General Specifications

• Product Type: Optical Distribution Frame (ODF)
• Core Count: 24 Core
• Adapter Type: LC (Lucent Connector) with UPC (Ultra Physical Contact) polish
• Configuration: Duplex (dual channel per adapter)
• Pre-Connectorized: 12 duplex LC/UPC adapters included
• Rack Mount: Typically designed for 1U (one rack unit high) or similar

Performance Specifications

• Insertion Loss:
  • Typically ≤ 0.3 dB per adapter
  • Maximum ≤ 0.5 dB per adapter
• Return Loss:
  • Typically ≥ 50 dB (for UPC polish)
• Operating Wavelength:
  • 1310 nm and 1550 nm (common for single-mode fibers)

Connector Specifications

• Connector Compatibility:
  • Designed for LC (Lucent Connector) type fibers
• Pre-Connectorized Adapters:
  • 12 duplex LC/UPC adapters pre-installed for easy connectivity
• Adapter Material:
  • Durable metal or plastic housing
  • High-precision ceramic or plastic sleeves for alignment
• Sleeve Type:
  • Duplex sleeves for each port

Mechanical Specifications

• Durability:
  • Typically rated for ≥ 500 mating cycles per adapter
• Insertion Force:
  • Designed to provide reliable connections with minimal insertion force

Environmental Specifications

• Operating Temperature:
  • Typically -20°C to 70°C
• Storage Temperature:
  • Typically -40°C to 85°C
• Humidity:
  • 95% relative humidity, non-condensing

Rack Mounting

• Rack Mount Type:
  • Designed for standard 19-inch racks or cabinets
• Installation:
  • Mounts in 1U of rack space or similar
• Front Panel:
  • Includes labeled ports for easy identification and management

Compliance and Certifications

• Standards Compliance:
  • Meets or exceeds standards such as TIA/EIA-568 and IEC
• Certifications:
  • RoHS compliant
  • UL Listed or similar safety certifications

Applications

• Network Environments:
  • Suitable for telecommunications, data centers, and local area networks (LAN)
• Usage:
  • Ideal for managing and connecting 24-core single-mode fiber networks
  • Provides organized and efficient patching with pre-installed duplex LC/UPC adapters

• Cable Type: 24-Core Multimode Fiber Optic Cable
• Core Type: Multimode
• Core Count: 24 fibers
• Fiber Type:
  • Core Diameter: Typically 50 µm or 62.5 µm (micrometers)
  • Cladding Diameter: 125 µm (micrometers)
• Performance Standards:
  • OM Rating: OM3 or OM4 (common standards for multimode fibers)
  • Bandwidth:
    • OM3: Up to 2 Gbps at 850 nm, 300 meters
    • OM4: Up to 2 Gbps at 850 nm, 400 meters
• Transmission Wavelength:
  • 850 nm: Primary wavelength for multimode fiber
  • 1300 nm: Secondary wavelength for longer-distance applications
• Jacket Material:
  • Outer Jacket: Typically made of PVC (Polyvinyl Chloride) or LSZH (Low Smoke Zero Halogen)
  • Color: Often black or other industry-standard colors
• Fiber Construction:
  • Buffer: Each fiber is individually buffered for protection
  • Strength Members: Usually include aramid yarn or fiberglass for strength
  • Central Strength Member: May include a fiberglass or metallic central member for additional strength
• Cable Construction:
  • Type: Loose tube or tight-buffered
  • Loose Tube: Fibers are housed in loose tubes that are filled with a gel or water-blocking material
  • Tight-Buffered: Fibers are directly coated with a buffer layer, making them more suitable for direct termination
• Armored/Non-Armored:
  • Armored: Some variants include an additional layer of protection, such as a steel armor, for enhanced durability
  • Non-Armored: Standard version without extra protective layers
• Temperature Range:
  • Operating Temperature: Typically -20°C to 70°C (-4°F to 158°F)
  • Storage Temperature: Typically -40°C to 85°C (-40°F to 185°F)
• Bend Radius:
  • Minimum Bend Radius (Installation): 10 times the outer diameter of the cable
  • Minimum Bend Radius (Operation): 15 times the outer diameter of the cable

