General Specifications

• Product Type: Fiber Optic Adapter
• Adapter Type: SC (Subscriber Connector)
• Mode: Multimode
• Configuration: Simplex (single channel)
• Color: Blue (standard color for single-mode adapters, sometimes used for multimode)

Performance Specifications

• Insertion Loss:
  • Typically ≤ 0.2 dB
  • Maximum ≤ 0.5 dB
• Return Loss:
  • Typically ≥ 20 dB
• Operating Wavelength:
  • 850 nm and 1300 nm (common for multimode fibers)

Connector Specifications

• Connector Compatibility:
  • Designed for SC (Subscriber Connector) type fibers
• Adapter Material:
  • Durable plastic or metal housing
  • High-precision ceramic or plastic sleeve for alignment
• Sleeve Type:
  • Single ceramic or plastic sleeve for simplex connection

Mechanical Specifications

• Durability:
  • Typically rated for ≥ 500 mating cycles
• Insertion Force:
  • Designed to provide a consistent and reliable connection with minimal insertion force

Environmental Specifications

• Operating Temperature:
  • Typically -20°C to 70°C
• Storage Temperature:
  • Typically -40°C to 85°C
• Humidity:
  • 95% relative humidity, non-condensing

Compliance and Certifications

• Standards Compliance:
  • Meets or exceeds standards such as TIA/EIA-568 and IEC
• Certifications:
  • RoHS compliant
  • UL Listed or similar safety certifications

Applications

• Network Environments:
  • Suitable for use in telecommunications, data centers, and local area networks (LAN)
• Usage:
  • Ideal for connecting SC multimode fiber cables in simplex configurations within patch panels, wall plates, and fiber optic termination setups

General Specifications

• Product Type: Fiber Optic Adapter
• Adapter Type: SC (Subscriber Connector)
• Mode: Multimode
• Configuration: Simplex (single channel)
• Color: Beige (standard color for multimode adapters)

Performance Specifications

• Insertion Loss:
  • Typically ≤ 0.2 dB
  • Maximum ≤ 0.5 dB
• Return Loss:
  • Typically ≥ 20 dB
• Operating Wavelength:
  • 850 nm and 1300 nm (common for multimode fibers)

Connector Specifications

• Connector Compatibility:
  • Designed for SC (Subscriber Connector) type fibers
• Adapter Material:
  • Durable plastic or metal housing
  • High-precision ceramic or plastic sleeve for alignment
• Sleeve Type:
  • Single ceramic or plastic sleeve for simplex connection

Mechanical Specifications

• Durability:
  • Typically rated for ≥ 500 mating cycles
• Insertion Force:
  • Designed to provide a consistent and reliable connection with minimal insertion force

Environmental Specifications

• Operating Temperature:
  • Typically -20°C to 70°C
• Storage Temperature:
  • Typically -40°C to 85°C
• Humidity:
  • 95% relative humidity, non-condensing

Compliance and Certifications

• Standards Compliance:
  • Meets or exceeds standards such as TIA/EIA-568 and IEC
• Certifications:
  • RoHS compliant
  • UL Listed or similar safety certifications

Applications

• Network Environments:
  • Suitable for use in telecommunications, data centers, and local area networks (LAN)
• Usage:
  • Ideal for connecting SC multimode fiber cables in patch panels, wall plates, and fiber optic termination setups

General Specifications

• Product Type: Optical Distribution Frame (ODF)
• Core Count: 48 Core
• Adapter Type: LC (Lucent Connector) with UPC (Ultra Physical Contact) polish
• Configuration: Duplex (dual channel per adapter)
• Pre-Connectorized: 12 duplex LC/UPC adapters included
• Rack Mount: Typically designed for 1U (one rack unit high) or similar

Performance Specifications

• Insertion Loss:
  • Typically ≤ 0.3 dB per adapter
  • Maximum ≤ 0.5 dB per adapter
• Return Loss:
  • Typically ≥ 50 dB (for UPC polish)
• Operating Wavelength:
  • 1310 nm and 1550 nm (common for single-mode fibers)

Connector Specifications

• Connector Compatibility:
  • Designed for LC (Lucent Connector) type fibers
• Pre-Connectorized Adapters:
  • 12 duplex LC/UPC adapters pre-installed for easy connectivity
• Adapter Material:
  • Durable metal or plastic housing
  • High-precision ceramic or plastic sleeves for alignment
• Sleeve Type:
  • Duplex sleeves for each port

