• Rack Units: 15U
• Dimensions (HxWxD): 15U x 600mm x 600mm
• Material: Cold-rolled steel
• Finish: Powder-coated, corrosion-resistant
• Protection Rating: IP55-rated for dust and water protection
• Cooling:
  • Built-in ventilation fans
  • Louvered vents for airflow
  • Optional air conditioning or heat exchanger units
• Door:
  • Single or dual door access
  • Sealed with weatherproof gasket
  • Equipped with a 3-point locking system for security
• Mounting:
  • 19-inch rack-mountable rails, adjustable depth
  • Front and rear mounting rails
• Cable Management:
  • Multiple cable entry points (top and bottom)
  • Grommets or sealing foam to protect against moisture
• Load Capacity: Supports up to 60 kg (varies by model)
• Temperature Management:
  • Thermostat-controlled fan operation
  • Optional heating system for cold climates
• Security:
  • Lockable door with anti-vandal features
  • Optional tamper alarms and access control
• Grounding: Built-in grounding strip for earthing
•

• Rack Units: 18U
• Dimensions (HxWxD): 18U x 600mm (W) x 600mm (D)
• Material: High-grade cold-rolled steel construction
• Finish: Powder-coated for corrosion resistance and durability
• Protection Rating: IP55-rated for protection against dust, rain, and harsh weather conditions
• Cooling System:
  • Built-in ventilation fans for active cooling
  • Louvered vents for passive airflow
  • Optional air conditioning or heat exchanger units for enhanced cooling
• Door:
  • Single or dual front and rear access doors with weatherproof gaskets
  • 3-point locking system for secure access
  • Optional anti-vandal features for additional security
• Mounting:
  • Standard 19-inch adjustable rack rails
  • Front and rear mounting rails with adjustable depth
• Cable Management:
  • Multiple cable entry points at the top and bottom
  • Sealable grommets to prevent dust and water ingress
• Load Capacity: Supports up to 70 kg (may vary depending on mounting setup)
• Temperature Management:
  • Thermostat-controlled fans for automatic temperature regulation
  • Optional heater for cold environments
• Security:
  • Lockable doors with anti-vandal design
  • Optional alarm systems and access control options
• Grounding: Integrated grounding strip for safe and effective earthing
• Accessories:
  • Adjustable shelving for flexible equipment organization
  • Power distribution units (PDUs) for structured power management
  • Mounting hardware included for straightforward installation

• Rack Units: 32U capacity, providing ample space for large networking and server equipment
• Dimensions:
  • Height: Approximately 32U (about 1,500mm)
  • Width: 600mm
  • Depth: 600mm, designed to accommodate deeper servers and networking gear
• Material: Heavy-duty steel construction with a weather-resistant and corrosion-resistant finish for outdoor durability
• Ingress Protection (IP) Rating: IP55, ensuring protection against dust ingress and water exposure from all directions
• Mounting Type: Freestanding design, allowing for versatile placement in outdoor environments
• Door:
  • Front Door: Lockable with a weather-tight seal to prevent water and dust entry
  • Side Doors: Access on both sides for maintenance and equipment management
  • Swing Angle: 180° door swing for easy access to the cabinet’s interior
• Ventilation:
  • Integrated Vents: Designed to facilitate airflow and cooling while preventing debris and moisture ingress
  • Fan Mounting Options: Capability to add fans for enhanced cooling in warmer climates or high-density equipment setups
• Cable Management:
  • Sealed Cable Entry Points: Located at the bottom with grommets to block moisture and dust
  • Cable Management Accessories: Includes internal hooks and rings to keep cables organized and minimize clutter
• Mounting Rails:
  • Adjustable 19-Inch Rails: Supports standard 19-inch rack-mounted equipment with adjustable depth for flexibility
  • Pre-installed Rails: Simplifies installation and setup of equipment

