General Specifications

• Product Type: Fiber Optic Access Terminal Box (ATB)
• Core Capacity: 24 cores
• Adapter Type: SC/UPC Simplex
• Number of Adapters: 24
• Material:
  • Housing: Cold-rolled steel or ABS plastic
  • Coating: Powder-coated or UV-resistant finish
• Color: Typically telecom gray or black

Dimensions and Weight

• Height: Approximately 300 mm
• Width: Approximately 250 mm
• Depth: Approximately 100 mm
• Weight: Approximately 2 kg - 3 kg (depends on materials and design)

Optical Performance

• Insertion Loss:
  • Maximum: ≤ 0.2 dB (per connection)
• Return Loss:
  • UPC Polish: ≥ 50 dB
• Fiber Type: Singlemode (SM) or Multimode (MM)
• Wavelength Compatibility:
  • Singlemode: 1260 nm - 1650 nm
  • Multimode: 850 nm and 1300 nm

Environmental Specifications

• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +85°C
• Humidity: 0% to 95% (non-condensing)

Mechanical Features

• Design:
  • Compact and durable with a front panel for adapter mounting
  • Integrated cable management features for organized fiber routing
• Cable Entry:
  • Rear or side cable entry ports with strain relief
  • Compatible with various cable types (e.g., loose tube, tight buffered)
• Splice Tray:
  • Capacity for up to 24 splices (if applicable)
  • Supports heat-shrink or mechanical splice protectors

Installation Features

• Mounting:
  • Wall-mountable or pole-mountable options
  • Includes mounting brackets or holes
• Access:
  • Front access door with secure latching mechanism
• Grounding:
  • Integrated grounding points or lugs

Compliance and Standards

• Industry Standards:
  • Complies with Telcordia GR-326 and GR-449
  • RoHS compliant
  • IEC 61754 compliant for fiber optic interconnects

Application Areas

• Telecommunications: Suitable for central offices and network access points
• Data Centers: Ideal for fiber optic connections and patching
• FTTH: Used in Fiber to the Home installations for terminating and managing fiber connections
• Enterprise Networks: For structured cabling and interconnects

Additional Features

• Labeling:
  • Port labeling for easy identification
  • Areas for custom labels and documentation
• Security:
  • Key-locking mechanism for secure access
  • Tamper-resistant design features
• Ventilation:
  • Passive ventilation slots to prevent overheating (if applicable)
• Customization:
  • Available with various connector and adapter configurations
  • Custom colors and finishes upon request

• Fiber Type: Multimode OM3/OM4
• Core Count: 24 cores
• Core Diameter: 50/125 µm or 62.5/125 µm (depending on type)
• Outer Diameter: Typically 9.0 mm or as per design
• Cable Structure: Tight-buffered or loose tube construction
• Material: Low Smoke Zero Halogen (LSZH) or PVC jacket options
• Installation: Indoor/outdoor use
• Operating Temperature: -20°C to +70°C
• Maximum Tensile Strength: 1000 N
• Minimum Bend Radius: 10 x cable diameter
• Transmission Distance: Up to 400 meters (OM3) or 600 meters (OM4) for 10Gbps Ethernet
• Bandwidth: OM3: 2000 MHz·km; OM4: 4700 MHz·km
• Connector Type: SC, LC, or ST connectors (available options)
• Color Code: According to TIA/EIA-598 standards
• Water Blocking: Optional water-blocking features
• Application: Data centers, LAN, backbone installations, and enterprise networks
• Certification: Complies with relevant standards (ISO/IEC 11801, ANSI/TIA-568)

• Product Type: 24 Core Singlemode Un-Armoured Fibre Optic Cable
• Core Count: 24 fibers
• Fiber Type: Singlemode
• Cable Construction:
  • Loose tube design to accommodate expansion and contraction
  • No armouring, suitable for indoor and some outdoor applications
• Outer Diameter: Typically ranges from 8-12 mm (exact dimensions may vary by manufacturer)
• Material:
  • Outer jacket made from low smoke zero halogen (LSZH) or polyethylene (PE)
  • Loose tubes made from plastic materials for fiber protection
• Operating Temperature Range: -40°C to +70°C
• Bending Radius: Minimum bending radius usually 10 times the outer diameter
• Wavelength: Optimized for wavelengths of 1310 nm and 1550 nm
• Transmission Distance: Suitable for long-distance transmission with low attenuation
• Connector Type: Various options available (e.g., SC, LC, ST)
• Moisture Resistance: Designed for indoor use; may have some moisture resistance
• Compliance: Meets international standards (e.g., IEC, TIA/EIA) for singlemode fiber cables

