
- Product Type: Planar Lightwave Circuit (PLC) Optical Splitter
- Configuration: 1x64 (1 input fiber and 64 output fibers)
- Design: Blockless (compact design without a protective box)
- Connector Type: LC/PC (Lucent Connector/Physical Contact)
- Connector Polish: PC (Physical Contact)
- Fiber Buffer Diameter: 900µm tight-buffered fiber
Optical Performance
- Wavelength Range: 1260 nm - 1650 nm (supports both 1310 nm and 1550 nm windows)
- Insertion Loss:
- Typical: ≤ 20.5 dB
- Maximum: ≤ 21.5 dB
- Uniformity: ≤ 2.0 dB (ensures consistent signal distribution among outputs)
- Return Loss: ≥ 50 dB for PC connectors (minimizes back reflections)
- Directivity: ≥ 55 dB (reduces cross-talk between inputs and outputs)
- Polarization Dependent Loss (PDL): ≤ 0.3 dB (ensures consistent performance regardless of polarization)
- Splitting Ratio: Equal power distribution (1:64 split)
Fiber Specifications
- Fiber Type: Singlemode fiber
- Fiber Mode Compatibility: ITU-T G.657A or G.652D compliant
- Input/Output Fiber Diameter: 900µm tight-buffered fiber for increased flexibility
- Cable Jacket Material: Coated with 900µm buffer layer for protection and flexibility
Physical Dimensions
- Splitter Type: Blockless, suitable for installation without enclosure
- Fiber Length: Typically 1-2 meters for both input and output fibers (varies by manufacturer)
- Connector Housing Material: High-quality plastic or metal
Environmental Specifications
- Operating Temperature: -40°C to +85°C (suitable for a wide range of environments)
- Storage Temperature: -40°C to +85°C
- Humidity: 0% to 95% (non-condensing, suitable for various environmental conditions)
Installation Features
- Installation Type: Can be spliced directly into existing fiber optic cables or used with enclosures
- Accessibility: Easy access for installation and maintenance
- Cable Management: Requires external cable management solutions
- Labeling: Clear labeling on fibers for easy identification and troubleshooting
Compliance and Standards
- Industry Standards:
- Telcordia GR-1209 and GR-1221 compliant for reliability and performance
- IEC 61753-1 compliant for fiber optic interconnecting devices
- RoHS compliant for environmental and safety regulations
Additional Features
- Design: Compact, blockless design for easy integration into various setups
- Accessories: May include protective caps for connectors and splice sleeves
- Reliability: High stability and reliability in various network applications, including FTTH, PON, and CATV
- Durability: Engineered for long-term operation with low maintenance requirements
1X64 blockless 900µm fiber LC/PC PLC Fiber splitter connectors
Original price was: KSh 20,000.KSh 18,000Current price is: KSh 18,000. ( Ex VAT )Original price was: KSh 20,000.KSh 18,000Current price is: KSh 18,000. ( Ex VAT ) Add to cart - -2%
General Specifications
- Product Type: Fiber Optic Splitter
- Configuration: 1x8 (1 input, 8 outputs)
- Splitter Type: Planar Lightwave Circuit (PLC)
- Housing Type: Bare steel tube
- Fiber Type: Singlemode
- Fiber Diameter: 250µm (micron)
Optical Performance
- Operating Wavelength: 1260 nm - 1650 nm (covers O, E, S, C, and L bands)
- Insertion Loss:
- Typical: ≤ 10.5 dB
- Maximum: ≤ 11.0 dB
- Uniformity: ≤ 0.8 dB (ensures consistent signal distribution across all outputs)
- Return Loss: ≥ 55 dB (minimizes back reflections)
- Polarization Dependent Loss (PDL): ≤ 0.2 dB (ensures stable performance across polarization states)
- Directivity: ≥ 55 dB (ensures minimal signal leakage between input and output ports)
Mechanical Specifications
- Steel Tube Dimensions:
- Length: Approximately 40 mm - 60 mm
- Diameter: Approximately 3 mm - 4 mm
- Fiber Length: Typically 1 meter (input and output fibers)
- Strength Member: Stainless steel for enhanced durability
- Weight: Lightweight design for easy handling and integration
Environmental Specifications
