General Specifications

• Product Type: Fiber Optic Connector
• Connector Type: LC (Lucent Connector)
• Polish Type: UPC (Ultra Physical Contact)
• Connector Length: 55 mm
• Fiber Type: Typically used with Single-Mode (SM) or Multi-Mode (MM) fibers

Performance Specifications

• Insertion Loss:
  • Typically ≤ 0.3 dB
  • Maximum ≤ 0.5 dB
• Return Loss:
  • ≥ 50 dB (for UPC polish)
• Operating Wavelength:
  • Commonly 1310 nm and 1550 nm for Single-Mode
  • 850 nm and 1300 nm for Multi-Mode

Connector Specifications

• Connector Material:
  • High-precision ceramic ferrule
  • Durable plastic or metal housing
• Polish Type:
  • UPC: Provides a high level of precision with a rounded end-face for low insertion loss and high return loss
• Fiber Diameter:
  • Compatible with 9/125 micrometers for Single-Mode
  • Compatible with 50/125 or 62.5/125 micrometers for Multi-Mode

Installation and Usage

• Fast Connector:
  • Designed for quick and easy field termination without the need for splicing or polishing
  • Typically includes a pre-assembled design for straightforward installation
• Compatibility:
  • Suitable for use with standard LC fiber optic patch panels, adapters, and equipment

Environmental Specifications

• Operating Temperature:
  • Typically -20°C to 70°C
• Storage Temperature:
  • Typically -40°C to 85°C
• Humidity:
  • 95% relative humidity, non-condensing

Mechanical Specifications

• Durability:
  • Typically rated for ≥ 500 mating cycles
• Insertion Force:
  • Designed to provide reliable connections with minimal insertion force

Compliance and Certifications

• Standards Compliance:
  • Meets or exceeds standards such as TIA/EIA-568 and IEC
• Certifications:
  • RoHS compliant
  • UL Listed or similar safety certifications

Applications

• Network Environments:
  • Ideal for telecommunications, data centers, and high-speed network connections
• Usage:
  • Suitable for use in fiber optic patch panels, wall plates, and field installations

• Fiber Type:
  • Multimode and Singlemode
• Core Count:
  • 12 fibers
• Core Diameter:
  • Multimode: 50 µm or 62.5 µm
  • Singlemode: 9 µm
• Connector Type:
  • SC, LC, ST, or MPO/MTP (customizable)
• Construction:
  • Tight-buffered or loose tube design
• Outer Jacket Material:
  • UV-resistant polyethylene (PE) for outdoor use
  • Low smoke zero halogen (LSZH) for indoor applications
• Operating Temperature Range:
  • -20°C to +70°C (-4°F to +158°F)
• Tensile Strength:
  • Up to 1000 N
• Attenuation:
  • Multimode: ≤ 3.0 dB/km at 850 nm; ≤ 1.0 dB/km at 1300 nm
  • Singlemode: ≤ 0.4 dB/km at 1310 nm; ≤ 0.3 dB/km at 1550 nm
• Standard Compliance:
  • Telcordia GR-20 and IEC 60794-1
• Application:
  • Suitable for data centers, LANs, and telecommunication networks
• Fire Rating:
  • OFNR (Optical Fiber Non-conductive Riser) or OFNP (Optical Fiber Non-conductive Plenum), as applicable
• Cable Diameter:
  • Typically ranges from 6.0 mm to 12.0 mm, depending on construction