• Core Configuration: 24 singlemode fibers
• Core Diameter: 9 µm
• Cladding Diameter: 125 µm
• Outer Diameter: Typically around 10.5 mm to 12 mm
• Armouring: Steel wire or aluminum armoured for enhanced protection
• Material: Low Smoke Zero Halogen (LSZH) or PVC outer sheath
• Maximum Attenuation:
  • ≤ 0.35 dB/km at 1310 nm
  • ≤ 0.20 dB/km at 1550 nm
• Operating Temperature Range: -40°C to +70°C
• Storage Temperature Range: -40°C to +85°C
• Tensile Strength: ≥ 1500 N
• Crush Resistance: ≥ 1500 N/100 mm
• Water Resistance: IP68 rated for submerged conditions
• Installation Method: Suitable for direct burial in underground applications
• Reinforcement: Additional moisture barriers for enhanced durability
• Applications: Telecommunications, data center interconnections, LAN/WAN backbones, FTTH deployments
• Weight: Approximately 100-120 kg/km (depending on armouring and sheath material)

General Specifications

• Product Type: Optical Distribution Frame (ODF)
• Rack Units: 1U
• Number of Ports: 24
• Connector Type: SC Duplex
• Connector Finish: UPC (Ultra Physical Contact)
• Fiber Type: Multimode (MM)

Adapter Panel

• Panel Type: Rack Mount
• Material: Cold-rolled steel with powder-coated finish
• Color: Typically black or gray
• Front Panel Ports: 24 SC Duplex adapters
• Rear Cable Management: Integrated management for efficient fiber routing and protection

Optical Performance

• Insertion Loss: ≤ 0.3 dB (typical)
• Return Loss: ≥ 50 dB for UPC
• Repeatability: ≤ 0.1 dB
• Durability: > 1000 mating cycles

Compatibility

• Fiber Modes: OM1, OM2, OM3, OM4, and OM5 compatible
• Cable Types: 50/125 μm and 62.5/125 μm multimode fibers
• Polishing Type: UPC polished connectors

Physical Dimensions

• Height: 1.75 inches (44.45 mm)
• Width: 19 inches (482.6 mm) standard rack width
• Depth: Typically around 10-12 inches (254-305 mm)

Environmental Specifications

• Operating Temperature: -40°C to +75°C
• Storage Temperature: -40°C to +85°C
• Humidity: 0% to 95% (non-condensing)

Installation Features

• Mounting: Standard 19-inch rack mountable
• Accessibility: Front access for easy installation and maintenance
• Cable Management: Includes rear cable management tray or brackets
• Labeling: Port numbering and labeling for easy identification

Compliance and Standards

• Industry Standards: Complies with TIA/EIA, IEC, and RoHS standards
• Fire Rating: Complies with UL 94V-0 flammability rating

Additional Features

• Design: Compact and lightweight design for efficient space utilization
• Security: Optional lockable doors for added security
• Accessories: Includes mounting screws, cable ties, and dust caps
• Customizability: Available in various colors and finishes upon request

• General Specifications

  • Product Type: Optical Distribution Frame (ODF)
  • Port Configuration: 24 Ports
  • Adapter Type: SC (Subscriber Connector) with UPC (Ultra Physical Contact) polish
  • Mode: Single-Mode (SM)
  • Configuration: Duplex (dual channel per port)
  • Rack Mount: 1U (one rack unit high)

  Performance Specifications

  • Insertion Loss:
    • Typically ≤ 0.3 dB per adapter
    • Maximum ≤ 0.5 dB per adapter
  • Return Loss:
    • Typically ≥ 50 dB (for UPC polish)
  • Operating Wavelength:
    • 1310 nm and 1550 nm (common for single-mode fibers)

  Connector Specifications

  • Connector Compatibility:
    • Designed for SC (Subscriber Connector) type fibers
  • Adapter Material:
    • Durable metal or plastic housing
    • High-precision ceramic or plastic sleeves for alignment
  • Sleeve Type:
    • Duplex sleeves for each port

  Mechanical Specifications

  • Durability:
    • Typically rated for ≥ 500 mating cycles per port
  • Insertion Force:
    • Designed to provide reliable connections with minimal insertion force

  Environmental Specifications

  • Operating Temperature:
    • Typically -20°C to 70°C
  • Storage Temperature:
    • Typically -40°C to 85°C
  • Humidity:
    • 95% relative humidity, non-condensing

  Rack Mounting

  • Rack Mount Type:
    • 1U rack mountable
  • Installation:
    • Designed to fit standard 19-inch racks or cabinets
  • Front Panel:
    • Includes labeled ports for easy identification and management

  Compliance and Certifications

  • Standards Compliance:
    • Meets or exceeds standards such as TIA/EIA-568 and IEC
  • Certifications:
    • RoHS compliant
    • UL Listed or similar safety certifications

  Applications

  • Network Environments:
    • Suitable for telecommunications, data centers, and local area networks (LAN)
  • Usage:
    • Ideal for organizing and managing single-mode fiber connections in a rack-mounted setup
    • Facilitates easy patching and routing of fiber optic cables within the ODF