Mechanical Specifications

• Durability:
  • Typically rated for ≥ 500 mating cycles per adapter
• Insertion Force:
  • Designed to provide reliable connections with minimal insertion force

Environmental Specifications

• Operating Temperature:
  • Typically -20°C to 70°C
• Storage Temperature:
  • Typically -40°C to 85°C
• Humidity:
  • 95% relative humidity, non-condensing

Rack Mounting

• Rack Mount Type:
  • Designed for standard 19-inch racks or cabinets
• Installation:
  • Mounts in 1U of rack space or similar
• Front Panel:
  • Includes labeled ports for easy identification and management

Compliance and Certifications

• Standards Compliance:
  • Meets or exceeds standards such as TIA/EIA-568 and IEC
• Certifications:
  • RoHS compliant
  • UL Listed or similar safety certifications

Applications

• Network Environments:
  • Suitable for telecommunications, data centers, and local area networks (LAN)
• Usage:
  • Ideal for managing and connecting 48-core single-mode fiber networks
  • Provides organized and efficient patching with pre-installed duplex LC/UPC adapters

Features

• Design:
  • Compact design for high-density fiber management
• Ease of Use:
  • Pre-connectorized adapters facilitate quick and easy installations
• Maintenance:
  • Easy access to ports for maintenance and reconfiguration

General Specifications

• Product Type: Optical Distribution Frame (ODF)
• Core Count: 24 Core
• Adapter Type: LC (Lucent Connector) with UPC (Ultra Physical Contact) polish
• Configuration: Duplex (dual channel per adapter)
• Pre-Connectorized: 12 duplex LC/UPC adapters included
• Rack Mount: Typically designed for 1U (one rack unit high) or similar

Performance Specifications

• Insertion Loss:
  • Typically ≤ 0.3 dB per adapter
  • Maximum ≤ 0.5 dB per adapter
• Return Loss:
  • Typically ≥ 50 dB (for UPC polish)
• Operating Wavelength:
  • 1310 nm and 1550 nm (common for single-mode fibers)

Connector Specifications

• Connector Compatibility:
  • Designed for LC (Lucent Connector) type fibers
• Pre-Connectorized Adapters:
  • 12 duplex LC/UPC adapters pre-installed for easy connectivity
• Adapter Material:
  • Durable metal or plastic housing
  • High-precision ceramic or plastic sleeves for alignment
• Sleeve Type:
  • Duplex sleeves for each port

Mechanical Specifications

• Durability:
  • Typically rated for ≥ 500 mating cycles per adapter
• Insertion Force:
  • Designed to provide reliable connections with minimal insertion force

Environmental Specifications

• Operating Temperature:
  • Typically -20°C to 70°C
• Storage Temperature:
  • Typically -40°C to 85°C
• Humidity:
  • 95% relative humidity, non-condensing

Rack Mounting

• Rack Mount Type:
  • Designed for standard 19-inch racks or cabinets
• Installation:
  • Mounts in 1U of rack space or similar
• Front Panel:
  • Includes labeled ports for easy identification and management

Compliance and Certifications

• Standards Compliance:
  • Meets or exceeds standards such as TIA/EIA-568 and IEC
• Certifications:
  • RoHS compliant
  • UL Listed or similar safety certifications

Applications

• Network Environments:
  • Suitable for telecommunications, data centers, and local area networks (LAN)
• Usage:
  • Ideal for managing and connecting 24-core single-mode fiber networks
  • Provides organized and efficient patching with pre-installed duplex LC/UPC adapters

General Specifications

• Product Type: Optical Distribution Frame (ODF)
• Port Configuration: 12 Ports
• Adapter Type: LC (Lucent Connector) with UPC (Ultra Physical Contact) polish
• Fiber Type: Single-Mode (SM)
• Configuration: Duplex (dual channel per port)
• Rack Mount: 1U (one rack unit high)

Performance Specifications

• Insertion Loss:
  • Typically ≤ 0.2 dB per adapter
  • Maximum ≤ 0.3 dB per adapter
• Return Loss:
  • Typically ≥ 50 dB (for UPC polish in single-mode applications)
• Operating Wavelength:
  • 1310 nm and 1550 nm (common for single-mode fibers)
• Optical Compatibility:
  • Supports G.652, G.657 single-mode fiber types