- Operating Temperature: -40°C to +85°C (suitable for a wide range of environmental conditions)
- Storage Temperature: -40°C to +85°C
- Humidity: 0% to 95% (non-condensing)
Installation Features
- Compatibility: Compatible with various fiber optic systems and networks
- Installation:
- Simple installation with fusion splicing or mechanical splicing
- Bare fiber ends allow for flexible integration
- Bend Radius: Supports standard bend radius requirements for 250µm fibers
Compliance and Standards
- Industry Standards:
- Compliant with Telcordia GR-1209 and GR-1221 standards
- RoHS compliant for environmental safety
Application Areas
- Telecommunications: Ideal for splitting optical signals in telecom networks
- Data Centers: Suitable for high-density fiber optic connections
- FTTH: Widely used in Fiber to the Home applications for signal distribution
- Passive Optical Networks (PON): Essential for splitting signals in PON architectures
- CATV: Used in cable television systems for efficient signal distribution
Additional Features
- Design: Compact and lightweight for easy integration and space-saving installations
- Durability: Steel tube housing provides mechanical protection and stability
- Reliability: High-quality PLC technology ensures long-term performance and reliability
- Customization: Available with various fiber lengths and connector options upon request
1X8 Bare PLC Steel Tube 250µm Single Mode Fiber Splitter
Original price was: KSh 6,600.KSh 6,500Current price is: KSh 6,500. ( Ex VAT )Original price was: KSh 6,600.KSh 6,500Current price is: KSh 6,500. ( Ex VAT ) Add to cart - -6%
General Specifications
- Product Type: Fiber Optic Access Terminal Box (ATB)
- Core Capacity: 2 cores
- Adapter Type: LC/UPC
- Number of Adapters: 1 LC/UPC Duplex Adapter
- Material:
- Housing: Cold-rolled steel, ABS plastic, or polycarbonate
- Finish: Powder-coated or UV-resistant finish
- Color: Typically white or gray
Dimensions and Weight
- Height: Approximately 150 mm
- Width: Approximately 120 mm
- Depth: Approximately 30 mm
- Weight: Approximately 0.3 kg - 0.5 kg (depends on materials and design)
Optical Performance
- Insertion Loss:
- Maximum: ≤ 0.2 dB (per connection)
- Return Loss:
- UPC Polish: ≥ 50 dB
- Fiber Type: Singlemode (SM) or Multimode (MM)
- Wavelength Compatibility:
- Singlemode: 1260 nm - 1650 nm
- Multimode: 850 nm and 1300 nm
Environmental Specifications
- Operating Temperature: -20°C to +60°C
- Storage Temperature: -40°C to +85°C
- Humidity: 0% to 95% (non-condensing)
Mechanical Features
- Design:
- Compact and lightweight with a secure enclosure
- Integrated cable management features for organized fiber routing
- Cable Entry:
- Rear or side cable entry ports with strain relief
- Compatible with various cable types (e.g., loose tube, tight buffered)
- Splice Tray:
- Capacity for up to 2 splices (if applicable)
- Supports heat-shrink or mechanical splice protectors
Installation Features
- Mounting:
- Wall-mountable or desktop installation
- Includes mounting brackets or adhesive pads
- Access:
- Front or top access with a secure latching mechanism
- Grounding:
- Integrated grounding points or lugs
Compliance and Standards
- Industry Standards:
- Complies with Telcordia GR-326 and GR-449
- RoHS compliant
- IEC 61754 compliant for fiber optic interconnects
Application Areas
- Telecommunications: Suitable for home and small office network access points
- FTTH: Ideal for Fiber to the Home installations for terminating and managing fiber connections
- Enterprise Networks: For structured cabling and interconnects in small network setups
Additional Features
- Labeling:
- Port labeling for easy identification
- Areas for custom labels and documentation
- Security:
- Tamper-resistant design features
- Ventilation:
- Passive ventilation slots to prevent overheating (if applicable)
- Customization:
- Available with various connector and adapter configurations
