Hikvision DS-2CD2942F-(I) 4MP Compact Fisheye Network Camera

General Information

• Product Type: 4MP Compact Fisheye Network Camera
• Model: DS-2CD2942F-(I)
• Resolution: 4MP (2560 × 1440)
• Video Format: H.265+, H.265, H.264+, H.264

Camera

• Image Sensor: 1/1.7″ Progressive Scan CMOS
• Lens:
  • Fisheye lens with a 180° or 360° panoramic view
• Field of View:
  • 180° or 360° (depending on the mounting orientation)
• Day/Night Mode:
  • Automatic IR cut filter (ICR)
• WDR (Wide Dynamic Range): 120 dB
• Noise Reduction: 3D DNR (Digital Noise Reduction)

Video

• Video Output:
  • Digital IP video stream
• Video Compression:
  • H.265+, H.265, H.264+, H.264
• Frame Rate:
  • Up to 30 fps at 4MP
• Bit Rate:
  • Adjustable, with options for constant bit rate or variable bit rate

Network & Connectivity

• Network Interface:
  • 1 × Ethernet port (10/100/1000 Mbps)
• Protocols Supported:
  • TCP/IP, DHCP, DDNS, SMTP, NTP, UPnP, RTP, RTSP
• Remote Access:
  • Mobile app (Hik-Connect or iVMS-4500)
  • Web browser interface (via Hikvision’s software)

Features

• Motion Detection:
  • Configurable motion detection areas
• Alarm Integration:
  • Support for alarm inputs and outputs
• Tamper Detection:
  • Alerts if camera is tampered with
• Privacy Masking:
  • Up to 4 configurable privacy zones
• ROI (Region of Interest):
  • Adjustable to improve image quality in specific areas
• ONVIF Compliance:
  • For integration with third-party NVRs
• E-PTZ (Electronic PTZ):
  • Digital pan-tilt-zoom functionality

Physical Specifications

• Housing:
  • Compact design suitable for discreet installation
  • Weatherproof (typically IP66)
• Dimensions:
  • Approximately 95 × 95 × 70 mm (3.7 × 3.7 × 2.8 inches)
• Weight:
  • Approximately 0.4 kg (0.9 lbs)

Power

• Power Supply:
  • 12V DC ± 25% or PoE (Power over Ethernet, IEEE 802.3af)
• Power Consumption:
  • Typically 6-10W
• Backup Power:
  • None (direct power or PoE required)

Environmental

• Operating Temperature:
  • -30°C to 60°C (-22°F to 140°F)
• Operating Humidity:
  • 10% to 90% (non-condensing)

Accessories

• Included Items:
  • Mounting bracket
  • User manual
• Optional Items:
  • Additional mounting accessories
  • Surge protectors

Applications

• Use Cases:
  • Indoor surveillance
  • Retail and commercial spaces
  • Office and public areas monitoring

Price Range

• Price Range:
  • $300 to $500 USD depending on supplier and quantity
• Best Price:
  • Prices can vary; check online retailers or local distributors for current pricing
