The Fanvil X3SP 2-Line PoE IP Phone is a versatile and cost-effective telephony solution designed for small to medium-sized businesses. This phone combines essential features with user-friendly functionality, making it an ideal choice for efficient communication.

Key Features and Functionality:

• Display and User Interface: The X3SP is equipped with a 2.4-inch color display (320×240 resolution) that provides a clear and intuitive interface. The display is complemented by 2 programmable soft keys and 2 dedicated line keys with LED indicators for easy access to frequently used functions and monitoring call status.

• High-Quality Audio: Designed for clear and reliable communication, the X3SP supports HD voice technology on both the handset and speakerphone. It features a full-duplex speakerphone with acoustic echo cancellation (AEC) and wideband audio support, ensuring high-quality audio. The phone supports a variety of voice codecs, including G.711, G.722, G.726, G.729AB, and iLBC, for optimal performance.

• Connectivity and Power: The X3SP offers dual 10/100 Mbps Ethernet ports and supports Power over Ethernet (PoE) (IEEE 802.3af), which simplifies installation by reducing the need for additional power cables. It also includes RJ9 ports for connecting a wired headset and the handset.

• Functionality: With support for up to 2 SIP lines, the X3SP allows users to manage multiple calls and lines efficiently. It features 3 programmable function keys and dedicated keys for headset, speakerphone, mute, and hold functions. The phonebook can store up to 500 contacts, and the device supports web-based management for easy configuration.

• Security and Management: The X3SP includes robust security features such as SRTP/TLS for encrypted voice and signaling, HTTPS for secure web access, and 802.1x network access control. It also supports auto-provisioning via FTP/TFTP/HTTP/HTTPS and remote management through TR-069 and SNMP, simplifying device setup and maintenance.

• Physical Design: The phone is designed to operate in a temperature range of 0-45°C (32-113°F) and a humidity range of 10-95% (non-condensing). Its compact dimensions (210x185x95 mm without stand) and lightweight design (approximately 0.9 kg) make it suitable for various office environments.

The Fanvil X3SP 2-Line PoE IP Phone offers a practical and efficient solution for modern business communication needs. Its blend of essential features, high-quality audio, and robust security ensures reliable performance and ease of use in any office setting.
