• General Specifications

  • Brand: D-Link
  • Product Type: Faceplate
  • Category: Cat 6
  • Port Count: Single port
  • Compatibility:
    • Designed for use with D-Link or compatible keystone jacks
    • Suitable for Cat 6 network installations

  Physical Specifications

  • Material:
    • Made from high-impact, flame-retardant ABS plastic
  • Color Options:
    • Typically available in white, ivory, or other colors to match decor
  • Dimensions:
    • Standard single-gang size: approximately 114mm x 70mm (4.5 inches x 2.75 inches)
  • Design:
    • Flush-mounted design for a clean and professional appearance
    • Smooth finish for easy cleaning and maintenance
  • Mounting:
    • Includes screws for secure mounting on standard electrical boxes or surface mount boxes
    • Compatible with both drywall and brick wall installations

  Features

  • Port Identification:
    • Integrated label holder for easy port labeling
    • Port numbering option for organized network setups
  • Keystone Compatibility:
    • Compatible with standard keystone jacks, including D-Link and other brands
    • Snap-in design allows for easy installation and removal of keystone jacks
  • Cable Management:
    • Provides a neat and organized exit point for network cables
  • Durability:
    • Resistant to cracking and damage from environmental factors

  Compliance and Certifications

  • Standards Compliance:
    • Meets or exceeds TIA/EIA-568-C.2 standards for Cat 6 installations
  • Certifications:
    • RoHS compliant, ensuring environmentally safe materials
    • UL Listed for safety and performance

  Environmental Specifications

  • Operating Temperature:
    • Suitable for use in environments with temperatures ranging from -10°C to 60°C
  • Storage Temperature:
    • Can be stored in temperatures ranging from -40°C to 70°C

  Applications

  • Network Environments:
    • Suitable for use in residential, commercial, and industrial settings
    • Ideal for structured cabling systems, including Ethernet, Fast Ethernet, and Gigabit Ethernet networks
  • Installation Locations:
    • Offices, homes, data centers, schools, and other locations requiring network connectivity

• Category: Cat 6
• Type: Unshielded Twisted Pair (UTP)
• Termination Type: Toolless Keystone Jack
• Material: High-impact, flame-retardant plastic
• Compatibility:
  • Compatible with 110 and Krone punch-down tools
  • Fits standard keystone faceplates, patch panels, and surface mount boxes
• Conductor Material: Phosphor bronze with gold-plated contacts
• Contact Resistance: 20 mΩ maximum
• Insulation Resistance: 500 MΩ minimum at 100 V DC
• Insertion Loss: ≤ 0.1 dB (1-250 MHz)
• Crosstalk:
  • Near-End Crosstalk (NEXT): ≥ 43 dB (1-250 MHz)
  • Power Sum Near-End Crosstalk (PSNEXT): ≥ 40 dB (1-250 MHz)
• Return Loss: ≥ 20 dB (1-250 MHz)
• Durability:
  • Supports up to 750 mating cycles
  • IDC Termination: Accepts 22 to 26 AWG solid cables
• Temperature Range:
  • Operating: -10°C to 60°C
  • Storage: -40°C to 70°C
• Color Coding:
  • T568A and T568B wiring schemes printed on the jack for easy identification
• Dimensions: Varies based on model but typically compact to fit standard keystone slots
• Compliance and Certifications:
  • Meets or exceeds TIA/EIA-568-C.2 standards
  • RoHS compliant
  • UL Listed
• Color Options: Available in various colors for easier network identification
• Application: Suitable for Ethernet, Fast Ethernet, and Gigabit Ethernet applications

• General Information:

  • Brand: D-Link
  • Model: Cat 6 Patchcord
  • Length: 2 meters (approx. 6.6 feet)
  • Type: Ethernet Patch Cable

  Cable Specifications:

  • Category: Cat 6
  • Cable Type: Unshielded Twisted Pair (UTP)
  • Connector Type: RJ-45
  • Pinout Standard: T568A/T568B (dual standard)
  • Conductor Material: Typically copper
  • Insulation: High-quality insulation to reduce crosstalk and interference

  Performance:

  • Transmission Speed: Up to 1 Gbps (Gigabit Ethernet)
  • Frequency: Up to 250 MHz
  • Data Rate: Supports high-speed data transmission
  • Signal Integrity: Designed to provide reliable and stable signal transmission with minimal interference

  Construction:

  • Cable Jacket Material: Typically PVC (Polyvinyl Chloride) or LSZH (Low Smoke Zero Halogen) for fire safety
  • Shielding: U/FTP (Unshielded Foiled Twisted Pair) or U/UTP (Unshielded Twisted Pair) based on model
  • Connector: Gold-plated contacts for improved conductivity and corrosion resistance
  • Boot: Often includes strain relief boots to prevent damage to the connectors and cable

  Environmental Considerations:

  • Operating Temperature Range: Typically designed for standard indoor operating conditions
  • RoHS Compliant: Generally adheres to regulations for hazardous materials

  Additional Information:

  • Packaging: Supplied individually or in bulk packaging
  • Storage: Store in a dry, cool environment to maintain cable quality
  The 2M D-Link Cat 6 Patchcord is designed to provide reliable and high-speed Eth

General Specifications

• Brand: D-Link
• Product Type: Patch Cord
• Category: Cat 6
• Cable Type: Unshielded Twisted Pair (UTP)
• Length: 0.5 meters (50 centimeters)

Performance Specifications

• Bandwidth: Supports frequencies up to 250 MHz
• Data Transmission:
  • Capable of supporting Gigabit Ethernet (1000BASE-T) and Fast Ethernet
• Insertion Loss:
  • Low insertion loss, meeting TIA/EIA-568-C.2 standards
• Near-End Crosstalk (NEXT):
  • Meets or exceeds TIA/EIA-568-C.2 standards to minimize interference
• Return Loss:
  • Meets or exceeds TIA/EIA-568-C.2 standards for signal integrity

Cable Specifications

• Conductor Material:
  • 24 AWG stranded copper for flexibility and performance
• Jacket Material:
  • PVC (Polyvinyl Chloride) or LSZH (Low Smoke Zero Halogen) for enhanced safety
• Jacket Diameter:
  • Typically between 5.8mm to 6.0mm
• Color Options:
  • Available in multiple colors such as blue, grey, yellow, red, green, and black for easy network identification

Connector Specifications

• Connector Type:
  • RJ45 to RJ45
• Connector Material:
  • Gold-plated contacts for superior conductivity and corrosion resistance
• Pin Configuration:
  • 8P8C (8 positions, 8 contacts) configuration
• Snagless Design:
  • Molded boots to prevent snagging and provide strain relief
• Durability:
  • Supports up to 750 mating cycles for long-term reliability

Compliance and Certifications

• Standards Compliance:
  • Meets or exceeds TIA/EIA-568-C.2 specifications for Category 6 cabling
  • ISO/IEC 11801 compliant
• Certifications:
  • RoHS compliant
  • UL Listed

Environmental Specifications

• Operating Temperature:
  • Suitable for use in environments with temperatures ranging from -20°C to 60°C
• Storage Temperature:
  • Can be stored in temperatures ranging from -40°C to 70°C

Applications

• Network Environments:
  • Suitable for use in data centers, enterprise networks, telecommunications rooms, and home networking
• Usage:
  • Ideal for connecting network devices such as switches, routers, patch panels, and workstations
• Compatibility:
  • Backward compatible with Cat 5e networks