- Custom colors and finishes upon request
2 Core FO Fibre Access Terminal Box (ATB) LC/UPS Adapter
Original price was: KSh 600.KSh 564Current price is: KSh 564. ( Ex VAT )Original price was: KSh 600.KSh 564Current price is: KSh 564. ( Ex VAT ) Add to cart - -11%
General Specifications
- Product Type: Fiber Optic Access Terminal Box (ATB)
- Core Capacity: 2 cores
- Adapter Type: SC/UPC Simplex
- Number of Adapters: 1 SC/UPC Simplex Adapter
- Material:
- Housing: Cold-rolled steel, ABS plastic, or polycarbonate
- Finish: Powder-coated or UV-resistant finish
- Color: Typically white or gray
Dimensions and Weight
- Height: Approximately 150 mm (5.9 inches)
- Width: Approximately 120 mm (4.7 inches)
- Depth: Approximately 30 mm (1.2 inches)
- Weight: Approximately 0.3 kg - 0.5 kg (0.66 lbs - 1.1 lbs), depending on materials and design
Optical Performance
- Insertion Loss:
- Maximum: ≤ 0.2 dB (per connection)
- Return Loss:
- UPC Polish: ≥ 50 dB
- Fiber Type: Singlemode (SM) or Multimode (MM)
- Wavelength Compatibility:
- Singlemode: 1260 nm - 1650 nm
- Multimode: 850 nm and 1300 nm
Environmental Specifications
- Operating Temperature: -20°C to +60°C (-4°F to +140°F)
- Storage Temperature: -40°C to +85°C (-40°F to +185°F)
- Humidity: 0% to 95% (non-condensing)
Mechanical Features
- Design:
- Compact and lightweight with a secure enclosure
- Integrated cable management features for organized fiber routing
- Cable Entry:
- Rear or side cable entry ports with strain relief
- Compatible with various cable types (e.g., loose tube, tight-buffered)
- Splice Tray:
- Capacity for up to 2 splices
- Supports heat-shrink or mechanical splice protectors
Installation Features
- Mounting:
- Wall-mountable or desktop installation
- Includes mounting brackets or adhesive pads
- Access:
- Front or top access with a secure latching mechanism
- Grounding:
- Integrated grounding points or lugs
Compliance and Standards
- Industry Standards:
- Complies with Telcordia GR-326 and GR-449
- RoHS compliant
- IEC 61754 compliant for fiber optic interconnects
Application Areas
- Telecommunications: Suitable for home and small office network access points
- FTTH: Ideal for Fiber to the Home installations for terminating and managing fiber connections
- Enterprise Networks: For structured cabling and interconnects in small network setups
Additional Features
- Labeling:
- Port labeling for easy identification
- Areas for custom labels and documentation
- Security:
- Tamper-resistant design features
- Ventilation:
- Passive ventilation slots to prevent overheating (if applicable)
- Customization:
- Available with various connector and adapter configurations
- Custom colors and finishes upon request
2 Core FO Fibre Access Terminal Box (ATB) SC/UPS Adapter
Original price was: KSh 600.KSh 534Current price is: KSh 534. ( Ex VAT )Original price was: KSh 600.KSh 534Current price is: KSh 534. ( Ex VAT ) Add to cart - -53%
- Type: Single-mode fiber optic drop cable
- Core Count: 2 cores
- Fiber Type: Single-mode
- Core Diameter: 9 µm
- Cladding Diameter: 125 µm
- Cable Structure:
- Fiber Configuration: Tight-buffered
- Strength Member: Aramid yarn or fiberglass
- Outer Jacket Material: LSZH (Low Smoke Zero Halogen) or PVC
- Cable Diameter: Approximately 2.0 mm to 3.0 mm (depending on design)
- Maximum Attenuation:
- At 1310 nm: ≤ 0.40 dB/km
- At 1550 nm: ≤ 0.25 dB/km
- Operating Temperature: -20°C to +60°C
- Installation Temperature: -10°C to +50°C
- Bending Radius:
- Dynamic: ≥ 20 times the outer diameter
- Static: ≥ 10 times the outer diameter
- Water Resistance: Yes (typically IP67 rated)
- Color Coding: Standard color coding for fibers (typically Blue and Yellow)
- Application: Suitable for Fiber to the Home (FTTH) installations, indoor environments, and connecting fiber networks to end-user locations
- Standards Compliance: Meets industry standards for fiber optic cables (such as IEC, Telcordia, etc.)
