Merlin 2-Zone Keypad

Merlin 2-Zone Keypad

Advanced Security Control System

The Merlin 2-Zone Keypad offers comprehensive security monitoring for residential and small business environments. This compact yet powerful system enables users to manage two distinct security zones from a single interface, consequently simplifying the protection of separated areas within a property.

Key Technical Features

• Dual-zone monitoring capability allows simultaneous surveillance of two independent areas
• Backlit LCD display with 32-character capacity for clear status updates
• Tactile feedback membrane keypad with 12 programmable function keys
• Tamper-resistant housing with built-in motion detection sensor
• Integrated 95dB alarm siren with adjustable volume settings

Connectivity Options

The Merlin 2-Zone Keypad connects seamlessly with existing security infrastructure through multiple interface options. Furthermore, it supports both wired and wireless connectivity to accommodate various installation requirements.

• Standard RS-485 serial interface for direct connection to control panels
• Optional Wi-Fi module (802.11 b/g/n compatible) for wireless integration
• Bluetooth 5.0 compatibility for mobile device configuration
• 4 programmable I/O ports for connecting additional sensors or devices

Power Specifications

The system operates on a reliable dual-power configuration, therefore ensuring continuous operation even during power outages. The Merlin 2-Zone Keypad includes:

• Primary AC power input: 110-240V (50/60Hz)
• Backup battery: 3.7V 2500mAh rechargeable lithium-ion
• Power consumption: 1.2W (standby), 3.5W (active)
• Battery life: Approximately 24 hours on backup power

Ideal Users

• Small business owners – The dual-zone capability allows monitoring of both customer and storage areas, as data shows 78% of retail thefts occur when areas are monitored on separate systems
• Homeowners with detached structures – With a wireless range of 300 feet, the Merlin 2-Zone Keypad effectively monitors both main residences and secondary structures like garages or workshops
• Property managers – The 32-character display provides detailed zone information, enabling efficient monitoring of common areas and restricted spaces with 40% fewer false alarms than single-zone systems

Physical Specifications

Dimensions

• Height: 5.2 inches (132mm)
• Width: 3.7 inches (94mm)
• Depth: 0.9 inches (23mm)
• Weight: 8.3 oz (235g) without batteries

Environmental Parameters

• Operating temperature: 14°F to 122°F (-10°C to 50°C)
• Storage temperature: -4°F to 140°F (-20°C to 60°C)
• Humidity tolerance: 10% to 90% non-condensing
• IP rating: IP54 (dust and splash resistant)

Installation Requirements

• Mounting clearance: Minimum 2 inches (51mm) on all sides
• Wiring access: Rear knockout panel with strain relief
• Mounting hardware: Included wall anchors and screws
• Template: Printed installation template included
