Hikvision DS-7104HQHI-K1 4 channel Turbo HD DVR

Channels:

• Supports 4 channels for video recording and monitoring
• Up to 4MP resolution recording for high-quality footage

Video Input:

• 4 × BNC inputs for connecting cameras
• Compatible with HD-TVI, AHD, CVI, and CVBS video formats
• Supports analog HD cameras and standard analog cameras

IP Camera Support:

• Additional IP camera channels (up to 2 IP cameras supported for a total of 6 channels)

Resolution:

• Recording resolution of up to 4MP for analog cameras
• Supports 4MP resolution for IP cameras (depending on the configuration)

Recording Capacity:

• 1 x HDD support for storage (up to 6TB capacity per HDD)
• SATA interface for hard drive connection

Compression:

• H.264 video compression for efficient storage
• H.264+ compression technology for additional storage optimization

Playback:

• Supports 4-channel playback for simultaneous video review
• Smart search for efficient footage retrieval and fast searching

Network Connectivity:

• 1 × RJ-45 10/100 Mbps Ethernet port for network access
• Remote viewing and control via Hik-Connect app (mobile) and iVMS-4200 (PC)

Video Output:

• 1 × HDMI output (up to 1080p resolution) for video display
• 1 × VGA output (up to 1920 × 1080 resolution) for external monitor connection

Audio:

• 1 × RCA audio input (one-way audio support)
• 1 × RCA audio output for audio playback

Backup and Storage:

• USB 2.0 ports for local backup of video footage
• Network backup options for storing footage off-site

User Interface:

• On-Screen Display (OSD) for easy configuration
• Graphical User Interface (GUI) for intuitive system management

Power Supply:

• 12V DC ± 10% power input
• Approx. 10W power consumption (without HDD)

Physical Dimensions:

• Dimensions: 315 mm × 240 mm × 45 mm (12.4" × 9.4" × 1.77")
• Weight: Approx. 1.0 kg (2.2 lbs) without HDD

Operating Environment:

• Operating temperature: 0°C to 45°C (32°F to 113°F)
• Operating humidity: 10% to 90% RH
