Epson PLQ-22 Passbook Printer

Epson PLQ-22 Passbook Printer

Epson PLQ-22 Passbook Printer from Mtech customer waiting time will be greatly reduced as it has an amazing printing speed. with this printer productivity and general organisation performance is improved hence the organisation is able to stay on top of business with quality services.

24-pin Epson PLQ-22 impact passbook printer is fast and versatile, with print speeds up to 480 cps, high paper throughput and the ability to handle passbooks up to 2.6mm thick. Epson PLQ-22 impact passbook printer features convenient automatic forms alignment and automatic print gap adjustment to ensure fast, trouble-free printing of passbooks and other specialized banking documents.

PLQ-22 Passbook Printer all-in-one device designed specifically to ease customer transactions in busy government and financial institutions such as banks and post offices. PQL-22 dot matrix passbook printer makes processing financial documents quick and easy, helping to reduce customer queues during busy periods.

PQL-22 dot matrix passbook printer  able to print at high speeds, the 24-pin, 94-column dot matrix printer can help cut total print time and improve the speed of every transaction – something both staff and customers will appreciate.

Epson PLQ-22 impact passbook printer specifications

• Print Method: 24-pin dot matrix
• Print Speed: Up to 576 cps (10 cpi draft)
• Print Resolution: Up to 240 x 144 dpi
• Connectivity: USB, Serial, Parallel
• Fonts: 10 scalable fonts, 8 barcode fonts
• Paper Handling:
  • Passbook Type: Single-sheet, multiple-copy, front/rear-feed
  • Paper Size: Maximum 245 x 297 mm (9.65 x 11.69 inches)
  • Paper Thickness: 0.065 to 0.16 mm (0.0026 to 0.0063 inches)
  • Copy Capability: 1 original + 5 copies
• Ribbon Cartridge: Approx. 10 million characters (black)
• MTBF (Mean Time Between Failures): Approx. 10,000 hours
• Emulations: ESC/P2, IBM PPDS
• Reliability:
  • Print Head Life: Approx. 400 million strokes/wire
  • Print Head Life (MTBF): Approx. 400 million strokes/wire
• Dimensions (W x D x H): 384 x 280 x 203 mm (15.12 x 11.02 x 7.99 inches)
• Weight: Approx. 7.2 kg (15.87 lbs)
• Power Requirements: AC 220 – 240 V
• Power Consumption: Approx. 47 W (printing), Approx. 3.3 W (standby)
• Operating Systems Compatibility: Windows XP/Vista/7/8/10, Windows Server
