Hikvision Access Control

General Specifications

• Device Type: Indoor video intercom station
• Display: 7-inch color TFT LCD screen
• Resolution: 800 × 480 pixels
• Material: High-quality plastic body

Communication

• Audio Communication: Full-duplex hands-free audio
• Video Input: Supports connection to door stations
• Audio Format: G.711

Functionality

• Main Features:
  • Live view of connected door stations and cameras
  • Intercom calling and receiving functionality
  • Unlock control for connected door locks
  • Do Not Disturb mode
• Control Interface: Touch-sensitive buttons for navigation and control

Connectivity

• Interface: 4-wire analog connection
• Door Stations Supported: Compatible with Hikvision video door stations

Power Specifications

• Power Supply: 12V DC
• Power Consumption: ≤ 6W

Physical Specifications

• Dimensions: 195 mm × 132 mm × 18 mm
• Weight: Approx. 0.5 kg
• Color: White

Installation

• Mounting: Surface-mounted for wall installation
• Wiring Type: 4-wire analog

Environmental Specifications

• Operating Temperature: -10°C to 55°C (14°F to 131°F)
• Operating Humidity: 10% to 90% (non-condensing)

Special Features

• Hands-Free Operation: Enables easy communication without the need for a handset
• DND Mode: Ensures privacy when activated
• Integrated Speaker and Microphone: For clear audio communication

General Overview

• Product Name: Hikvision DS-KZX-1 Access Control Demo Case
• Purpose: Designed to showcase and demonstrate Hikvision access control products in a mobile and compact format.
• Type: Demo case for distribution and presentation.
• Ideal Use: For distributors, installers, and security professionals to demonstrate Hikvision access control solutions in a hands-on manner.

Key Features

• Portable Design: Easy to transport, making it ideal for product demonstrations at trade shows, sales meetings, or on-site client presentations.
• Integrated Components: Comes pre-installed with various Hikvision access control components, such as controllers, card readers, and other essential accessories.
• Display-Friendly: Includes clear, visible display areas to showcase key components and connections for hands-on demonstrations.
• Protection: Equipped with a durable casing to protect the devices during transport and handling.

Included Components

• Controller: Typically includes a Hikvision access control panel or controller for demonstration.
• Card Readers: Often includes several models of Hikvision card readers, such as RFID and biometric readers.
• Power Supply: Integrated power supply to power the demo setup.
• Cables: Comes with all necessary cables and connectors to set up a working demonstration.
• Display Features: Display compartments for storing and showing the devices during presentations.
• Instructions: Includes a user manual or quick-start guide for setting up and demonstrating the system.

Design and Construction

• Material: Durable and lightweight casing, often made of high-quality ABS plastic or metal for sturdiness and portability.
• Portability: Compact and lightweight, designed for ease of transport and setup.
• Size: Designed to be easily carried, with dimensions that accommodate the devices without being overly bulky.
• Locking Mechanism: Some versions include a secure locking system to protect the components during transportation.

Power and Connectivity

• Power Supply:
  • Powered through standard AC or DC adapters, depending on the configuration.
  • Support for backup battery options to ensure functionality during presentations.
• Connectivity:
  • Ports for connecting to external devices like PCs, card readers, and biometric systems.
  • Can be connected to a network to demonstrate live or remote access management.

Application

• Training and Education: Ideal for security system training or teaching users about access control solutions.
• Sales Demonstration: Aimed at sales teams or distributors, providing them with a portable solution to demonstrate products.
• Field Demonstrations: Convenient for field demonstrations, allowing security professionals to showcase solutions at client sites.

Environmental Specifications

• Operating Temperature: Typically ranges from -10°C to 55°C (14°F to 131°F).
• Humidity: Suitable for environments with humidity levels from 10% to 90% RH (non-condensing).

General Features

• Model: DS-K1T341AM
• Series: Value Series
• Device Type: Face recognition terminal for access control and time attendance
• Application: Designed for offices, residential buildings, and secure facilities

Biometric Features

• Face Recognition:
  • Supports up to 1500 face templates
  • Recognition distance: 0.3 to 1 meter
  • Recognition speed: ≤ 1 second per face
  • Face recognition accuracy rate: > 99%
• Fingerprint Recognition:
  • Supports 1500 fingerprint templates
  • Accuracy: ≤ 0.001% false acceptance rate (FAR)
  • Speed: ≤ 1 second per fingerprint
• Card Reader:
  • Supports EM cards (13.56 MHz)
  • Storage capacity: 1500 card users

Camera

• Type: Dual-lens camera with visible light and infrared sensors
• Resolution: 2 MP
• Features:
  • Anti-spoofing technology (prevents photo, video, or mask-based fraud)
  • Reliable performance in low-light conditions

