• Horizontal: 70.9°
• Vertical: 39.3°
• Diagonal: 79.3°

• Color: 0.01 Lux @ (F1.2, AGC ON)
• B/W: 0.008 Lux @ (F1.2, AGC ON)

• TVI: 720p@25fps/720p@30fps

• Digital Noise Reduction (DNR): 3D DNR
• Backlight Compensation (BLC): Yes
• Highlight Compensation (HLC): Yes

• AGC (Automatic Gain Control): Yes
• White Balance: Auto
• Brightness: Adjustable via menu
• Sharpness: Adjustable via menu
• Mirror: On/Off

• Camera Module: 40 mm × 40 mm × 11.6 mm (1.57" × 1.57" × 0.46")
• Separate Camera Unit: 43 mm × 41 mm × 11.6 mm (1.69" × 1.61" × 0.46")

Camera Specifications

• Model: DS-2DE2A204IW-DE3
• Type: IP PTZ (Pan-Tilt-Zoom) Camera
• Image Sensor: 1/2.8" Progressive Scan CMOS
• Resolution: 4 MP (2560 × 1440)
• Lens:
  • Type: Motorized Varifocal Lens
  • Focal Length: 2.8-12 mm
  • Aperture: F1.6-F2.8
  • Field of View:
    • Horizontal: 96.3° - 30.8°
    • Vertical: 52.7° - 17.4°
• Optical Zoom: 4x optical zoom
• Digital Zoom: Up to 16x
• Day & Night: True Day/Night with IR cut filter
• Minimum Illumination:
  • Color: 0.005 Lux @ (F1.6, AGC ON)
  • B/W: 0 Lux with IR
• Infrared (IR) Range: Up to 50 meters (164 feet)
• Wide Dynamic Range (WDR): 120 dB
• Pan Range: 0° to 360° endless
• Tilt Range: -15° to 90°
• Zoom Control: Motorized lens with PTZ control

Video Specifications

• Max Resolution: 2560 × 1440 (4 MP)
• Main Stream:
  • 50 Hz: 25 fps (2560 × 1440, 1920 × 1080)
  • 60 Hz: 30 fps (2560 × 1440, 1920 × 1080)
• Sub Stream:
  • 50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
  • 60 Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
• Video Compression:
  • Main Stream: H.265+/H.265, H.264+/H.264
  • Sub Stream: H.264+/H.264
• Bit Rate: 32 Kbps to 16 Mbps

Image Enhancements

• 3D Digital Noise Reduction (3D DNR): Yes
• Backlight Compensation (BLC): Yes
• Highlight Compensation (HLC): Yes
• Defog: Yes
• Electronic Image Stabilization (EIS): Yes
• Region of Interest (ROI): Up to 4 fixed regions for each stream
• Image Settings:
  • Saturation, brightness, contrast, and sharpness adjustable via client software or web browser

Network

• Ethernet: 1 RJ45 10M/100M/1000M self-adaptive Ethernet port
• Protocols Supported: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
• Network Storage: NAS (NFS, SMB/CIFS), ANR
• Security Features:
  • User authentication
  • Watermark
  • IP address filtering
  • Basic and digest authentication for HTTP/HTTPS
  • TLS 1.2 for HTTPS
  • HTTPS, AES-128, AES-256 encryption
  • H.265+ for enhanced encoding performance

Alarm & Event

• Alarm Input/Output: 1 input, 1 output
• Alarm Triggers: Motion detection, video tampering alarm, network disconnection, IP address conflict, illegal login, HDD full, HDD error
• Event Notification: Alarm output, e-mail, FTP, HTTP listening, NAS, SD card (with optional MicroSD/SDHC/SDXC card slot)

Storage

• Built-in Storage: MicroSD/SDHC/SDXC card slot, up to 256 GB

Interface

• Audio:
  • Input: 1 audio input, 3.5 mm interface, Mic in/Line in
  • Output: 1 audio output, 3.5 mm interface, Line out
• RS-485 Interface: 1
• Reset Button: Yes

Smart Features

• Smart Event Detection:
  • Line crossing detection
  • Intrusion detection
  • Object removal detection
  • Unattended baggage detection
  • Scene change detection

