Authentication Options

• Fingerprint recognition, RFID card, and password authentication.
• Fingerprint capacity: Stores up to 500 fingerprints.
• Card capacity: Supports 500 RFID cards (125kHz EM).
• Password capacity: Allows for 8 user passwords.
• Supports multi-factor authentication (combination of fingerprint, card, and/or password).

Access Control Features

• Standalone operation: No need for a separate control panel.
• Built-in relay for door lock control.
• Tamper alarm to protect against unauthorized tampering.
• Wiegand 26 output for integration with third-party access control systems.
• Configurable anti-passback for enhanced security.
• Response time: ≤ 1 second.

Keypad & Interface

• Capacitive touch keypad with numeric input for passwords and settings.
• LED indicators and audio prompts for user feedback.
• Simple user enrollment via keypad interface.

Design & Durability

• Compact and stylish design suitable for modern interiors.
• Material: Durable ABS plastic construction.
• Operating temperature: -10°C to 60°C.
• Operating humidity: 20% to 80%.
• IP54 rating for limited water and dust resistance, suitable for indoor environments.

Connectivity

• Supports Wiegand input/output for seamless integration.
• Directly connects to door locks, exit buttons, and alarm devices.
• Standalone mode or integration into larger access systems.

Power Requirements

• Input voltage: 12V DC.
• Current draw: Less than 50mA (standby).

Physical Dimensions

• Dimensions: 88mm x 88mm x 33.6mm (H x W x D).
• Lightweight design for easy installation.

General Specifications:

• Model: ZK-D2180S
• Type: Walk-through metal detector
• Detection Zones: 18 independent detection zones for precise location pinpointing
• Weight: 70 kg (standard)

Metal Detection Performance:

• Detection Sensitivity: Adjustable sensitivity levels for detecting various metallic objects, from small items to larger weapons
• Detection Accuracy: Accurate multi-zone detection for precise identification of the location of metallic objects
• Alarm Modes:
  • Visual alarm through LED indicators
  • Audible alarm with adjustable volume
• LED Indicators: Located on both sides of the frame to indicate detection zones

User Access & Security:

• Password Protection: Secure password access to prevent unauthorized changes to configuration settings
• Tamper Detection: Built-in anti-tamper features to protect against unauthorized manipulation

Power & Environment:

• Power Supply: AC 100–240V, 50/60Hz
• Power Consumption: <15W
• Operating Temperature: -20°C to 50°C (-4°F to 122°F)
• Operating Humidity: 0%–95% (non-condensing)

Construction & Design:

• Dimensions:
  • Exterior: 2220 mm (H) x 820 mm (W) x 500 mm (D)
  • Interior passageway: 2000 mm (H) x 700 mm (W)
• Material: High-strength, durable metal frame for extended service life
• Portability: Modular design for easy installation, disassembly, and relocation

Display & Interface:

• Display: Integrated LCD screen for real-time status, settings, and configuration monitoring
• Control Panel: Button-based or touch controls for configuration

Key Features:

• 18 Detection Zones: Provides precise multi-zone detection for accurate identification of metallic items' location
• Multi-Frequency Operation: Reduces interference from external electromagnetic sources, ensuring reliable performance
• Password Protection: Prevents unauthorized access and ensures secure operation
• Adjustable Sensitivity: Allows customization for different levels of security requirements
• Safe for All: Non-invasive operation, safe for individuals with medical implants

• Authentication Methods:

  • Supports fingerprint, face, and palm vein recognition for multi-modal authentication.
  • Offers flexible authentication with options for fingerprint + face, fingerprint + palm vein, or face + palm vein.

• Fingerprint Capacity:

  • Stores up to 10,000 fingerprint templates for efficient user management.

• Face Recognition:

  • Capable of storing up to 5,000 face templates for identification.
  • Face recognition speed: < 1 second per user.
  • Infrared (IR) Camera for high accuracy even in low-light conditions.

• Palm Vein Recognition:

  • Stores up to 5,000 palm vein templates.
  • Non-contact recognition for added hygiene and comfort.

• User Capacity:

  • 10,000 users can be stored in total, combining fingerprint, face, and palm vein templates.

• Display:

  • 8-inch color TFT touchscreen for user interaction and device configuration.
  • Supports multi-language display options for global use.

• Communication:

  • TCP/IP and Wi-Fi for network connectivity and remote management.
  • RS485 and USB for offline communication and data transfer.
  • Wiegand input/output for integration with external systems.

• Power Supply:

  • Operates on DC 12V, with optional PoE (Power over Ethernet) for easier installation.
  • Backup battery for emergency power supply (depending on model).

• Security Features:

  • Data encryption for secure communication and protection of biometric data.
  • Anti-spoofing technology to detect fake biometric inputs (e.g., fake fingerprints or photos).
  • Tamper detection for monitoring device integrity and physical security.

• Access Control Features:

  • Time zones and access schedules for controlling when users can access secured areas.
  • Supports multi-level access control for administrators, employees, and visitors.
  • Built-in door relay and alarm outputs for complete access control solutions.

• Audit Logs:

  • Stores audit trails of access events, including user information, date, and time.
  • Real-time logging and event reporting for security monitoring and compliance.

• Integration:

  • Compatible with ZKTeco’s software for easy configuration and user management.
  • Can be integrated with existing access control systems and time attendance software.

• Environmental Conditions:

  • Operating temperature: 0°C to 45°C.
  • Humidity range: 20% to 80% (non-condensing).
  • Designed for both indoor and outdoor use (weather-resistant models available).

