• Cable Type: Outdoor Singlemode Fiber Optic Cable
• Fiber Count: 12 cores
• Mode Type: Singlemode (SM)
• Fiber Specifications:
  • Typically G.652D or G.657A1 compliant
  • Standard core diameter: 8.3 µm
  • Cladding diameter: 125 µm
• Cable Structure:
  • Loose tube design for enhanced fiber protection
  • Central strength member made of fiberglass reinforced plastic (FRP) or aramid yarn
• Jacket Material:
  • UV-resistant black polyethylene (PE) or anti-tracking (AT) material
• Outer Diameter: Approximately 8mm to 12mm (varies by manufacturer)
• Jacket Thickness: Typically around 1.5mm to 2.5mm for added durability
• Tensile Strength:
  • Short-term tensile strength: ≥ 2000 N
  • Long-term tensile strength: ≥ 1000 N
• Crush Resistance:
  • Short-term: ≥ 1000 N/100mm
  • Long-term: ≥ 300 N/100mm
• Bending Radius:
  • Dynamic: ≥ 20 times the cable diameter
  • Static: ≥ 10 times the cable diameter
•

• Type: Singlemode Fibre Optic Cable
• Core Count: 12 Fibers
• Cable Structure: Un-armoured
• Core Diameter: 9 µm
• Cladding Diameter: 125 µm
• Outer Diameter: Typically 3.0 mm
• Material: PVC or LSZH (Low Smoke Zero Halogen) sheath
• Transmission Wavelength: 1310 nm and 1550 nm
• Maximum Attenuation: ≤ 0.35 dB/km at 1310 nm, ≤ 0.20 dB/km at 1550 nm
• Bend Radius: Minimum bend radius of 10 x outer diameter during installation and 20 x outer diameter when in use
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +70°C
• Color Coding: Fibers typically color-coded according to standards (e.g., Yellow for singlemode)
• Refractive Index Profile: Step index or graded index as per specifications
• Jacket Color: Yellow for singlemode applications
• Fire Rating: Complies with relevant fire safety standards (e.g., OFNR, OFNP)

General Specifications

• Product Type: Optical Distribution Frame (ODF)
• Port Configuration: 12 Ports
• Adapter Type: LC (Lucent Connector) with UPC (Ultra Physical Contact) polish
• Fiber Type: Single-Mode (SM)
• Configuration: Duplex (dual channel per port)
• Rack Mount: 1U (one rack unit high)

Performance Specifications

• Insertion Loss:
  • Typically ≤ 0.2 dB per adapter
  • Maximum ≤ 0.3 dB per adapter
• Return Loss:
  • Typically ≥ 50 dB (for UPC polish in single-mode applications)
• Operating Wavelength:
  • 1310 nm and 1550 nm (common for single-mode fibers)
• Optical Compatibility:
  • Supports G.652, G.657 single-mode fiber types

Connector Specifications

• Connector Compatibility:
  • Designed for LC (Lucent Connector) type fibers
• Adapter Material:
  • Durable metal or plastic housing
  • High-precision ceramic sleeves for accurate alignment
• Sleeve Type:
  • Duplex sleeves for each port

Mechanical Specifications

• Durability:
  • Typically rated for ≥ 1000 mating cycles per adapter
• Insertion Force:
  • Low insertion force for easy connection and disconnection
• Construction Material:
  • Corrosion-resistant metal frame or high-strength plastic

Environmental Specifications

• Operating Temperature:
  • Typically -20°C to 70°C
• Storage Temperature:
  • Typically -40°C to 85°C
• Humidity:
  • Up to 95% relative humidity, non-condensing

Rack Mounting

• Rack Mount Type:
  • Designed for standard 19-inch racks or cabinets
• Installation:
  • Occupies 1U of rack space
• Front Panel:
  • Clearly labeled ports for easy identification and management
• Cable Management:
  • Integrated cable management features for organized routing

Compliance and Certifications

• Standards Compliance:
  • Meets or exceeds standards such as TIA/EIA-568 and IEC
• Certifications:
  • RoHS compliant
  • UL Listed or similar safety certifications

Applications

• Network Environments:
  • Suitable for telecommunications, data centers, enterprise networks, and local area networks (LAN)
• Usage:
  • Ideal for managing and connecting 12-port single-mode fiber networks
  • Facilitates organized and efficient patching with duplex LC/UPC adapters

Features

• Design:
  • Compact, high-density design for efficient fiber management
• Ease of Use:
  • Front-access design for straightforward installation and maintenance
• Maintenance:
  • Easy access to ports for quick maintenance, upgrades, and reconfiguration

General Specifications

• Product Type: Optical Distribution Frame (ODF)
• Rack Units: 1U
• Number of Ports: 12
• Connector Type: SC Duplex
• Connector Finish: UPC (Ultra Physical Contact)
• Fiber Type: Multimode (MM)

Adapter Panel

• Panel Type: Rack Mount
• Material: Cold-rolled steel with powder-coated finish
• Color: Typically black or gray
• Front Panel Ports: 12 SC Duplex adapters
• Rear Cable Management: Integrated management for efficient fiber routing and protection

Optical Performance

• Insertion Loss: ≤ 0.3 dB (typical)
• Return Loss: ≥ 50 dB for UPC
• Repeatability: ≤ 0.1 dB
• Durability: > 1000 mating cycles

Compatibility

• Fiber Modes: OM1, OM2, OM3, OM4, and OM5 compatible
• Cable Types: 50/125 μm and 62.5/125 μm multimode fibers
• Polishing Type: UPC polished connectors

Physical Dimensions

• Height: 1.75 inches (44.45 mm)
• Width: 19 inches (482.6 mm) standard rack width
• Depth: Typically around 10-12 inches (254-305 mm)

Environmental Specifications

• Operating Temperature: -40°C to +75°C
• Storage Temperature: -40°C to +85°C
• Humidity: 0% to 95% (non-condensing)

Installation Features

• Mounting: Standard 19-inch rack mountable
• Accessibility: Front access for easy installation and maintenance
• Cable Management: Includes rear cable management tray or brackets
• Labeling: Port numbering and labeling for easy identification

Compliance and Standards

• Industry Standards: Complies with TIA/EIA, IEC, and RoHS standards
• Fire Rating: Complies with UL 94V-0 flammability rating

Additional Features

• Design: Compact and lightweight design for efficient space utilization
• Security: Optional lockable doors for added security
• Accessories: Includes mounting screws, cable ties, and dust caps
• Customizability: Available in various colors and finishes upon request