Physical & Environmental

• Weatherproof Rating: IP66
• Vandal-Proof Rating: IK10
• Operating Temperature: -30°C to 60°C (-22°F to 140°F)
• Operating Humidity: 95% or less (non-condensing)
• Power Supply:
  • 24 V AC ± 25%
  • PoE (802.3at, Class 4)
• Power Consumption:
  • 24 V AC, max. 36 W
  • PoE, max. 45 W
• Dimensions: 229 × 143 × 335 mm (9.02" × 5.63" × 13.19")
• Weight: Approx. 2.6 kg (5.73 lbs)

Additional Features

• PTZ Control: 360° pan and -15° to 90° tilt with motorized zoom
• Installation Options: Wall or ceiling mount
• Color: White

Image Sensor:

• 1/2.8" Progressive Scan CMOS
• 2MP (1920x1080) resolution

Lens:

• 25x optical zoom lens
• Focal length: 4.8mm to 120mm
• Horizontal field of view: 57.3° to 2.5°
• Auto focus with manual zoom and focus adjustment

Low Light Performance:

• DarkFighter technology for enhanced low-light performance
• Minimum illumination:
  • Color: 0.005 lux (F1.6, AGC ON)
  • B/W: 0.0005 lux (F1.6, AGC ON)

IR Illumination:

• Built-in IR LEDs with a range of up to 100 meters (328 ft)
• Smart IR for adaptive illumination intensity adjustment based on zoom level

Pan & Tilt:

• Pan: 0° to 360° endless rotation
• Tilt: -15° to 90° (Auto flip)
• Pan Speed: 0.1° to 60° per second
• Tilt Speed: 0.1° to 60° per second

Video Compression:

• H.265+/H.265/H.264+/H.264 video compression
• Support for dual-stream encoding for efficient bandwidth and storage management

Audio:

• Two-way audio support via an optional microphone and speaker (external)

Network Interface:

• 1 x RJ-45 Ethernet port (10/100Base-T)
• Supports Power over Ethernet (PoE) - IEEE 802.3af, IEEE 802.3at

Video Outputs:

• 1x BNC video output for connection to analog devices (CVBS)

Intelligent Features:

• Motion detection, Intrusion detection, Line crossing detection
• Video tampering alarm
• Face detection (optional)

Storage:

• MicroSD/SDHC/SDXC card slot (up to 256GB) for local storage
• Supports NAS storage and NVR recording

Operating Conditions:

• Operating temperature: -40°C to 60°C (-40°F to 140°F)
• Humidity: 95% or less (non-condensing)
• IK10-rated vandal resistance
• IP66-rated weatherproof, suitable for outdoor use

Power Supply:

• Power input: 12V DC ± 25% or PoE (IEEE 802.3af/at)
• Power consumption: Max 18W (PoE) / Max 25W (12V DC)

Mounting:

• Ceiling or wall mount options
• 4-inch PTZ camera design

Integration & Compatibility:

• ONVIF compliant (Profile S, Profile G, Profile T)
• Compatible with Hikvision’s iVMS-4200 and Hik-Connect mobile app for remote management

• Horizontal: 55.3° – 2.4°
• Vertical: 42.1° – 1.8°

• Built-in IR illumination, effective up to 100 meters (328 feet) for clear night-time surveillance
• Darkfighter technology for color video in extremely low light conditions

• 360° endless pan rotation for full coverage
• 90° tilt range, with automatic flip functionality for continuous monitoring
• Pan speed: 0.1° to 120°/s
• Tilt speed: 0.1° to 60°/s

• H.265+, H.265, H.264+, H.264 video compression formats for bandwidth efficiency
• Supports dual-stream video encoding

• Ethernet interface (10/100Mbps)
• PoE (Power over Ethernet) support for easy installation
• ONVIF compatibility for third-party integration

• Wide Dynamic Range (WDR) for balanced exposure in complex lighting conditions
• 3D Digital Noise Reduction (DNR) for clear image quality in low-light settings
• Motion detection, intrusion detection, line crossing detection, and object removal detection for enhanced security

• Two-way audio support via built-in microphone and speaker (optional)

• IP66 rated, ensuring durability against rain, dust, and harsh weather conditions
• IK10 vandal-resistant for increased protection in exposed locations

• Temperature: -30°C to 60°C (-22°F to 140°F)
• Humidity: 95% or less (non-condensing)
