Faceplate Specifications:

• Product Type: Faceplate
• Compatibility: Designed for use with Siemon's CAT 6A 10G modules
• Port Capacity: Typically accommodates 1 to 6 modules per faceplate (depending on model)
• Material: High-impact, flame-retardant thermoplastic
• Color: Typically white or other standard colors; customizable options may be available
• Mounting Type: Fits standard 19-inch rack or wall-mounted enclosures
• Dimensions: Standard sizes to fit standard outlet boxes and enclosures
• Labeling: Includes labeling areas for port identification and network documentation
• Installation: Tool-less or screw-mounted options for easy installation and removal
• Standards Compliance: Meets or exceeds ANSI/TIA-568-C.2 and ISO/IEC 11801 standards

Module Specifications:

• Product Type: CAT 6A 10G Module
• Connector Type: RJ45, supporting CAT 6A performance
• Category Rating: CAT 6A (Class EA), supports 10 Gigabit Ethernet (10GBASE-T)
• Cable Compatibility: Supports 22-24 AWG twisted pair cables
• Shielding: Available in both shielded and unshielded versions; shielded modules offer enhanced protection against electromagnetic interference (EMI) and crosstalk
• Termination Style: Tool-less termination for quick and easy installation
• Contact Material: Precision-machined, gold-plated contacts for reliable performance
• Data Rate: Supports data rates up to 10Gbps
• Frequency Range: Operates at frequencies up to 500 MHz
• Standards Compliance:
  • ANSI/TIA-568-C.2
  • ISO/IEC 11801
  • IEC 60603-7
  • RoHS compliant

Price Considerations:

• Pricing: The price for the faceplate and module can vary based on quantity, vendor, and specific configuration. Contact Siemon or an authorized distributor for current pricing and availability.

• Product Type: Shielded Patch Cord
• Cable Category: CAT 7A (Class FA)
• Connector Type: TERA 4-pair (4PR) to MC6 (Modular Category 6)
• Cable Length: 3 meters (approximately 9.8 feet)
• Cable Construction:
  • Cable Shielding: Fully shielded S/FTP (Shielded Foiled Twisted Pair) for maximum protection against electromagnetic interference (EMI) and crosstalk
  • Pairs: 4 twisted pairs, individually shielded
• Conductor Type: Stranded copper conductors for flexibility and durability
• Conductor Gauge: Typically 26 AWG stranded
• Jacket Material: Low smoke zero halogen (LSZH) or PVC, providing flame retardancy and environmental safety
• Jacket Color: Black (B02L)
• Connector Performance:
  • TERA Connector: Siemon’s proprietary interface for superior performance in high-frequency applications
  • MC6 Connector: Modular Category 6 connector for backward compatibility with CAT 6 and CAT 5e systems
  • Contact Material: Phosphor bronze with 50 micro-inch gold plating for reliable connections
• Data Rate Support: Capable of supporting data rates up to 10Gbps and beyond
• Frequency Range: Supports frequencies up to 1,000 MHz, suitable for CAT 7A applications
• Standards Compliance:
  • Meets or exceeds ISO/IEC 11801 Class FA
  • Compliant with ANSI/TIA-568-C.2 for structured cabling
  • IEC 60603-7 (connectors) and IEC 61156-5 (cables)
  • RoHS Compliant
• Electrical Performance:
  • Impedance: 100 ohms ± 15%
  • Propagation Delay: ≤ 570 ns/100m
  • Return Loss: High return loss for minimal signal degradation
• Operating Temperature Range: -20°C to +60°C
• Plug Retention Force: ≥ 50N (for robust connection reliability)
• Application: Suitable for high-performance networking environments, including data centers, enterprise networks, and broadcast applications requiring shielded connections
• Packaging: Supplied in individual packaging for protection during transit and storage