• Type: Multi-functional floor socket outlet with 3-pin power and data socket
• Configuration: 1-Gang, 3-pin UK power socket and data cable socket combination
• Power Socket:
  • Voltage Rating: 220-250V AC
  • Current Rating: 13A
  • Pin Type: 3-pin (UK Type G)
• Data Cable Socket: RJ45 Cat5e or Cat6 (depending on model) for network connectivity
• Material: Heavy-duty metal or polycarbonate casing for durability
• Finish: Brushed stainless steel or other corrosion-resistant finish for a professional appearance and long-lasting durability
• Installation: Flush-mounted for installation into flooring, suitable for offices, meeting rooms, and workspaces
• Cover Type: Pop-up or flip-up cover with self-closing lid for protection against dust and debris
• Cable Management: Integrated cable access points to keep cables organized and prevent tangling
• Dimensions: Approximately 120mm x 120mm (varies by model, check specific product details)
• IP Rating: IP20 for indoor use, with limited dust protection
• Compliance: Meets BS 5733 and IEC standards for safety and performance
• Usage: Ideal for environments requiring combined power and data connectivity within reach on the floor level

4U -300x600x600 Duff Network Data cabinet

• Rack Units: 42U
• Dimensions: 800mm (W) x 1000mm (D) x 1981mm (H)
• Weight Capacity: Up to 1000 kg (evenly distributed)
• Material: Cold-rolled steel construction for enhanced durability
• Color: Powder-coated black finish for corrosion resistance
• Cooling Options: Ventilated side panels and adjustable fan trays to support airflow
• Doors:
  • Front: Tempered glass door for visibility and security
  • Rear: Solid metal door with locking mechanism for enhanced security
• Side Panels: Removable and lockable for easy access to equipment
• Mounting Rails: Adjustable front and rear rails with standard 19-inch mounting for equipment compatibility
• Cable Management: Integrated cable management system for organized wiring and improved airflow
• Access Points: Multiple knockouts for cable entry/exit at top and bottom
• Compatibility: Suitable for standard 19-inch rack-mounted equipment
• Assembly: Flat-packed for easy transport; quick assembly required
• Accessories: Optional shelves, power strips, and cooling fans available
• Certifications: Compliance with international standards for safety and performance

• Rack Units: 6U capacity, ideal for housing small networking equipment like routers, switches, and patch panels
• Dimensions:
  • Height: 370mm
  • Width: 600mm
  • Depth: 600mm, offering extra room for deeper devices and organized cabling
• Material: Durable steel construction for enhanced strength and protection of equipment
• Mounting Type: Wall-mountable design to save floor space, suitable for compact spaces like offices, server rooms, and IT closets
• Weight Capacity: Supports moderate equipment loads based on secure wall mounting
• Door:
  • Front Door: Lockable tempered glass for added security and visibility
  • Swing Angle: 180° door swing for easy access to interior components
• Ventilation:
  • Vented Side Panels: Provides natural airflow to help prevent overheating
  • Fan Mounts: Compatible with optional fans on the top or bottom to enhance cooling as needed
• Cable Management:
  • Cable Entry Points: Located at both top and bottom for clean, organized cabling
  • Grommeted Openings: Protects cables from wear and minimizes clutter
• Mounting Rails:
  • Adjustable Rails: 19-inch standard rack rails with adjustable depth for customized equipment placement
  • Pre-installed Rails: Simplifies device installation and rack setup
• Locking Mechanism: Lockable front door to prevent unauthorized access
• Color: Black powder-coated finish, providing corrosion resistance and a professional appearance
• Compliance: Conforms to industry standards for network and server rack installations
• Application: Suitable for small to medium-sized networking setups in professional settings, such as offices and small server environments

• Rack Units: 6U capacity, suitable for smaller networking setups like patch panels, switches, and routers
• Dimensions:
  • Height: 370mm
  • Width: 600mm
  • Depth: 450mm, offering ample space for compact equipment and cable management
• Material: High-quality steel construction for durability and equipment protection
• Mounting Type: Wall-mount design, ideal for saving floor space in offices, small IT closets, and data rooms
• Weight Capacity: Supports moderate loads depending on wall mounting and anchoring
• Door:
  • Front Door: Lockable, tempered glass for security with visibility into the cabinet’s interior
  • Swing Angle: 180° for full, unobstructed access to equipment
• Ventilation:
  • Vented Side Panels: Facilitates airflow to maintain optimal equipment temperature
  • Fan Mounts: Option to install fans on the top or bottom for enhanced cooling
• Cable Management:
  • Cable Entry Points: Top and bottom entry points for organized cable routing
  • Grommeted Openings: Protects cables and maintains a tidy installation
• Mounting Rails:
  • Adjustable Rails: 19-inch standard rack-compatible, allowing for flexible device positioning
  • Pre-installed Rails: Simplifies initial setup and equipment mounting
• Locking Mechanism: Front door lock for protection against unauthorized access