2 Core SingleMode Indoor Fiber Optic FTTH Drop Cable
Original price was: KSh 32.KSh 15Current price is: KSh 15. ( Ex VAT )Original price was: KSh 32.KSh 15Current price is: KSh 15. ( Ex VAT ) Add to cart - -10%
- Product Type: 2 Core SingleMode Outdoor FTTH Drop Cable
- Core Count: 2 fibers
- Fiber Type: Singlemode
- Cable Length: 1 kilometer (1000 meters)
- Construction:
- Loose tube or tight-buffered design
- UV-resistant outer jacket for outdoor applications
- Outer Diameter: Typically ranges from 3-5 mm (exact dimensions may vary by manufacturer)
- Material:
- Outer jacket made from low smoke zero halogen (LSZH) or polyethylene (PE)
- Reinforced with aramid yarn for additional strength and protection
- Operating Temperature Range: -40°C to +70°C
- Bending Radius: Minimum bending radius usually 10 times the outer diameter
- Wavelength: Optimized for wavelengths of 1310 nm and 1550 nm
- Transmission Distance: Capable of long-distance transmission with low attenuation
- Connector Type: Various options available (e.g., SC, LC)
- Moisture Resistance: Designed for outdoor use with moisture-proof features
- Compliance: Meets international standards (e.g., IEC, TIA/EIA) for singlemode fiber cables
- Application: Ideal for Fiber-to-the-Home (FTTH) installations, telecommunications, and data networks
2 Core SingleMode Outdoor FTTH Drop Cable, 1KM
Original price was: KSh 10,000.KSh 9,000Current price is: KSh 9,000. ( Ex VAT )Original price was: KSh 10,000.KSh 9,000Current price is: KSh 9,000. ( Ex VAT ) Add to cart - -14%
- Cable Type: Cat 6 UTP (Unshielded Twisted Pair) Patch Cord
- Length: 2 meters (approximately 6.6 feet)
- Category: Cat 6
- Conductor:
- Material: Solid or stranded copper
- Gauge: 23 AWG (American Wire Gauge) or 24 AWG
- Connector:
- Type: RJ45 (8P8C) connectors
- Shielding: Unshielded, with plastic clip covers
- Construction:
- Cable Type: Unshielded twisted pair (UTP)
- Twisting: Twisted pair for each signal line to reduce interference
- Insulation: High-quality PE (Polyethylene) insulation
- Performance:
- Data Rate: Supports up to 1 Gbps (Gigabit Ethernet)
- Frequency: Up to 250 MHz
- Application:
- Usage: Suitable for networking, data transmission, and connecting devices such as computers, routers, switches, and hubs
- Color: Typically blue or other standard colors
- Jacket:
- Material: PVC (Polyvinyl Chloride) for durability
- Diameter: Standard for Cat 6 cables
- Compliance:
- Standards: Complies with ANSI/TIA-568-C.2 Cat 6 standards
- Certifications: RoHS (Restriction of Hazardous Substances) compliant
- Connector Features:
- Contacts: Gold-plated contacts for reliable signal transmission and resistance to corrosion
- Clip: Snag-less boot to prevent damage during installation and removal
- Temperature Range:
- Operating Temperature: Typically from 0°C to 60°C (32°F to 140°F)
- Storage Temperature: Typically from -20°C to 75°C (-4°F to 167°F)
2 Meter Cat 6 UTP Patch Cord , EaseNet
