DS-2DE5225IW-AE Hikvision 2MP 25X IR PTZ IP Camera

Name: DS-2DE5225IW-AE Hikvision 2MP 25X IR PTZ IP Camera
Brand: Hikvision
SKU: 6857
Price: 43000 KES
Availability: InStock

in Hikvision

Sku: 6857

Write a Review

DS-2DE5225IW-AE Hikvision 2MP 25X IR PTZ IP Camera

Chat On Whatsapp

KSh 43,000 Save:KSh 2,000(4%) ( Ex VAT )

Features

Model: DS-2DE5225IW-AE
Camera Type: 2MP 25X IR PTZ IP Camera
Image Sensor:
- 1/2.8" Progressive Scan CMOS
- Effective Pixels: 1920(H)×1080(V)
Resolution:
- 2MP (1920×1080)
Video Frame Rate:
- 50Hz: 25fps (1920×1080, 1280×720)
- 60Hz: 30fps (1920×1080, 1280×720)
Minimum Illumination:
- Color: 0.005 Lux @(F1.6, AGC ON)
- B/W: 0.001 Lux @(F1.6, AGC ON)
- 0 Lux with IR
Shutter Speed: 1/1 s to 1/30,000 s
Lens:
- Optical Zoom: 25X
- Focal Length: 4.8 mm to 120 mm
- Digital Zoom: 16X
- Angle of View:
  - Horizontal: 58.3° to 2.5°
  - Vertical: 34.4° to 1.4°
  - Diagonal: 65.6° to 2.9°
- Aperture: F1.6 to F3.5
Day & Night: IR Cut Filter with Auto Switch
IR Range: Up to 100 meters (328 feet)
Pan and Tilt:
- Pan Range: 360° endless
- Pan Speed: Configurable, from 0.1° to 160°/s
- Tilt Range: -15° to 90° (auto flip)
- Tilt Speed: Configurable, from 0.1° to 120°/s
- Number of Presets: 300
- Patrol: 8 patrols, up to 32 presets per patrol
- Pattern: 4 patterns, record time over 10 minutes per pattern
Wide Dynamic Range (WDR): 120dB True WDR
Digital Noise Reduction (DNR): 3D DNR
Video Compression:
- Main Stream: H.265+/H.265/H.264+/H.264
- Sub Stream: H.265/H.264/MJPEG
Bit Rate: 32 Kbps to 16 Mbps
Audio Compression:
- G.711/G.722.1/G.726/MP2L2/AAC/PCM
Audio Input/Output:
- 1 audio input, 1 audio output
Network Protocols:
- TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, UDP, Bonjour
Simultaneous Live View: Up to 20 channels
On-board Storage:
- Built-in MicroSD/SDHC/SDXC slot, up to 256 GB
Smart Features:
- Line Crossing Detection
- Intrusion Detection
- Region of Interest (ROI)
- Motion Detection
- Unattended Baggage Detection
- Object Removal Detection
Image Settings:
- Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable via client software or web browser
Alarm:
- 7 alarm inputs, 2 alarm outputs
Operating Conditions:
- Temperature: -30°C to 65°C (-22°F to 149°F)
- Humidity: 95% or less (non-condensing)
Power Supply:
- 24 VAC
- Hi-PoE
Power Consumption: Max. 20W (IR off), Max. 30W (IR on)
Weatherproof Rating: IP66
Vandalproof Rating: IK10
Dimensions:
- Φ220 mm × 353.4 mm (Φ8.66" × 13.91")
Weight:
- Approx. 3 kg (6.61 lbs)
Mounting Options:
- Wall Mount, Ceiling Mount, Pole Mount, Corner Mount

Categories: Hikvision, Hikvision PTZ CCTV cameras, security Brand: Hikvision

Description
Reviews (0)

Description

DS-2DE5225IW-AE Hikvision 2MP 25X Network IR PTZ IP Camera

DS-2DE5225IW-AE Hikvision 2MP 25X Network IR PTZ IP Camera offers full pan/tilt functionality and a 25x optical zoom for detailed examination of outdoor locations. Hikvision 2MP 25X Network camera offers remote access is supported via Hikvision’s free iVMS-4200 video management system (VMS) and the camera can be easily installed via Power-over-Ethernet Plus (PoE+).

2MP 25X Network camera uses a 1/2.8″ progressive scan CMOS sensor to capture 1920 x 1080 resolution video at 30 fps. Smart IR provides up to 490′ of night vision. The 4.8-120mm varifocal lens delivers a 57.6 to 2.5° horizontal field of view. Hikvision 2MP 25X Network camera features endless panning, a -15 to 90° tilt range, and 25x optical zoom.

An onboard memory card slot accepts microSD/SDHC/SDXC cards up to 256GB (available separately). DS-2DE5225IW-AE PTZ Integrated PoE technology simplifies connectivity by enabling the transfer of power and data through a single cable. This PTZ camera complies with ONVIF profiles S and G, making it compatible with a wide range of surveillance devices. It is IP66 rated for outdoor use.

Hikvision DS-2DE5225IW-AE Specs

Camera
Sensor	2 MP 1/2.8″ CMOS
Focal Length	4.8 to 120mm
Maximum Aperture	f/1.5 – f/3.5
Zoom	Optical: 25x Digital: 16x
Lens Field of View	Horizontal: 57.6 to 2.5° Vertical: 34.4 to 1.4° Diagonal: 64.5 to 2.9°
IR Cut Filter	Mechanical
Day/Night	Yes
Minimum Illumination	Color: 0.005 Lux B&W: 0 Lux
Shutter Speed	1/30,000 to 1 Seconds

Video
Streaming Resolution	1920 x 1080 at 30 fps (16.384 Mb/s )
Supported Video Compression	H.264, H.264+, H.265, H.265+, MJPEG
Multi-View Streaming	Yes, 3 Streams
Automatic Gain Control	Yes

Networking
Security	Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, MAC Address Filtering
Supported Protocols	Bonjour, DDNS, DHCP, DNS, FTP, HTTP, IPv4/v6, NTP, PPPoE, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), TCP, UPnP

System Integration
Application Programming Interface (API)	Open API Supports ONVIF Profiles S & G, ISAPI, CGI, Hikvision SDK, and Third-Party Management Platforms
Analytics	Motion Detection Video Tampering Detection Exception Detection Intrusion Detection Line Crossing Detection Region Entrance Detection Region Exiting Detection Object Removal Detection Unattended Baggage Detection
Event Trigger	Yes
Event Action	Recording, Notification, Alarm
Data Streaming	Yes

System Requirements
Mobile Operating Systems	iOS, Android
Operating Temperature	-22 to 149°F / -30 to 65°C
Operating Humidity	0 to 90%
IP Rating	IP66

General
Recording Media	microSD (Up to 256 GB)
Pan/Tilt	Manual Pan: 360° at 210°/s Programmed Pan: 360° at 120°/s Manual Tilt: 105° (-15 to 90°) at 80°/s Programmed Tilt: 105° (-15 to 90°) at 80°/s
I/O Connections	1 x Power 1 x RJ45
IR Range	490′ / 149.35 m
Video Management Software	iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Internal Storage	None
External Storage Options	NAS
Power Source	AC, PoE 802.3at (30 W)
Power Consumption	30 W
Material of Construction	Aluminum, Polymer
Dimensions	ø: 8.2 x H: 13.6″ / ø: 208.0 x H: 345.0 mm
Weight	7.28 lb / 3.3 kg
