General Specifications

• Product Type: Planar Lightwave Circuit (PLC) Optical Splitter
• Configuration: 1x16 (1 input fiber and 16 output fibers)
• Design: Bare PLC Splitter in a Steel Tube
• Fiber Type: Singlemode Fiber
• Fiber Buffer Diameter: 250µm (tight-buffered)

Optical Performance

• Wavelength Range: 1260 nm - 1650 nm (supports both 1310 nm and 1550 nm windows)
• Insertion Loss:
  • Typical: ≤ 12.0 dB
  • Maximum: ≤ 13.0 dB
• Uniformity: ≤ 1.5 dB (ensures consistent signal distribution among outputs)
• Return Loss: ≥ 50 dB (minimizes back reflections)
• Directivity: ≥ 55 dB (reduces cross-talk between inputs and outputs)
• Polarization Dependent Loss (PDL): ≤ 0.2 dB (ensures consistent performance regardless of polarization)
• Splitting Ratio: 1:16 (equal power distribution)

Fiber Specifications

• Fiber Mode Compatibility: ITU-T G.657A or G.652D compliant
• Input/Output Fiber Diameter: 250µm tight-buffered fiber
• Cable Jacket Material: Steel tube for added protection and mechanical strength

Physical Dimensions

• Enclosure Type: Steel tube
• Dimensions:
  • Length: Typically 60-100 mm (varies by design)
  • Diameter: Approximately 6-8 mm
• Weight: Approximately 50-100 grams (varies by design and length)

Environmental Specifications

• Operating Temperature: -40°C to +85°C (suitable for a wide range of environments)
• Storage Temperature: -40°C to +85°C
• Humidity: 0% to 95% (non-condensing, suitable for various environmental conditions)

Installation Features

• Mounting: Typically installed in splice trays or enclosures
• Cable Management: Requires external cable management solutions
• Accessibility: Accessible for splicing and maintenance
• Labeling: Clear port numbering and labeling for easy identification and troubleshooting

Compliance and Standards

• Industry Standards:
  • Telcordia GR-1209 and GR-1221 compliant for reliability and performance
  • IEC 61753-1 compliant for fiber optic interconnecting devices
  • RoHS compliant for environmental and safety regulations

Additional Features

• Design: Compact and durable steel tube design for robust protection
• Accessories: May include splice sleeves, protective caps, and installation instructions
• Reliability: High stability and reliability for various network applications, including FTTH, PON, and CATV
• Durability: Engineered for long-term operation with low maintenance requirements

General Specifications

• Product Type: Fiber Optic Splitter
• Configuration: 1x8 (1 input, 8 outputs)
• Splitter Type: Planar Lightwave Circuit (PLC)
• Housing Type: Bare steel tube
• Fiber Type: Singlemode
• Fiber Diameter: 250µm (micron)

Optical Performance

• Operating Wavelength: 1260 nm - 1650 nm (covers O, E, S, C, and L bands)
• Insertion Loss:
  • Typical: ≤ 10.5 dB
  • Maximum: ≤ 11.0 dB
• Uniformity: ≤ 0.8 dB (ensures consistent signal distribution across all outputs)
• Return Loss: ≥ 55 dB (minimizes back reflections)
• Polarization Dependent Loss (PDL): ≤ 0.2 dB (ensures stable performance across polarization states)
• Directivity: ≥ 55 dB (ensures minimal signal leakage between input and output ports)

Mechanical Specifications

• Steel Tube Dimensions:
  • Length: Approximately 40 mm - 60 mm
  • Diameter: Approximately 3 mm - 4 mm
• Fiber Length: Typically 1 meter (input and output fibers)
• Strength Member: Stainless steel for enhanced durability
• Weight: Lightweight design for easy handling and integration

Environmental Specifications

• Operating Temperature: -40°C to +85°C (suitable for a wide range of environmental conditions)
• Storage Temperature: -40°C to +85°C
• Humidity: 0% to 95% (non-condensing)

Installation Features

• Compatibility: Compatible with various fiber optic systems and networks
• Installation:
  • Simple installation with fusion splicing or mechanical splicing
  • Bare fiber ends allow for flexible integration
• Bend Radius: Supports standard bend radius requirements for 250µm fibers

Compliance and Standards

• Industry Standards:
  • Compliant with Telcordia GR-1209 and GR-1221 standards
  • RoHS compliant for environmental safety