Connector Specifications

• Connector Compatibility:
  • Designed for LC (Lucent Connector) type fibers
• Adapter Material:
  • Durable metal or plastic housing
  • High-precision ceramic sleeves for accurate alignment
• Sleeve Type:
  • Duplex sleeves for each port

Mechanical Specifications

• Durability:
  • Typically rated for ≥ 1000 mating cycles per adapter
• Insertion Force:
  • Low insertion force for easy connection and disconnection
• Construction Material:
  • Corrosion-resistant metal frame or high-strength plastic

Environmental Specifications

• Operating Temperature:
  • Typically -20°C to 70°C
• Storage Temperature:
  • Typically -40°C to 85°C
• Humidity:
  • Up to 95% relative humidity, non-condensing

Rack Mounting

• Rack Mount Type:
  • Designed for standard 19-inch racks or cabinets
• Installation:
  • Occupies 1U of rack space
• Front Panel:
  • Clearly labeled ports for easy identification and management
• Cable Management:
  • Integrated cable management features for organized routing

Compliance and Certifications

• Standards Compliance:
  • Meets or exceeds standards such as TIA/EIA-568 and IEC
• Certifications:
  • RoHS compliant
  • UL Listed or similar safety certifications

Applications

• Network Environments:
  • Suitable for telecommunications, data centers, enterprise networks, and local area networks (LAN)
• Usage:
  • Ideal for managing and connecting 12-port single-mode fiber networks
  • Facilitates organized and efficient patching with duplex LC/UPC adapters

Features

• Design:
  • Compact, high-density design for efficient fiber management
• Ease of Use:
  • Front-access design for straightforward installation and maintenance
• Maintenance:
  • Easy access to ports for quick maintenance, upgrades, and reconfiguration

General Specifications

• Product Type: Optical Distribution Frame (ODF)
• Port Configuration: 48 Ports
• Adapter Type: SC (Subscriber Connector) with UPC (Ultra Physical Contact) polish
• Fiber Type: Single-Mode (SM)
• Configuration: Duplex (dual channel per port)
• Rack Mount: 1U (one rack unit high)

Performance Specifications

• Insertion Loss:
  • Typically ≤ 0.2 dB per adapter
  • Maximum ≤ 0.3 dB per adapter
• Return Loss:
  • Typically ≥ 50 dB (for UPC polish in single-mode applications)
• Operating Wavelength:
  • 1310 nm and 1550 nm (common for single-mode fibers)
• Optical Compatibility:
  • Supports G.652, G.657 single-mode fiber types

Connector Specifications

• Connector Compatibility:
  • Designed for SC (Subscriber Connector) type fibers
• Adapter Material:
  • Durable metal or plastic housing
  • High-precision ceramic sleeves for accurate alignment
• Sleeve Type:
  • Duplex sleeves for each port

Mechanical Specifications

• Durability:
  • Typically rated for ≥ 1000 mating cycles per adapter
• Insertion Force:
  • Low insertion force for easy connection and disconnection
• Construction Material:
  • Corrosion-resistant metal frame or high-strength plastic

Environmental Specifications

• Operating Temperature:
  • Typically -20°C to 70°C
• Storage Temperature:
  • Typically -40°C to 85°C
• Humidity:
  • Up to 95% relative humidity, non-condensing

Rack Mounting

• Rack Mount Type:
  • Designed for standard 19-inch racks or cabinets
• Installation:
  • Occupies 1U of rack space
• Front Panel:
  • Clearly labeled ports for easy identification and management
• Cable Management:
  • Integrated cable management features for organized routing

Compliance and Certifications

• Standards Compliance:
  • Meets or exceeds standards such as TIA/EIA-568 and IEC 61754-4
• Certifications:
  • RoHS compliant
  • UL Listed or similar safety certifications

Applications

• Network Environments:
  • Suitable for telecommunications, data centers, enterprise networks, and local area networks (LAN)
• Usage:
  • Ideal for managing and connecting 48-port single-mode fiber networks
  • Facilitates organized and efficient patching with duplex SC/UPC adapters

Features

• Design:
  • High-density design for maximum fiber management in minimal rack space
• Ease of Use:
  • Front-access design for straightforward installation and maintenance
• Maintenance:
  • Easy access to ports for quick maintenance, upgrades, and reconfiguration