• Fiber Count: 24 cores
• Mode Type: Singlemode
• Core Diameter: 9 microns
• Cladding Diameter: 125 microns
• Fiber Type: OS2 (optimized for long-distance communication)
• Jacket Material: LSZH (Low Smoke Zero Halogen) for enhanced safety and reduced toxic emissions
• Cable Outer Diameter: Typically 8.5mm to 12mm (varies by manufacturer)
• Number of Fibers per Bundle: 24 fibers bundled together for organized installation
• Strength Member: Aramid yarn or glass fibers for enhanced tensile strength
• Operating Wavelength: 1310 nm & 1550 nm (optimized for long-distance transmission)
• Maximum Attenuation: ≤ 0.35 dB/km at 1310 nm; ≤ 0.20 dB/km at 1550 nm
• Minimum Bend Radius: 10x the outer diameter during installation; 20x during operation
• Temperature Range: -20°C to +70°C (Operating); -40°C to +85°C (Storage)
• Installation Method: Suitable for aerial, underground, or duct installation
• Compliance Standards: TIA/EIA-568-C.3, IEC 60793-2-50, RoHS compliant

General Specifications

• Product Type: Optical Distribution Frame (ODF)
• Rack Units: 1U
• Number of Ports: 24
• Connector Type: LC Duplex
• Connector Finish: UPC (Ultra Physical Contact)
• Fiber Type: Multimode (MM)

Adapter Panel

• Panel Type: Rack Mount
• Material: Cold-rolled steel with powder-coated finish
• Color: Typically black or gray
• Front Panel Ports: 24 LC Duplex adapters
• Rear Cable Management: Integrated management for efficient fiber routing and protection

Optical Performance

• Insertion Loss: ≤ 0.3 dB (typical)
• Return Loss: ≥ 50 dB for UPC
• Repeatability: ≤ 0.1 dB
• Durability: > 1000 mating cycles

Compatibility

• Fiber Modes: OM1, OM2, OM3, OM4, and OM5 compatible
• Cable Types: 50/125 μm and 62.5/125 μm multimode fibers
• Polishing Type: UPC polished connectors

Physical Dimensions

• Height: 1.75 inches (44.45 mm)
• Width: 19 inches (482.6 mm) standard rack width
• Depth: Typically around 10-12 inches (254-305 mm)

Environmental Specifications

• Operating Temperature: -40°C to +75°C
• Storage Temperature: -40°C to +85°C
• Humidity: 0% to 95% (non-condensing)

Installation Features

• Mounting: Standard 19-inch rack mountable
• Accessibility: Front access for easy installation and maintenance
• Cable Management: Includes rear cable management tray or brackets
• Labeling: Port numbering and labeling for easy identification

Compliance and Standards

• Industry Standards: Complies with TIA/EIA, IEC, and RoHS standards
• Fire Rating: Complies with UL 94V-0 flammability rating

Additional Features

• Design: Compact and lightweight design for efficient space utilization
• Security: Optional lockable doors for added security
• Accessories: Includes mounting screws, cable ties, and dust caps

General Specifications

• Product Type: Optical Distribution Frame (ODF)
• Port Configuration: 24 Ports
• Adapter Type: LC (Lucent Connector) with UPC (Ultra Physical Contact) polish
• Mode: Single-Mode (SM)
• Configuration: Duplex (dual channel per port)
• Rack Mount: 1U (one rack unit high)

Performance Specifications

• Insertion Loss:
  • Typically ≤ 0.3 dB per adapter
  • Maximum ≤ 0.5 dB per adapter
• Return Loss:
  • Typically ≥ 50 dB (for UPC polish)
• Operating Wavelength:
  • 1310 nm and 1550 nm (common for single-mode fibers)

Connector Specifications

• Connector Compatibility:
  • Designed for LC (Lucent Connector) type fibers
• Adapter Material:
  • Durable metal or plastic housing
  • High-precision ceramic or plastic sleeves for alignment
• Sleeve Type:
  • Duplex sleeves for each port

Mechanical Specifications

• Durability:
  • Typically rated for ≥ 500 mating cycles per port
• Insertion Force:
  • Designed to provide reliable connections with minimal insertion force

Environmental Specifications

• Operating Temperature:
  • Typically -20°C to 70°C
• Storage Temperature:
  • Typically -40°C to 85°C
• Humidity:
  • 95% relative humidity, non-condensing

Rack Mounting

• Rack Mount Type:
  • 1U rack mountable
• Installation:
  • Designed to fit standard 19-inch racks or cabinets
• Front Panel:
  • Includes labeled ports for easy identification and management

Compliance and Certifications

• Standards Compliance:
  • Meets or exceeds standards such as TIA/EIA-568 and IEC
• Certifications:
  • RoHS compliant
  • UL Listed or similar safety certifications

Applications

• Network Environments:
  • Suitable for telecommunications, data centers, and local area networks (LAN)
• Usage:
  • Ideal for organizing and managing single-mode fiber connections in a rack-mounted setup
  • Facilitates easy patching and routing of fiber optic cables within the ODF