Application Areas

• Telecommunications: Ideal for splitting optical signals in telecom networks
• Data Centers: Suitable for high-density fiber optic connections
• FTTH: Widely used in Fiber to the Home applications for signal distribution
• Passive Optical Networks (PON): Essential for splitting signals in PON architectures
• CATV: Used in cable television systems for efficient signal distribution

Additional Features

• Design: Compact and lightweight for easy integration and space-saving installations
• Durability: Steel tube housing provides mechanical protection and stability
• Reliability: High-quality PLC technology ensures long-term performance and reliability
• Customization: Available with various fiber lengths and connector options upon request

General Specifications

• Product Type: Planar Lightwave Circuit (PLC) Optical Splitter
• Configuration: 1x2 (1 input fiber and 2 output fibers)
• Design: Bare PLC Splitter in a Steel Tube
• Fiber Type: Singlemode Fiber
• Fiber Buffer Diameter: 250µm (tight-buffered)

Optical Performance

• Wavelength Range: 1260 nm - 1650 nm (supports both 1310 nm and 1550 nm windows)
• Insertion Loss:
  • Typical: ≤ 3.8 dB
  • Maximum: ≤ 4.0 dB
• Uniformity: ≤ 0.8 dB (ensures consistent signal distribution among outputs)
• Return Loss: ≥ 50 dB (minimizes back reflections)
• Directivity: ≥ 55 dB (reduces cross-talk between inputs and outputs)
• Polarization Dependent Loss (PDL): ≤ 0.2 dB (ensures consistent performance regardless of polarization)
• Splitting Ratio: 1:2 (equal power distribution)

Fiber Specifications

• Fiber Mode Compatibility: ITU-T G.657A or G.652D compliant
• Input/Output Fiber Diameter: 250µm tight-buffered fiber
• Cable Jacket Material: Steel tube for added protection and mechanical strength

Physical Dimensions

• Enclosure Type: Steel tube
• Dimensions:
  • Length: Typically 50-80 mm (varies by design)
  • Diameter: Approximately 6-8 mm
• Weight: Approximately 30-60 grams (varies by design and length)

Environmental Specifications

• Operating Temperature: -40°C to +85°C (suitable for a wide range of environments)
• Storage Temperature: -40°C to +85°C
• Humidity: 0% to 95% (non-condensing, suitable for various environmental conditions)

Installation Features

• Mounting: Typically installed in splice trays or enclosures
• Cable Management: Requires external cable management solutions
• Accessibility: Accessible for splicing and maintenance
• Labeling: Clear port numbering and labeling for easy identification and troubleshooting

Compliance and Standards

• Industry Standards:
  • Telcordia GR-1209 and GR-1221 compliant for reliability and performance
  • IEC 61753-1 compliant for fiber optic interconnecting devices
  • RoHS compliant for environmental and safety regulations

Additional Features

• Design: Compact and durable steel tube design for robust protection
• Accessories: May include splice sleeves, protective caps, and installation instructions
• Reliability: High stability and reliability for various network applications, including FTTH, PON, and CATV
• Durability: Engineered for long-term operation with low maintenance requirements

General Specifications

• Module Type: Small Form-Factor Pluggable (SFP) Mini GBIC
• Standard: 1000Base-LX (Gigabit Ethernet over Singlemode Fiber)
• Distance: Up to 20 kilometers (km)
• Wavelength: 1310 nm

Optical Characteristics

• Optical Connector: LC Duplex
• Transmitter Type: Laser Diode (LD)
• Receiver Type: Photodiode (PD)
• Transmit Power:
  • Minimum: -9 dBm
  • Maximum: -3 dBm
• Receiver Sensitivity:
  • Typical: -20 dBm
• Maximum Input Power: -3 dBm
• Optical Fiber Type: Singlemode Fiber (SMF)

Electrical Characteristics

• Data Rate: 1 Gbps (Gigabit per second)
• Power Consumption: Typically ≤ 1.0 W

Performance Specifications

• Bit Error Rate (BER): < 1 x 10^-12
• Link Budget: 11 dB
• Temperature Range:
  • Operating: 0°C to +70°C
  • Storage: -40°C to +85°C

Mechanical Specifications

• Form Factor: SFP Mini GBIC
• Dimensions:
  • Length: Approximately 72 mm
  • Width: Approximately 13 mm
  • Height: Approximately 8 mm
• Weight: Approximately 30 grams