Original price was: KSh 350.KSh 300Current price is: KSh 300. ( Ex VAT )Original price was: KSh 350.KSh 300Current price is: KSh 300. ( Ex VAT ) Add to cart - -10%
- Length: 2 meters (6.56 feet)
- Category: Category 6 (Cat 6)
- Cable Type: Unshielded Twisted Pair (UTP)
- Connector Type:
- Plug Type: Modular RJ45 connectors on both ends
- Contacts: Typically 50-micron gold-plated for reliable connectivity and durability
- Performance:
- Data Rate: Supports up to 1 Gbps (Gigabit Ethernet)
- Bandwidth: Up to 250 MHz
- Standards Compliance: Meets or exceeds ANSI/TIA-568-C.2 Category 6 standards and ISO/IEC 11801 Class E standards
- Conductor Configuration:
- Pairs: 4 twisted pairs
- Conductor Gauge: Typically 24 AWG or 26 AWG stranded copper conductors (varies by model)
- Cable Jacket:
- Material: PVC (Polyvinyl Chloride) or optional LSZH (Low Smoke Zero Halogen) for enhanced safety
- Color: Available in various colors such as gray, blue, yellow, green, etc.
- Temperature Range:
- Operating Temperature: Typically -20°C to +60°C (-4°F to +140°F)
- Storage Temperature: Typically -20°C to +75°C (-4°F to +167°F)
- Durability:
- Minimum Bend Radius: Typically 4x the cable diameter
- Plug Retention Force: Ensures a secure connection
- Compliance:
- RoHS: Compliant (Restriction of Hazardous Substances)
- Certifications: UL listed, ETL verified for performance and compliance
- Applications:
- Suitable for standard networking applications where Gigabit Ethernet is required
- Ideal for use in office environments, home networks, and other networking scenarios
- Suitable for connecting network devices such as switches, routers, and patch panels
- Packaging:
- Supplied individually in protective, easy-to-open packaging
2 Meter Cat6 UTP Patchcord
Original price was: KSh 500.KSh 450Current price is: KSh 450. ( Ex VAT )Original price was: KSh 500.KSh 450Current price is: KSh 450. ( Ex VAT ) Add to cart - -29%
- Length: 2 meters (6.56 feet)
- Category: Category 6A (Cat 6A)
- Cable Type: Shielded Twisted Pair (STP) or Unshielded Twisted Pair (UTP) (depending on specific model)
- Shielding (if STP):
- Shielding Type: Foil Shielded Twisted Pair (F/UTP) with overall shield
- Shield Material: Typically aluminum foil with a drain wire
- Connector Type:
- Plug Type: Modular RJ45 connectors on both ends
- Contacts: 50-micron gold-plated for enhanced durability and reliable connectivity
- Performance:
- Data Rate: Supports up to 10 Gbps (10 Gigabit Ethernet)
- Bandwidth: Up to 500 MHz
- Standards Compliance: Meets or exceeds ANSI/TIA-568-C.2 Category 6A and ISO/IEC 11801 Class EA standards
- Conductor Configuration:
- Pairs: 4 twisted pairs
- Conductor Gauge: Typically 26 AWG or 28 AWG stranded copper conductors (varies by model)
- Cable Jacket:
- Material: PVC (Polyvinyl Chloride) or LSZH (Low Smoke Zero Halogen) for enhanced safety
- Color: Available in various colors such as gray, blue, yellow, green, etc.
