General Specifications

• Product Type: Fiber Optic Access Terminal Box (ATB)
• Core Capacity: 12 cores
• Adapter Type: LC/UPC Simplex
• Number of Adapters: 12
• Material:
  • Housing: Cold-rolled steel or ABS plastic
  • Coating: Powder-coated or UV-resistant finish
• Color: Typically telecom gray or black

Dimensions and Weight

• Height: Approximately 200 mm - 300 mm (varies by design)
• Width: Approximately 300 mm - 400 mm (varies by design)
• Depth: Approximately 100 mm - 150 mm (varies by design)
• Weight: Approximately 1 kg - 2 kg (depends on materials and design)

Optical Performance

• Insertion Loss:
  • Maximum: ≤ 0.2 dB (per connection)
• Return Loss:
  • UPC Polish: ≥ 50 dB
• Fiber Type: Singlemode (SM) or Multimode (MM)
• Wavelength Compatibility:
  • Singlemode: 1260 nm - 1650 nm
  • Multimode: 850 nm and 1300 nm

Environmental Specifications

• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +85°C
• Humidity: 0% to 95% (non-condensing)

Mechanical Features

• Design:
  • Compact and durable with a front panel for adapter mounting
  • Integrated cable management features for organized fiber routing
• Cable Entry:
  • Rear or side cable entry ports with strain relief
  • Compatible with various cable types (e.g., loose tube, tight buffered)
• Splice Tray:
  • Capacity for up to 12 splices (if applicable)
  • Supports heat-shrink or mechanical splice protectors

Installation Features

• Mounting:
  • Wall-mountable or pole-mountable options
  • Includes mounting brackets or holes
• Access:
  • Front access door with secure latching mechanism
• Grounding:
  • Integrated grounding points or lugs

Compliance and Standards

• Industry Standards:
  • Complies with Telcordia GR-326 and GR-449
  • RoHS compliant
  • IEC 61754 compliant for fiber optic interconnects

Application Areas

• Telecommunications: Suitable for central offices and network access points
• Data Centers: Ideal for high-density fiber optic connections and patching
• FTTH: Used in Fiber to the Home installations for terminating and managing fiber connections
• Enterprise Networks: For structured cabling and interconnects

Additional Features

• Labeling:
  • Port labeling for easy identification
  • Areas for custom labels and documentation
• Security:
  • Key-locking mechanism for secure access
  • Tamper-resistant design features
• Ventilation:
  • Passive ventilation slots to prevent overheating (if applicable)
• Customization:
  • Available with various connector and adapter configurations
  • Custom colors and finishes upon request

General Specifications:

• Product Type: Multi-Mode Fibre Optic Cable
• Core Count: 12 cores
• Fiber Type: Multi-mode (OM1, OM2, OM3, OM4, or OM5)
• Application: Indoor, outdoor, or general-purpose installations
• Jacket Material: High-density polyethylene (HDPE), low smoke zero halogen (LSZH), or flame-retardant PVC

Optical Performance:

• Attenuation:
  • OM1: ≤ 3.5 dB/km at 850 nm, ≤ 1.0 dB/km at 1300 nm
  • OM2: ≤ 3.0 dB/km at 850 nm, ≤ 1.0 dB/km at 1300 nm
  • OM3: ≤ 2.0 dB/km at 850 nm, ≤ 0.5 dB/km at 1300 nm
  • OM4: ≤ 2.0 dB/km at 850 nm, ≤ 0.5 dB/km at 1300 nm
  • OM5: ≤ 2.0 dB/km at 850 nm, ≤ 0.5 dB/km at 1300 nm
• Bandwidth:
  • OM1: 200 MHz·km at 850 nm, 500 MHz·km at 1300 nm
  • OM2: 500 MHz·km at 850 nm, 500 MHz·km at 1300 nm
  • OM3: 2000 MHz·km at 850 nm
  • OM4: 4700 MHz·km at 850 nm
  • OM5: 2800 MHz·km at 850 nm

Physical Specifications:

• Outer Diameter: Typically 6 mm to 12 mm (depending on construction)
• Cable Construction: Loose tube design or tight-buffered construction
• Number of Fibers per Tube: Typically 6 or 12 fibers per tube (in loose tube designs)
• Strength Members: Aramid yarn or glass fiber for added tensile strength

Mechanical Specifications:

• Tensile Strength: Typically ≥ 1000 N
• Crush Resistance: Typically ≥ 1000 N/100 mm
• Impact Resistance: Typically ≥ 10 impacts of 1 J

Environmental Resistance:

• Temperature Range: Operating: -20°C to +60°C, Installation: -10°C to +50°C
• Water Blocking: Gel or dry water-blocking to prevent water ingress (for outdoor cables)
• UV Resistance: UV-resistant to prevent degradation from sunlight (for outdoor cables)

Installation and Performance:

• Minimum Bend Radius: 10 x cable diameter (dynamic), 5 x cable diameter (static)
• Flame Resistance: Conforms to IEC 60332-1 (flame-retardant performance)

Compliance and Standards:

• Standards Compliance: IEC 60794, ANSI/TIA-568, ISO/IEC 11801, RoHS compliant
• Certification: Often certified by telecommunications and electrical standards organizations

Additional Features:

• Color Coding: Fibers are color-coded for easy identification
• Cable Type: May be available in loose tube or tight-buffered constructions based on application needs.