Compliance and Standards

• Standards Compliance:
  • IEEE 802.3z (Gigabit Ethernet)
  • RoHS (Restriction of Hazardous Substances)
• Safety: CE, FCC, and other relevant safety certifications

Additional Features

• Hot Swappable: Yes (supports hot swapping for easy replacement without powering down)
• Diagnostics: Built-in digital diagnostic monitoring (DDM) for real-time status and performance metrics
• Connector: LC/PC (Physical Contact)

General Specifications

• Product Type: Fiber Optical Attenuator
• Connector Type: LC/UPC (Lucent Connector / Ultra Physical Contact)
  • Male Connector: LC/UPC Male
  • Female Connector: LC/UPC Female
• Attenuation Level: 20 dB
• Operating Wavelength: 1260 nm - 1620 nm (suitable for both 1310 nm and 1550 nm windows)
• Fiber Type Compatibility: Singlemode fiber

Optical Performance

• Attenuation Tolerance: ± 0.5 dB (accuracy of attenuation level)
• Return Loss:
  • Typical: ≥ 50 dB (reduces back reflections)
• Polarization Dependent Loss (PDL): ≤ 0.1 dB (ensures consistent performance regardless of polarization)
• Operating Temperature: -40°C to +75°C (suitable for a wide range of environments)
• Storage Temperature: -40°C to +85°C
• Humidity: 0% to 95% (non-condensing)

Mechanical Specifications

• Housing Material:
  • Ferrule: Zirconia ceramic for high precision and durability
  • Body: Metal or high-strength polymer housing
• Connector Durability: 500 mating cycles (ensures longevity with repeated use)
• Dimensions:
  • Length: Typically 25 mm - 35 mm
  • Diameter: Approximately 5 mm - 10 mm
• Weight: Approximately 5-10 grams

Environmental Specifications

• Shock Resistance: Complies with industry shock and vibration standards
• Vibration Resistance: Designed to withstand mechanical vibrations
• Thermal Stability: Maintains attenuation level across temperature changes

Installation and Usage Features

• Mounting Type: Plug-in (easy installation and removal)
• Usage: Suitable for applications where signal strength reduction is required
• Compatibility: Compatible with standard LC/UPC fiber optic connectors

Compliance and Standards

• Industry Standards:
  • Telcordia GR-910 compliant for reliability and performance
  • RoHS compliant for environmental and safety regulations
• Quality Assurance: 100% tested for insertion loss, return loss, and attenuation accuracy

Application Areas

• Telecommunications: Used in telecom networks to adjust optical power levels
• Data Centers: Helps balance optical signal strength in data center applications
• FTTH: Utilized in Fiber to the Home networks for signal regulation
• CATV: Suitable for cable television systems to control signal power
• Testing and Measurement: Used in laboratory settings for testing and calibration

Additional Features

• Design: Compact and lightweight for easy handling and integration
• Labeling: Clearly labeled with attenuation value for easy identification
• Reliability: High reliability and stability for long-term applications

General Specifications

• Type: Fiber Attenuator
• Connector Type: LC/UPC Male to LC/UPC Female
• Attenuation Values:
  • Available in 4 dB and 5 dB
• Application: Optical signal attenuation to prevent signal overload and improve network performance

Optical Performance

• Insertion Loss:
  • Typical: ≤ 0.2 dB
  • Maximum: ≤ 0.3 dB
• Return Loss:
  • UPC Polish: ≥ 50 dB
• Wavelength Range:
  • Singlemode: 1260 nm - 1650 nm
  • Multimode: 850 nm and 1300 nm (if applicable)

Mechanical and Design Features

• Housing Material:
  • Body: Stainless steel or high-quality plastic
• Connector Material:
  • Ferrule: Zirconia ceramic or equivalent
• Dimensions:
  • Length: Typically 50 mm - 60 mm
  • Diameter: Typically 5 mm - 7 mm
• Weight: Approximately 10 g - 20 g per attenuator

Environmental Specifications

• Operating Temperature: -40°C to +85°C
• Storage Temperature: -40°C to +85°C
• Humidity: 0% to 95% (non-condensing)

Performance Specifications

• Attenuation Accuracy: ± 0.5 dB
• Durability:
  • Cycles: ≥ 500 mating cycles
• Vibration Resistance: Meets or exceeds industry standards for vibration resistance
• Shock Resistance: Meets or exceeds industry standards for shock resistance