- Temperature Range:
- Operating Temperature: -20°C to +60°C (-4°F to +140°F)
- Storage Temperature: -20°C to +75°C (-4°F to +167°F)
- Durability:
- Minimum Bend Radius: Typically 4x the cable diameter
- Plug Retention Force: Ensures a secure connection
- Compliance:
- RoHS: Compliant (Restriction of Hazardous Substances)
- Certifications: UL listed, ETL verified for performance and compliance
- Applications:
- Suitable for high-performance networking environments requiring 10 Gigabit Ethernet
- Ideal for use in data centers, enterprise networks, and telecommunications rooms
- Suitable for connecting network devices such as switches, routers, and patch panels
- Packaging:
- Supplied individually in protective, easy-to-open packaging
2 Meter Cat6A Ethernet Patch Cord
Original price was: KSh 700.KSh 500Current price is: KSh 500. ( Ex VAT )Original price was: KSh 700.KSh 500Current price is: KSh 500. ( Ex VAT ) Add to cart - -4%
General Specifications
- Product Type: Rack Mount Optical Splitter
- Configuration: 2 x 32 (2 input fibers and 32 output fibers)
- Connector Type: SC/PC (Standard Connector/Physical Contact)
- Connector Polish: PC (Physical Contact)
- Fiber Jacket Type: PVC (Polyvinyl Chloride)
- Fiber Buffer Diameter: 0.9mm
Optical Performance
- Wavelength Range: 1260 nm - 1650 nm (suitable for both 1310 nm and 1550 nm windows)
- Insertion Loss:
- Typical: ≤ 16.5 dB
- Maximum: ≤ 17.5 dB
- Uniformity: ≤ 1.5 dB (ensuring consistent signal distribution among outputs)
- Return Loss: ≥ 50 dB for PC connectors (minimizing back reflections)
- Directivity: ≥ 55 dB (reducing cross-talk between inputs)
- Polarization Dependent Loss (PDL): ≤ 0.2 dB (ensuring consistent performance regardless of polarization)
- Splitting Ratio: Equal power distribution (1:32 split for each input)
Fiber Specifications
- Fiber Type: Singlemode fiber
- Fiber Mode Compatibility: ITU-T G.657A or G.652D compliant
- Input/Output Fiber Diameter: 0.9mm buffered fiber
- Cable Jacket Material: PVC for protection and flexibility
Physical Dimensions
- Enclosure Type: 19-inch rack mountable
- Height: 1U or 2U (depending on design and manufacturer)
- Width: 19 inches (482.6 mm) standard rack width
- Depth: Typically around 10-12 inches (254-305 mm), varies by manufacturer
Environmental Specifications
- Operating Temperature: -40°C to +85°C (suitable for a wide range of environments)
- Storage Temperature: -40°C to +85°C
- Humidity: 0% to 95% (non-condensing, suitable for various environmental conditions)
Installation Features
- Mounting: Standard 19-inch rack mountable
- Accessibility: Front access for easy installation, operation, and maintenance
- Cable Management: Built-in cable management features for organized routing and protection
- Labeling: Clear port numbering and labeling for easy identification and troubleshooting
Compliance and Standards
- Industry Standards:
- Telcordia GR-1209 and GR-1221 compliant for reliability and performance
- IEC 61753-1 compliant for fiber optic interconnecting devices
- RoHS compliant for environmental and safety regulations
Additional Features
- Design: Compact and efficient design for space utilization
- Security: Optional lockable front panels for added security in high-traffic areas
- Accessories: Supplied with necessary mounting brackets, screws, dust caps, and installation instructions
- Reliability: High stability and reliability in various network applications, including FTTH, PON, and CATV
- Durability: Engineered for long-term operation with low maintenance requirements
2 X 32 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors
Original price was: KSh 28,000.KSh 27,000Current price is: KSh 27,000. ( Ex VAT )Original price was: KSh 28,000.KSh 27,000Current price is: KSh 27,000. ( Ex VAT ) Add to cart - -7%
