Fanvil V61G Entry Level IP Phone

Fanvil V61G Entry Level IP Phone

The Fanvil V61G delivers essential VoIP functionality designed for budget-conscious businesses. This entry-level model features a monochrome display and streamlined interface that prioritizes core telephony functions.

Core Communication Features

The V61G supports two SIP accounts simultaneously. This dual-account capability allows users to manage separate business lines or departments from a single device. Additionally, the phone integrates three-way conferencing functionality directly into its operating system.

Display and User Interface

A 2.4-inch monochrome LCD screen provides clear caller information and menu navigation. The display shows essential call details including caller ID, call duration, and phone status indicators. Furthermore, the interface uses intuitive icons that reduce training time for new users.

Network Connectivity

Ethernet Integration: The V61G includes dual Gigabit Ethernet ports supporting 10/100/1000 Mbps speeds. One port connects to your network switch while the second provides passthrough connectivity for a computer or additional device.

Power Options: The device supports both Power over Ethernet (PoE) and external power adapter configurations. PoE capability eliminates the need for separate power cables in most installations.

Audio Technology

The handset incorporates HD audio codecs including G.722 and G.711. These codecs ensure clear voice transmission across various network conditions. Moreover, the speakerphone function supports hands-free conversations with noise reduction algorithms.

Programmable Functions

Six programmable keys provide quick access to frequently used features. Users can configure these buttons for speed dial, line monitoring, or feature activation. Similarly, the phone supports up to 100 contacts in its internal directory.

Target Users

The Fanvil V61G best serves:

• Small office receptionists – Dual SIP account support allows handling of multiple business lines efficiently
• Budget-conscious startups – Entry-level pricing without sacrificing essential VoIP features
• Remote workers – Compact design (7.9″ x 7.1″ x 3.5″) fits easily in home office spaces
• Basic desk users – Monochrome display and simplified interface reduce complexity for users who primarily make/receive calls
• Temporary installations – PoE support enables quick deployment without additional power infrastructure

Technical Specifications

Display & Interface

• Screen: 2.4-inch monochrome LCD
• Resolution: 128 x 64 pixels
• Programmable keys: 6 with LED indicators
• Navigation: 4-way directional pad with center select button

Network & Connectivity

• Ethernet ports: Dual 10/100/1000 Mbps
• Network protocols: SIP v2.0 (RFC3261), TCP/UDP/TLS
• NAT traversal: STUN, TURN, ICE support
• VLAN: 802.1Q VLAN tagging

Audio Specifications

• Codecs: G.711 (a-law, μ-law), G.722, G.729A/B, G.726, iLBC
• Frequency response: 300-3400Hz (handset), 300-7000Hz (speakerphone)
• Echo cancellation: ITU-T G.168 compliant
• DTMF: In-band, Out-of-band, SIP INFO

Power & Physical

• Power consumption: 3W maximum
• Power supply: PoE (802.3af) or 12V/1A external adapter
• Dimensions: 201 x 180 x 89 mm (7.9″ x 7.1″ x 3.5″)
• Weight: 0.8 kg (1.76 lbs)
• Operating temperature: 0°C to 40°C (32°F to 104°F)

SIP & Call Features

• SIP accounts: 2 concurrent registrations
• Call features: Hold, transfer, forward, waiting, conference (3-way)
• Directory capacity: 1000 entries
• Call history: 100 records each (dialed, received, missed)
• Speed dial: 100 entries
