Camera Specifications

• Model: DS-2CD2625FWD-IZ(S)
• Image Sensor: 1/2.8″ Progressive Scan CMOS
• Minimum Illumination:
  • Color: 0.01 Lux @ (F1.2, AGC ON)
  • B/W: 0.001 Lux @ (F1.2, AGC ON)
  • 0 Lux with IR
• Shutter Speed: 1/3 s to 1/100,000 s
• Lens:
  • Type: Motorized Varifocal Lens
  • Focal Length: 2.8 mm to 12 mm
  • Aperture: F1.2
  • Field of View:
    • Horizontal: 102° to 33°
    • Vertical: 55° to 18°
    • Diagonal: 120° to 40°
• Day & Night: IR cut filter with auto switch
• IR Range: Up to 40 meters (131 feet)
• Wide Dynamic Range (WDR): 120 dB

Video Specifications

• Max Resolution: 1920 × 1080 (2 MP)
• Main Stream:
  • 50 Hz: 25 fps (1920 × 1080, 1280 × 720)
  • 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
• Sub Stream:
  • 50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
  • 60 Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
• Third Stream:
  • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240)
  • 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240)
• Video Compression:
  • Main Stream: H.264+/H.264
  • Sub Stream: H.264+/H.264
  • Third Stream: MJPEG
• Bit Rate: 32 Kbps to 16 Mbps

Image Enhancements

• 3D Digital Noise Reduction (3D DNR): Yes
• Backlight Compensation (BLC): Yes
• Highlight Compensation (HLC): Yes
• Defog: Yes
• Electronic Image Stabilization (EIS): Yes
• Region of Interest (ROI): Up to 4 fixed regions for each stream
• Image Settings:
  • Saturation, brightness, contrast, and sharpness adjustable via client software or web browser

Network

• Ethernet: 1 RJ45 10M/100M/1000M self-adaptive Ethernet port
• Protocols Supported: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
• Network Storage: NAS (NFS, SMB/CIFS), ANR
• Security Features:
  • User authentication
  • Watermark
  • IP address filtering
  • Basic and digest authentication for HTTP/HTTPS
  • TLS 1.2 for HTTPS
  • HTTPS, AES-128, AES-256 encryption
  • H.264+ for enhanced encoding performance

Alarm & Event

• Alarm Input/Output: 1 input, 1 output
• Alarm Triggers: Motion detection, video tampering alarm, network disconnection, IP address conflict, illegal login, HDD full, HDD error
• Event Notification: Alarm output, e-mail, FTP, HTTP listening, NAS, SD card (with optional MicroSD/SDHC/SDXC card slot)

Storage

• Built-in Storage: MicroSD/SDHC/SDXC card slot, up to 128 GB

Interface

• Audio:
  • Input: 1 audio input, 3.5 mm interface, Mic in/Line in
  • Output: 1 audio output, 3.5 mm interface, Line out
• RS-485 Interface: 1
• Reset Button: Yes

Smart Features

• Smart Event Detection:
  • Line crossing detection
  • Intrusion detection
  • Object removal detection
  • Unattended baggage detection
  • Scene change detection

Physical & Environmental

• Weatherproof Rating: IP67
• Vandal-Proof Rating: IK10
• Operating Temperature: -30°C to 60°C (-22°F to 140°F)
• Operating Humidity: 95% or less (non-condensing)
• Power Supply:
  • 12 VDC ± 25%
  • PoE (802.3at, Class 4)
• Power Consumption:
  • 12 VDC, max. 12 W
  • PoE, max. 15 W
• Dimensions: 120 × 265 mm (4.72″ × 10.43″)
• Weight: Approx. 1.3 kg (2.87 lbs)

Additional Features

• EXIR Technology: Enhanced IR for better night vision
• Motorized Zoom Lens: Allows remote focus and zoom adjustments
• Installation Options: Wall or pole mount