- Product Type: RG59 CCTV Coaxial Cable
- Length: 200 meters
- Cable Type: Coaxial
- Impedance: 75 ohms
- Conductor: Copper center conductor for improved signal quality
- Shielding:
- Double shielding with aluminum foil and braided copper
- Reduces interference and enhances signal integrity
- Jacket Material: PVC (Polyvinyl Chloride) outer jacket
- Outer Diameter: Approximately 6.9 mm
- Temperature Range: -20°C to 60°C (-4°F to 140°F)
- Application: Designed for use in CCTV surveillance systems
- Transmission Distance: Supports video transmission up to 300 meters without significant loss (depending on equipment)
- Flexibility: Flexible design for easy installation in various environments
- Color: Typically black or grey (varies by model)
- Connector Type: Compatible with BNC connectors (not included)
- Uses: Suitable for transmitting video signals from cameras to DVRs or monitors
- Compliance: Meets or exceeds relevant industry standards for video transmission
200M RG59 CCTV Coaxial Cable
Original price was: KSh 7,500.KSh 7,000Current price is: KSh 7,000. ( Ex VAT )Original price was: KSh 7,500.KSh 7,000Current price is: KSh 7,000. ( Ex VAT ) Add to cart - -47%
General Specifications
- Module Type: Small Form-Factor Pluggable (SFP) Mini GBIC
- Standard: 1000Base-LX (Gigabit Ethernet over Singlemode Fiber)
- Distance: Up to 20 kilometers (km)
- Wavelength: 1310 nm
Optical Characteristics
- Optical Connector: LC Duplex
- Transmitter Type: Laser Diode (LD)
- Receiver Type: Photodiode (PD)
- Transmit Power:
- Minimum: -9 dBm
- Maximum: -3 dBm
- Receiver Sensitivity:
- Typical: -20 dBm
- Maximum Input Power: -3 dBm
- Optical Fiber Type: Singlemode Fiber (SMF)
Electrical Characteristics
- Data Rate: 1 Gbps (Gigabit per second)
- Power Consumption: Typically ≤ 1.0 W
Performance Specifications
- Bit Error Rate (BER): < 1 x 10^-12
- Link Budget: 11 dB
- Temperature Range:
- Operating: 0°C to +70°C
- Storage: -40°C to +85°C
Mechanical Specifications
- Form Factor: SFP Mini GBIC
- Dimensions:
- Length: Approximately 72 mm
- Width: Approximately 13 mm
- Height: Approximately 8 mm
- Weight: Approximately 30 grams
Compliance and Standards
- Standards Compliance:
- IEEE 802.3z (Gigabit Ethernet)
- RoHS (Restriction of Hazardous Substances)
- Safety: CE, FCC, and other relevant safety certifications
Additional Features
- Hot Swappable: Yes (supports hot swapping for easy replacement without powering down)
- Diagnostics: Built-in digital diagnostic monitoring (DDM) for real-time status and performance metrics
- Connector: LC/PC (Physical Contact)
20km Transceiver 1000 Base-LX SPF Mini GBC Module
Original price was: KSh 30,000.KSh 16,000Current price is: KSh 16,000. ( Ex VAT )Original price was: KSh 30,000.KSh 16,000Current price is: KSh 16,000. ( Ex VAT ) Add to cart - -10%
- Rack Units: 22U
- Dimensions (HxWxD): 1200mm (H) x 600mm (W) x 1000mm (D)
- Material: High-quality cold-rolled steel for durability
- Finish: Powder-coated for enhanced corrosion resistance and aesthetics
- Weight Capacity: Supports up to 800 kg of equipment
- Cooling System:
- Ventilated side panels and rear door for optimal airflow
- Adjustable fan mounting options to enhance cooling efficiency
- Doors:
- Lockable front and rear doors for security
- Front door made of tempered glass for visibility
- Solid rear door for protection and stability
- Mounting:
- Standard 19-inch adjustable mounting rails for versatile equipment installation
- Adjustable mounting depth to accommodate various equipment sizes
- Cable Management:
- Multiple cable entry points at the top and bottom for flexible routing
- Integrated cable management features, including hooks and trays, for organized cabling
- Security Features:
- 3-point locking system on front and rear doors for enhanced security