General Specifications

• Product Type: Optical Distribution Frame (ODF)
• Port Configuration: 48 Ports
• Adapter Type: LC (Lucent Connector) with UPC (Ultra Physical Contact) polish
• Fiber Type: Multimode (MM)
• Configuration: Duplex (dual channel per port)
• Rack Mount: 1U (one rack unit high)

Performance Specifications

• Insertion Loss:
  • Typically ≤ 0.3 dB per adapter
  • Maximum ≤ 0.5 dB per adapter
• Return Loss:
  • Typically ≥ 30 dB (for UPC polish in multimode applications)
• Operating Wavelength:
  • 850 nm and 1300 nm (common for multimode fibers)
• Optical Compatibility:
  • OM1, OM2, OM3, OM4, OM5 multimode fiber types

Connector Specifications

• Connector Compatibility:
  • Designed for LC (Lucent Connector) type fibers
• Adapter Material:
  • Durable metal or plastic housing
  • High-precision ceramic or plastic sleeves for alignment
• Sleeve Type:
  • Duplex sleeves for each port

Mechanical Specifications

• Durability:
  • Typically rated for ≥ 500 mating cycles per adapter
• Insertion Force:
  • Designed to provide reliable connections with minimal insertion force
• Construction Material:
  • Corrosion-resistant metal frame or high-strength plastic

Environmental Specifications

• Operating Temperature:
  • Typically -20°C to 70°C
• Storage Temperature:
  • Typically -40°C to 85°C
• Humidity:
  • 95% relative humidity, non-condensing

Rack Mounting

• Rack Mount Type:
  • Designed for standard 19-inch racks or cabinets
• Installation:
  • Occupies 1U of rack space
• Front Panel:
  • Includes clearly labeled ports for easy identification and management
• Cable Management:
  • Built-in features for organized cable routing and management

Compliance and Certifications

• Standards Compliance:
  • Meets or exceeds standards such as TIA/EIA-568 and IEC
• Certifications:
  • RoHS compliant
  • UL Listed or similar safety certifications

Applications

• Network Environments:
  • Suitable for data centers, enterprise networks, telecommunications, and local area networks (LAN)
• Usage:
  • Ideal for managing and connecting 48-port multimode fiber networks
  • Facilitates organized and efficient patching with duplex LC/UPC adapters

Features

• Design:
  • High-density design for efficient fiber management in minimal rack space
• Ease of Use:
  • Front-access design for easy patching and maintenance
• Maintenance:
  • Easy access to ports for maintenance, upgrades, and reconfiguration

General Specifications

• Product Type: Optical Distribution Frame (ODF)
• Rack Units: 1U
• Number of Ports: 24
• Connector Type: LC Duplex
• Connector Finish: UPC (Ultra Physical Contact)
• Fiber Type: Multimode (MM)

Adapter Panel

• Panel Type: Rack Mount
• Material: Cold-rolled steel with powder-coated finish
• Color: Typically black or gray
• Front Panel Ports: 24 LC Duplex adapters
• Rear Cable Management: Integrated management for efficient fiber routing and protection

Optical Performance

• Insertion Loss: ≤ 0.3 dB (typical)
• Return Loss: ≥ 50 dB for UPC
• Repeatability: ≤ 0.1 dB
• Durability: > 1000 mating cycles

Compatibility

• Fiber Modes: OM1, OM2, OM3, OM4, and OM5 compatible
• Cable Types: 50/125 μm and 62.5/125 μm multimode fibers
• Polishing Type: UPC polished connectors

Physical Dimensions

• Height: 1.75 inches (44.45 mm)
• Width: 19 inches (482.6 mm) standard rack width
• Depth: Typically around 10-12 inches (254-305 mm)

Environmental Specifications

• Operating Temperature: -40°C to +75°C
• Storage Temperature: -40°C to +85°C
• Humidity: 0% to 95% (non-condensing)

Installation Features

• Mounting: Standard 19-inch rack mountable
• Accessibility: Front access for easy installation and maintenance
• Cable Management: Includes rear cable management tray or brackets
• Labeling: Port numbering and labeling for easy identification

Compliance and Standards

• Industry Standards: Complies with TIA/EIA, IEC, and RoHS standards
• Fire Rating: Complies with UL 94V-0 flammability rating

Additional Features

• Design: Compact and lightweight design for efficient space utilization
• Security: Optional lockable doors for added security
• Accessories: Includes mounting screws, cable ties, and dust caps