Display

• Screen Size: 4.3-inch LCD touch screen
• Resolution: 480 × 272 pixels
• Interface: User-friendly touch navigation

Access Control Features

• Authentication Modes:
  • Face recognition
  • Fingerprint
  • Card access
  • Password entry
  • Multi-factor authentication (any combination of the above)
• User Capacity: Supports up to 1500 users
• Log Capacity: Stores up to 150,000 events/records
• Relay Output: For door control and access systems
• Tamper Alarm: Alerts in case of unauthorized attempts

Connectivity

• Network:
  • Supports TCP/IP for communication
  • Wi-Fi capability (optional)
• Interfaces:
  • Wiegand interface (input/output)
  • RS-485 communication port
  • USB 2.0 port for data export/import
• Power Supply: 12V DC input

Environmental and Durability Features

• Operating Temperature: -10°C to 50°C (14°F to 122°F)
• Humidity Range: 10% to 90% (non-condensing)
• Ingress Protection: IP42-rated for resistance to dust and water
• Build: Durable housing for long-lasting use

General Specifications

• Product Line: DS-K1100 Series
• Category: Proximity Card Reader
• Application: Access control systems
• Model Variants:
  • DS-K1100M: Supports MIFARE cards
  • DS-K1100E: Supports EM cards

Card Compatibility

• Card Types:
  • MIFARE (13.56 MHz) for DS-K1100M
  • EM (125 kHz) for DS-K1100E
• Read Range: Up to 50 mm

Performance Features

• Read Speed: < 0.1 seconds per card
• Communication Protocols:
  • RS-485
  • Wiegand (configurable for 26-bit or 34-bit)
• Indicator: Multi-color LED for operation status
• Buzzer: Integrated for sound notifications

Physical Specifications

• Design: Compact and sleek for indoor or outdoor installations
• Dimensions: 120 mm × 86 mm × 25 mm
• Weight: Approx. 0.3 kg
• Material: Durable polycarbonate with scratch resistance

Connectivity

• Interface Options:
  • RS-485 for direct communication
  • Wiegand output for compatibility with third-party controllers
• Wiring Distance:
  • RS-485: Up to 1200 meters with shielded twisted pair
  • Wiegand: Up to 100 meters

Environmental Specifications

• Operating Temperature: -20°C to 65°C (-4°F to 149°F)
• Operating Humidity: 10% to 90% (non-condensing)
• Ingress Protection: IP65 for outdoor use

Power Specifications

• Power Supply: 12V DC
• Power Consumption: ≤ 2W

Special Features

• Tamper Alarm: Alerts triggered by unauthorized disassembly
• LED Indicator: Multi-color LED for card recognition and status updates
• Sound Notification: Audible feedback for successful or failed operations
• Firmware Upgradable: Supports future feature enhancements

General Overview

• Product Name: Hikvision DS-K1101MK Keypad Mifare Card Reader
• Type: Combination Mifare card reader and keypad access control device
• Application: Ideal for secure access in residential, commercial, and institutional settings.

Key Features

• Card Compatibility:
  • Supports Mifare contactless smart cards for convenient and secure access.
  • Reading distance: Up to 5 cm (2 inches), depending on the card.
• Keypad:
  • 4x4 numerical keypad for PIN code entry, providing a second layer of security.
  • Up to 50,000 user PIN code capacity.
• Multi-Authentication Modes:
  • Supports multiple authentication methods including Mifare card, PIN code, or card + PIN combination.
• Visual Indicators:
  • Dual-color LED indicators (Red/Green) for access status feedback (granted or denied).
• Audio Feedback:
  • Built-in buzzer for audible confirmation of successful or failed access attempts.

Design & Build

• Material:
  • Sturdy, high-quality ABS plastic housing for durability.
• Weather Resistance:
  • IP65-rated for protection against dust and water, suitable for both indoor and outdoor installation.
• Dimensions:
  • 115 mm x 80 mm x 22 mm (H×W×D), compact and easy to install.

Connectivity

• Interfaces:
  • Wiegand (WG26/WG34) for seamless integration with access control systems.
  • RS485 for secure communication with control panels.
• Power Supply:
  • Powered by 12V DC with low energy consumption.

Security Features

• Encryption:
  • Secure communication with control systems to prevent unauthorized data access.
• Anti-Tamper Protection:
  • Built-in alarm triggered if the device is tampered with or removed.

Environmental Specifications

• Operating Temperature:
  • Supports a wide temperature range from -20°C to 65°C (-4°F to 149°F).
• Operating Humidity:
  • 10% to 90% relative humidity, non-condensing, ideal for a variety of environments.

Applications

• Suitable for a range of access control applications:
  • Office buildings
  • Residential properties
  • Gated communities
  • Educational institutions