- Optional alarm system compatibility for additional protection
- Grounding: Integrated grounding bar for safe electrical management
- Accessories:
- Compatible with optional shelves, power distribution units (PDUs), and other accessories
- Vertical and horizontal cable management options available
- Installation: Easy assembly with all necessary hardware included
22U 600mm x 1000mm Server Rack Data Cabinet
Original price was: KSh 48,000.KSh 43,000Current price is: KSh 43,000. ( Ex VAT )Original price was: KSh 48,000.KSh 43,000Current price is: KSh 43,000. ( Ex VAT ) Add to cart - -3%
- Rack Units: 22U
- Dimensions (H x W x D): 1200mm (H) x 600mm (W) x 600mm (D)
- Material: Durable cold-rolled steel for enhanced strength
- Weight Capacity: Supports up to 800 kg of equipment
- Finish: Electrostatic powder-coated for corrosion resistance and durability
- Doors:
- Lockable tempered glass front door for security and visibility
- Solid metal rear door for enhanced protection
- Removable side panels for easy access and maintenance
- Cooling Features:
- Ventilated side panels for optimal airflow
- Top and bottom cable entry points for effective cooling and cable management
- Optional fan kit available for improved airflow
- Mounting Rails:
- Standard 19-inch adjustable mounting rails to fit various equipment
- Adjustable mounting depth to accommodate different devices
- Cable Management:
- Multiple cable entry points for organized routing
- Integrated cable management trays and hooks to minimize clutter
- Security Features:
- 3-point locking system on front door and additional locking on rear door
- Installation:
- Quick and easy installation with included mounting hardware
- Adjustable leveling feet for stability on uneven floors
- Applications: Suitable for network equipment, servers, telecommunications, and IT infrastructure
22U 600mm X 600mm Floor standing Data Cabinet, servers rack
Original price was: KSh 30,000.KSh 29,000Current price is: KSh 29,000. ( Ex VAT )Original price was: KSh 30,000.KSh 29,000Current price is: KSh 29,000. ( Ex VAT ) Add to cart - -3%
- Rack Units: 22U
- Dimensions (HxWxD): 22U x 600mm (W) x 600mm (D)
- Material: High-strength cold-rolled steel construction
- Finish: Powder-coated exterior for enhanced corrosion and weather resistance
- Protection Rating: IP55-rated for weather protection (dustproof and waterproof)
- Cooling System:
- Integrated ventilation fans for active cooling
- Louvered vents for passive airflow
- Optional cooling options (e.g., heat exchangers or air conditioning units)
- Door:
- Single or dual access door(s) with weather-sealed gaskets
- 3-point locking system for secure access
- Optional anti-vandal and tamper-resistant features
- Mounting:
- Standard 19-inch rack-mountable adjustable rails
- Front and rear mounting rails with adjustable depth for various equipment sizes
- Cable Management:
- Multiple cable entry points on the top and bottom panels
- Sealable grommets to prevent dust and water ingress
- Load Capacity: Supports up to 80 kg (varies by configuration and equipment)
- Temperature Management:
- Thermostat-controlled fans for efficient temperature control
- Optional heating unit for cold climates
- Security:
- Anti-vandal and lockable design
- Optional alarm systems and access control features for added security
- Grounding: Integrated grounding strip for safe and reliable earthing
- Accessories:
- Adjustable shelving options
- Power distribution units (PDUs) for organized power management
- Mounting hardware included
22U 600×600 Outdoor Data server Cabinet
Original price was: KSh 59,000.KSh 57,000Current price is: KSh 57,000. ( Ex VAT )Original price was: KSh 59,000.KSh 57,000Current price is: KSh 57,000. ( Ex VAT ) Add to cart
