Panasonic Extension Cards for KX-TDA100 DBP
Modular Expansion Solutions for Enterprise Communication Systems
The Panasonic Extension Cards for KX-TDA100 DBP provide flexible capacity expansion options for your Panasonic KX-TDA100 Digital Hybrid IP-PBX system. These purpose-built cards allow system administrators to customize their telecommunications infrastructure according to specific organizational requirements. Each card type serves a distinct function within the KX-TDA100 DBP framework, enabling incremental scaling of capabilities.
Digital Extension Card Options
The KX-TDA100 DBP supports multiple digital extension card variants, each designed to accommodate different terminal densities:

DLC8 card supports 8 digital extension ports
DLC16 card supports 16 digital extension ports
DHLC8 card combines 8 digital extensions with hybrid functionality

These digital extension cards connect seamlessly with Panasonic’s DT/KX series proprietary digital handsets. Additionally, the DHLC8 card offers hybrid capability, supporting both digital extensions and analog devices on the same card.
Analog Extension Capabilities
For environments requiring analog device integration, the Panasonic Extension Cards for KX-TDA100 DBP include:

SLC8 card accommodates 8 single line telephone devices
SLC16 card supports 16 single line telephone connections
MSLC16 card provides 16 single line connections with message waiting functionality

Each analog card features surge protection and caller ID compatibility. Moreover, the MSLC16 card adds message waiting indication support for compatible analog telephones.
IP Extension Integration
The IP Extension Cards expand the KX-TDA100 DBP system into IP-based communications:

IP-EXT16 card supports 16 IP proprietary telephones
DSP16 card provides 16 channels of VoIP resource capacity
DSP64 card delivers 64 channels of VoIP resource capacity

These cards facilitate integration with Panasonic’s IP-proprietary phones and SIP-based devices. Furthermore, the DSP cards enable VoIP compression codecs including G.711, G.729a, and G.722 for high-definition voice.
Ideal Users for Panasonic Extension Cards for KX-TDA100 DBP

Medium-sized businesses (50-100 employees) benefit from the modular expansion capabilities, allowing gradual system growth without replacing the core PBX
Multi-location organizations can leverage the IP extension cards’ 16-64 channel capacity to create unified communications across geographic boundaries
Hybrid work environments gain flexibility through the DHLC8 card’s dual-purpose functionality, supporting both digital and analog devices simultaneously
Call centers appreciate the scalability of adding 8-16 extensions per card to match changing staffing requirements

Compatibility and Installation
The Panasonic Extension Cards for KX-TDA100 DBP install directly into the expansion slots of the KX-TDA100 main cabinet. The system accommodates up to 11 extension cards in various configurations. Each card uses the proprietary Panasonic connection interface for guaranteed compatibility and performance with the KX-TDA100 DBP system.
Physical Specifications

Form factor: Proprietary Panasonic expansion card
Dimensions: 250mm x 90mm x 25mm (standard card size)
Connection interface: Panasonic proprietary connector
Installation type: Slot-based internal installation
Maximum cards per system: 11 extension cards

Technical Capabilities

Digital extension support: Up to 128 digital extensions
Analog extension support: Up to 128 analog devices
IP extension support: Up to 128 IP extensions
Power consumption: 3-5W per card (varies by model)
Firmware upgradeable: Yes, via system software updates

Environmental Specifications

Operating temperature: 0°C to 40°C
Operating humidity: 10% to 90% non-condensing
MTBF (Mean Time Between Failures): >100,000 hours
Warranty: 2-year manufacturer warranty
Regulatory compliance: FCC, CE, RoHS