• Controller Type:

  • Standalone Access Controller
  • Networked Access Control System

• Supported Devices:

  • Fingerprint
  • RFID
  • Card Reader (EM/Mifare)
  • PIN Code

• Authentication Methods:

  • Fingerprint Recognition
  • RFID Card (EM/Mifare)
  • PIN Code

• Capacity:

  • User Capacity: 30,000 users
  • Transaction Log Capacity: 100,000 records

• Communication and Connectivity:

  • Network: TCP/IP
  • USB: For data transfer and backup
  • Wiegand Input: For connecting external devices (e.g., card readers)
  • Wiegand Output: For integration with third-party devices
  • Relay Output: For controlling access mechanisms (e.g., door locks)

• Input/Output Ports:

  • 2 Door Output (Relay)
  • 2 Door Input (Request to Exit / Door Contact)
  • 1 Alarm Output
  • 1 Relay Output for Door Locking

• Power and Consumption:

  • Power Supply: DC 12V
  • Power Consumption: 3W

• Environmental Conditions:

  • Operating Temperature: 0°C to 45°C
  • Operating Humidity: 20% to 80% (non-condensing)

• Advanced Features:

  • Support for Biometric and RFID Authentication: Flexible access control options
  • Multiple Door Control: Allows for control of up to two doors
  • Time Zone Management: Time-based access control settings
  • Automatic Lock Release: Can release the door lock during specific conditions or emergencies
  • Emergency Alarm: Provides alarm output during unauthorized access attempts

• Design and Build:

  • Compact, rack-mounted design
  • Dimensions: 184mm x 138mm x 30mm
  • Weight: 0.5 kg

• Software Compatibility:

  • Compatible with ZKTeco's ZKBioSecurity for centralized management of access control systems
  • Real-time Monitoring: Provides live updates for system status, logs, and access events

• Access Control:

  • Supports EM and Mifare RFID cards
  • Card Capacity: 50,000 users (EM or Mifare)
  • Transaction Log Capacity: 100,000 records

• Communication and Connectivity:

  • Network Connectivity: TCP/IP, RS-485
  • USB Host for data backup and firmware updates
  • Wiegand Input/Output for compatibility with third-party devices
  • Relay Output for integration with door locks and other peripherals

• Power and Consumption:

  • Power Supply: DC 12V
  • Power Consumption: ≤ 3W (idle)
  • Standby Current: <50mA

• Card Reader:

  • Supports EM 125 kHz and Mifare 13.56 MHz cards
  • Reading Distance: 5-10 cm (depending on the card)

• Security and Features:

  • Tamper Detection: Integrated alarm system
  • Relay Output: Supports electric lock, door sensor, exit button
  • Input Options: Door status, alarm input, exit button input

• Environmental and Durability:

  • Operating Temperature: 0°C to 45°C
  • Operating Humidity: 20% to 80% (non-condensing)
  • IP Rating: IP65 for dust and water resistance

• Compatibility:

  • Compatible with ZKTeco BioSecurity and ZKBioAccess software for centralized control
  • Supports integration with third-party access control and security systems

• Dimensions:

  • Size: 160mm x 110mm x 27mm
  • Weight: 0.28 kg

•

General Features:

• Model: ZKTeco CR60W
• Type: RFID USB Reader
• Application: Designed specifically for hotel management systems for room access, keycard management, and guest services
• Interface: USB 2.0 for easy connectivity with hotel management software or POS systems
• Compatibility: Compatible with Windows and Linux operating systems
• Functionality: Designed for reading RFID-enabled room key cards and providing access to hotel rooms or other restricted areas
• Usage: Ideal for hotel front desks, reception, security systems, and room access

RFID Technology:

• Frequency: Operates on the 13.56 MHz RFID frequency
• Card Type Support:
  • Supports Mifare 1K, Mifare 4K, Mifare Ultralight, Mifare Plus, and other compatible cards
  • Can read both RFID cards and tags
• Reading Range: Up to 5 cm for reliable card reading at close range
• Card Compatibility: Compatible with ISO 14443A/B standard cards
• RFID Reading Speed: Fast card reading with minimal delay for efficient operations

Physical Specifications:

• Design: Compact and ergonomic design for easy placement and handling at hotel front desks or kiosks
• Material: Made with high-quality, durable plastic housing
• Dimensions:
  • Length: 90 mm
  • Width: 55 mm
  • Height: 15 mm
• Weight: Lightweight and easy to handle, weighing around 100g

Power and Connectivity:

• Power Supply: Powered directly via USB connection (no external power supply required)
• USB Port: USB 2.0 interface for both power and data transmission
• Connection Type: Plug-and-play functionality with no additional drivers required for most systems
• Cable Length: 1.5 meters cable for flexible installation options

Software and Integration:

• Hotel Management Integration: Specifically designed to integrate with hotel management software for secure guest access control, room management, and billing systems
• SDK Availability: Provides an SDK (Software Development Kit) for easy integration into custom hotel management applications
• Real-Time Data Processing: Allows real-time updates of guest card access to hotel management systems

Security and User Features:

• Card Encoding: Supports encoding and writing information onto RFID cards (e.g., room number, access time, guest details)
• Security Protocol: Ensures secure communication between the RFID reader and the card to prevent unauthorized access
• Error Indicators: LED indicator to show successful or unsuccessful card reads