Compliance and Standards

• Industry Standards:
  • Complies with Telcordia GR-326
  • RoHS compliant
  • IEC 61300 compliant for fiber optic performance

Application Areas

• Telecommunications: Used in telecom networks to control signal strength and quality
• Data Centers: For managing optical signal levels and ensuring network performance
• Testing and Measurement: In optical testing setups to simulate real-world attenuation scenarios
• Fiber Optic Networks: To balance and optimize optical signal levels in various network applications

Additional Features

• Color Coding: Available with color bands for easy identification of attenuation values
• Packaging: Typically supplied in protective packaging to prevent damage during transport
• Customization: Available in various attenuation values upon request

General Specifications:

• Product Type: Pedestal Mounted Fiber Distribution Cabinet
• Fiber Capacity: 144 cores
• Connector Type: SC/APC connectors

Physical Specifications:

• Material: Typically made from high-quality stainless steel or aluminum alloy with a powder-coated finish for corrosion resistance
• Dimensions: Varies by manufacturer, but typically ranges around 1200 mm (H) x 600 mm (W) x 400 mm (D)
• Mounting Type: Pedestal mounted for outdoor installation
• Color: Standard color is gray or green, with other options available depending on the manufacturer

Fiber Management:

• Splice Tray Capacity: Holds multiple splice trays, each accommodating 24 fibers (up to 6 trays for 144 fibers)
• Adapter Panels: Pre-installed adapter panels with SC/APC connectors, supporting up to 144 fiber terminations
• Cable Management: Integrated cable management system with bend radius protection, routing guides, and slack storage
• Splitter Modules: Space available for the installation of optical splitters, typically up to 1x32 or 2x32 configurations

Environmental and Mechanical Protection:

• Ingress Protection: IP55 or higher, providing protection against dust, rain, and other environmental factors
• Temperature Range: Operating: -40°C to +60°C
• Impact Resistance: IK10 or higher, providing high resistance to mechanical impacts
• UV Resistance: UV-resistant coating to prevent degradation from sunlight exposure

Security and Access:

• Locking Mechanism: Multi-point locking system with padlock provision for enhanced security
• Access Doors: Front and rear access doors for easy installation and maintenance
• Cable Entry Points: Multiple entry points for feeder and distribution cables, equipped with grommets or sealing glands

Standards and Compliance:

• Standards Compliance:
  • IEC 61753 (performance)
  • IEC 60529 (ingress protection)
  • TIA/EIA-568 (connectors and fiber management)
  • RoHS compliant
• Grounding: Equipped with an internal grounding system compliant with IEC 60728-11

Additional Features:

• Cooling: Passive ventilation or optional active cooling for temperature management
• Labeling: Laser-etched or printed labels for easy identification of fiber connections and ports
• Mounting Hardware: Supplied with all necessary hardware for pedestal mounting
•

General Specifications:

• Product Type: Fibre Splicing Tray
• Capacity: 24 fibers
• Design: For use with dome enclosures

Physical Specifications:

• Material: Typically made from high-quality plastic or metal (e.g., ABS, PVC)
• Dimensions: Designed to fit standard dome enclosures; exact dimensions may vary based on enclosure size
• Color: Often white or light gray

Splicing Capacity:

• Number of Fibers: Accommodates up to 24 fibers
• Splice Holders: Includes slots or holders for up to 24 splice protectors or heat-shrink splices

Features:

• Fiber Routing: Designed with cable routing and management features to organize and protect fibers
• Access Ports: Includes entry and exit ports for fibers, allowing for easy access and routing
• Mounting: Can be mounted securely within a dome enclosure using standard mounting hardware

Installation and Use:

• Compatibility: Suitable for use with various types of dome enclosures
• Ease of Installation: Designed for straightforward installation and maintenance
• Protective Features: Provides protection for spliced fibers and splice protectors

Environmental Resistance:

• Temperature Range: Typically designed to operate within a range of -20°C to +70°C
• Durability: Built to withstand environmental factors such as moisture, dust, and mechanical stresses

Compliance and Standards:

• Standards Compliance: Often meets industry standards for fiber splicing and enclosure compatibility
• Certification: May be certified by telecommunications and electrical standards organizations

Additional Features:

• Labeling: May include labeling areas for easy identification of fibers and splices
• Cable Management: Integrated cable management features to ensure neat and organized fiber routing
